US082-SSC3240EVZ
Evaluation Board for High-End 24-Bit Sensor Signal Conditioner with Analog and Digital Output
Introduction
This document provides quick-start instructions for the US082-SSC3240EVZ board, including setting up and
programming the board.
Important: To ensure correct setup of the US082-SSC3240EVZ board, complete the steps in the order listed in
Quick Start
Procedure.
Contents
1.
Board Information....................................................................................................................................................... 2
1.1
Acquiring the Board ........................................................................................................................................... 2
1.2
Board Contents .................................................................................................................................................. 2
1.2.1
Hardware Requirements ..................................................................................................................... 3
1.2.2
Software Requirements ...................................................................................................................... 3
2.
Calibration Procedure ................................................................................................................................................ 3
3.
Quick Start Procedure ................................................................................................................................................ 4
3.1
Studio .................................................................................................................................................. 4
2
3.2
Kit Hardware Connection ................................................................................................................................... 4
3.2.1
Load Cell Base and Platform .............................................................................................................. 6
4.
Board Testing ............................................................................................................................................................. 7
4.1
Programming the Renesas Development Board ................................................................................................. 7
4.2
Using RTT Viewer .............................................................................................................................................. 9
5.
References and Support........................................................................................................................................... 11
6.
Revision History ....................................................................................................................................................... 12
R36UH0021EU0100 Rev.1.00
Jul 3, 2025
Quick Start Guide
Page 1
© 2025 Renesas Electronics
Advertisement
Table of Contents
Related Manuals for Renesas US082-SSC3240EVZ
Summary of Contents for Renesas US082-SSC3240EVZ
-
Page 1: Table Of Contents
Evaluation Board for High-End 24-Bit Sensor Signal Conditioner with Analog and Digital Output Introduction This document provides quick-start instructions for the US082-SSC3240EVZ board, including setting up and programming the board. Important: To ensure correct setup of the US082-SSC3240EVZ board, complete the steps in the order listed in Quick Start Procedure. Contents Board Information............................... -
Page 2: Board Information
High-End 24-Bit Sensor Signal Conditioner with Analog and Digital Output Board Contents The US082-SSC3240EVZ board integrates the ZSSC3240, a high-precision sensor signal conditioning IC designed for amplification, digitization, and correction of resistive sensor signals including bridge, half-bridge, and single-element types like Pt100 and temperature diodes. The board offers 0V to1V or 0V to 5V absolute voltage output and VDD-ratiometric voltage output. -
Page 3: Hardware Requirements
US082-SSC3240EVZ Quick Start Guide 1.2.1 Hardware Requirements To setup and configure the US082-SSC3240EVZ board, the following hardware is recommended or required: EK-RA6M4 ■ USB micro-B cable (provided with the EK-RA6M4) ■ PC running Windows 10/11 with at least one USB port ■... -
Page 4: Quick Start Procedure
US082-SSC3240EVZ Quick Start Guide Quick Start Procedure Complete the following quick-start procedure steps in the order listed. Install e Studio Install the latest version of the Studio and the RA Flexible Software Package (FSP). Kit Hardware Connection Use the following steps to set up the kit’s hardware connections. - Page 5 US082-SSC3240EVZ Quick Start Guide 4. Plug the US082-SSC3240EVZ board into the US082-INTERPEVZ on the PMOD1 connector. Ensure all pins are properly aligned (see Figure 5. Connect the EK-RA6M4 to the computer using the USB micro-B cable. The kit is now ready to use.
-
Page 6: Load Cell Base And Platform
US082-SSC3240EVZ Quick Start Guide 3.2.1 Load Cell Base and Platform If using the load cell base and platform, assemble the platform as follows: 1. Attach the load cell to the base using M5 screws (see Figure Figure 5. Load Cell Base 2. -
Page 7: Board Testing
US082-SSC3240EVZ Quick Start Guide Board Testing Programming the Renesas Development Board 1. Open the sample project in e studio. Figure 7. ZSSC3240 Project Structure 2. Click the Build icon. Figure 8. Project Build R36UH0021EU0100 Rev.1.00 Page 7 Jul 3, 2025... - Page 8 US082-SSC3240EVZ Quick Start Guide 3. From the menu bar, select Run → Debug Configurations. Figure 9. Debug Configuration 4. Select Renesas GDB Hardware Debugging → ZSSC3240_Demo Debug_Flat (see Figure 10). 5. Click the Debug button. Figure 10. Start Debug Mode R36UH0021EU0100 Rev.1.00...
-
Page 9: Using Rtt Viewer
US082-SSC3240EVZ Quick Start Guide 6. Click the Play button to run the code. Figure 11. Running the Code Using RTT Viewer 1. Close e studio. 2. Open the J-Link RTT Viewer (see Figure 12). 3. Press S3 on the EK-RA6M4. - Page 10 US082-SSC3240EVZ Quick Start Guide 5. Ensure your configuration matches the configuration shown in Figure a. Search Range: 0x20000000 0x8000 6. Click OK. Figure 13. RTT Viewer Options 7. You should see the following output in the “All Terminals” tab. Figure 14. Demo Output R36UH0021EU0100 Rev.1.00...
-
Page 11: References And Support
US082-SSC3240EVZ Quick Start Guide 8. Add weight to the scale and the weight in grams is displayed in the terminal. Figure 15. Sensor Output with 500g Weight References and Support studio webpage ■ ZSSC3240 product page ■ RA Product Information ■... -
Page 12: Revision History
US082-SSC3240EVZ Quick Start Guide Revision History Revision Date Description 1.00 Jul 3, 2025 Initial release. R36UH0021EU0100 Rev.1.00 Page 12 Jul 3, 2025... - Page 13 Renesas' products are provided only subject to Renesas' Terms and Conditions of Sale or other applicable terms agreed to in writing. No use of any Renesas resources expands or otherwise alters any applicable warranties or warranty disclaimers for these products.
