TJERNLUND PRODUCTS, INC.
1601 Ninth Street • White Bear Lake, MN 55110-6794
PHONE (800) 255-4208 • (651) 426-2993 • FAX (651) 426-9547
Visit our web site • www.tjernlund.com
WATER HEATER VENT PACKAGE
NOTE:
The VP-2 and VP-3 Water Heater Vent Packages use a solenoid valve as part
of the safety interlock circuit. The solenoid valve is installed in the gas supply piping
to the water heater's thermostat/valve. To save installation time, do not pipe gas to
water heater before installing the gas solenoid valve.
OPTIONAL PILOT SAVER KIT AVAILABLE
The optional Pilot Saver Kit (P/N: 950-2061) allows for Solenoid Valve to be installed in
1/2" burner gas line from water heater gas valve to burner, eliminating pilot outages
caused by power interruptions.
Rev. A 01/00
Copyright © 2000, Tjernlund Products, Inc. All rights reserved.
MODELS
For Natural Gas or LP
VP-2 For Millivolt Water Heaters up to
60,000 BTU/hr
VP-3 For Millivolt Water Heaters from
60,000 to 120,000 BTU/hr
OWNERS INSTRUCTIONS
THESE INSTRUCTIONS MUST REMAIN
WITH EQUIPMENT
DO NOT DESTROY
ALWAYS FOLLOW WATER
HEATER MANUFACTURER'S
INSTRUCTIONS FOR PROPER
OPERATION OF HEATER AND
RE-LIGHTING OF PILOT
Patented
P/N 8504025
