Galvin Specialised Ezy-Push 368696MX Product Installation Manualline

®
Ezy-Push CP-BS Timeflow Push Button Pillar Tap
- Temperature Mixing
PRODUCT CODES:
368696MX
-
SPECIFICATIONS
− Time flow taps are designed to operate at full mains pressure.
− The valve has a unique self-closing operation.
− The taps are made of chrome plated brass.
− Clean hygienic design.
− Easy to operate and low maintenance.
− Supplied with hot (red), warm (yellow) and cold (blue) buttons depending on the requirements.
− Smooth round designs to facilitate easy clean and help reduce dirt and bacteria growth.
Note: Time is based on 500kPa, @ 22 degrees Celsius. Time will vary plus or minus 30% based on
water temperatures, pressures, flow rates and water quality.
IMPORTANT: All Ezy-Push
accordance with AS/NZS 3718 and leave our premises in good working order. Time varies with changes to
temperature, pressure, flow rate and water quantity.
TECHNICAL DATA
Inlet
Outlet
Headwork
Working Pressure Range (kPa)
Working Temperature Range (°C)
Nominal Flow Rate (LPM)
Finish
NOTE: Galvin Specialised continually strive to improve their products. Specifications may change without
notice.
TOOLS REQUIRED
−
Power drill
−
Spanner or adjustable crescent
−
Screw driver
®
CP-BS Timeflow Push Button Pillar Tap- Temperature Mixing are tested in
th
Version 2, 12 July 2021, Page 1 of 4
½" BSP - Female
Aerator/Flow Restrictor
Time Flow Cartridge
Min 100
Max 500
Min 5
Max 65
4.6
Chrome
