Page 2
1. 2. Do not, drill, cut, weld or otherwise modify the towbar. FOR TOWING PURPOSES ONLY - This towbar is designed and tested by Hayman Reese to adhere to ADR 62/02 which provides only for the expected load demands of towing.
Page 4
CUSTOMER INFORMATION PLACE THESE INSTRUCTIONS IN THE VEHICLE’S GLOVEBOX AFTER INSTALLATION 1. Open the Tailgate and remove 2x Screws securing the rear bumper facia to vehicle assembly, located below the taillight. Repeat other side. 2. Remove the Plastic Trim, to exposing the fasteners to the taillight.
Page 5
CUSTOMER INFORMATION PLACE THESE INSTRUCTIONS IN THE VEHICLE’S GLOVEBOX AFTER INSTALLATION 5. Peel Bumper trim up to edge of rear bumper facia. CAUTION: Use a tool to ensure tabs disconnect from vehicle assembly as tabs are fragile and prone to breaking. 6.
Page 6
CUSTOMER INFORMATION PLACE THESE INSTRUCTIONS IN THE VEHICLE’S GLOVEBOX AFTER INSTALLATION 9. Remove and discard the rear impact beam mounts by removing 5x Bolts. Repeat other side. 10. Loosely secure the side arms to the vehicle using 3x M12 x 45 x 1.25P Bolts and 1x Washer per Bolt LHS side arm is identified by the triangular feature (cutout) 11.
Page 7
CUSTOMER INFORMATION PLACE THESE INSTRUCTIONS IN THE VEHICLE’S GLOVEBOX AFTER INSTALLATION 12. Perform a cut on the bumper trim to Clear the Towbar & Hitch box. Basing about the facia centreline, following the lines 105mm marked on the facia perform a cut that is 55mm wide and 105 mm long.
Page 8
CUSTOMER INFORMATION PLACE THESE INSTRUCTIONS IN THE VEHICLE’S GLOVEBOX AFTER INSTALLATION 16. Remove the 2x Trim Clips (1) securing the rear Scuff Trim (2). 17. Remove the rear scuff trim. 18. Remove vehicle foam insert on both side of the spare tyre.
Page 9
CUSTOMER INFORMATION PLACE THESE INSTRUCTIONS IN THE VEHICLE’S GLOVEBOX AFTER INSTALLATION 25. Locate the Vehicle 8-way Pre-Wire Connectors (1) in the LHS rear compartment area. 26. Cut back the tape to reveal 8-way Vehicle Pre-Wire Connectors. 27. Disconnect the Vehicle Pre-Wire Connectors (1), patch in the Pre-Wire Connectors (2) of the Trailer Wiring Harness (102848-WL) in between the Vehicle Pre-Wire Connectors (1).
Page 10
CUSTOMER INFORMATION PLACE THESE INSTRUCTIONS IN THE VEHICLE’S GLOVEBOX AFTER INSTALLATION 32. With the rear bumper removed, secure the Tail Harness (1) to the towbar. 33. On the LHS of the vehicle, remove the existing blanking Grommet (2). 34. Route the Tail Harness (1) up through the 30mm hole into the vehicle.
Page 11
CUSTOMER INFORMATION PLACE THESE INSTRUCTIONS IN THE VEHICLE’S GLOVEBOX AFTER INSTALLATION 43. To disable RPA function. Put the vehicle into Reverse Position and the Parking Aids Screen will display in the Vehicle Cluster Information Display (1). 44. Using the Controls on the Steering Wheel press “OK” to disable RPA.
Page 12
TOWBAR MAINTENANCE AND CARE: 1. Hayman Reese recommend that the towbar LUG or TBM (tow ball Mount) Pull Pin and R-clip are removed and stored when not in use. Removal of LUG or TBM (tow ball mount) is advisable when not in use to assist with any of the following.
Page 13
VEHICLE’S GLOVEBOX AFTER INSTALLATION HAYMAN REESE SMART PIN Your Hayman Reese towbar is equipped with Smart Pin technology to help reduce towbar tongue rattle in most driving conditions. Please ensure below instructions are understood and routine maintenance is carried out to ensure best towing experience.
