tHERMo PRoDUcts UsER ManUaL
UK
costanza IDRo 5.0
MADE
IN
ITALY
design & production
004330013 - Rev 000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COSTANZA IDRO 5.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Extraflame COSTANZA IDRO 5.0

Summary of Contents for Extraflame COSTANZA IDRO 5.0

  • Page 1 PRoDUcts UsER ManUaL costanza IDRo 5.0 MADE ITALY design & production 004330013 - Rev 000...
  • Page 2 APPLY TECHNICAL DATA LABEL...

  • Page 3: Table Of Contents

    ........................................ 12 HydrauLIc SyStEM ..................................13 installation and safetY deViCes ..................................13 aNtI-coNdENSatIoN dEVIcE (MaNdatory) .......................... 14 dEtaILS coStaNZa Idro 5.0 ............................... 15 on/off ..............................................15 fEaturES ....................................... 16 cHEckS aNd MEaSurES for coMMISSIoNING ........................16 the pellet load motor does not fUnCtion: ..............................16 bUlb thermostats - rearm ......................................
  • Page 4 ATTENZIONE TASSATIVO ATENÇÃO - OBrIgATÓrIO PrImA dI mOVImENTArE lA STufA TOglIErE lE mAIO- ANTES dE mOVImENTAr A SAlAmANdrA, rETIrAr AS lIchE INdIcATE PEr EVITArE dANNI. cErâmIcAS INdIcAdAS PArA EVITAr dANOS. PEr l’AllINEAmENTO dEl TOP uTIlIZZArE lE 4 VITI. PArA O AlINhAmENTO SuPErIOr uSE 4 PArAfuSOS. ATTENTION - cOmPulSOrY TÄhElEPANu! BEfOrE mOVINg ThE STOVE, kINdlY TAkE ThE cErA-...
  • Page 5 Silicone ENGLISH...

  • Page 6: English

    We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner...
  • Page 7 RECEIVED INSTRUCTIONS ON SAFE USE OF THE APPLIANCE AND THAT THEY UNDERSTAND THE INHERENT DANGERS. Š THE GENERATOR MUST NOT BE USED BY PERSONS (INCLUDING CHILDREN) WITH REDUCED PHYSICAL, SENSORY AND MENTAL CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.

  • Page 8: Routine Maintenance

    THAT SWITCH THE GENERATOR OFF. IF THIS OCCURS, CONTACT THE TECHNICAL AFTER-SALES SERVICE AND ALWAYS DISABLE THE SAFETY SYSTEMS. Š IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE BRIGADE.

  • Page 9: Installation

    INsTAllATION GENERAl The support surfaces and/or points must have a suitable load-bearing capacity to support the weight of the appliance, of the accessories and coatings. The generator must be on the level for correct operation. The flue extraction and hydraulic connections must be carried out by qualified personnel who must issue documentation of conformity according to the regulations of the country of installation.

  • Page 10: Ventilation And Aeration Of The Installation Premises

    VENTIlATION ANd AERATION Of ThE INsTAllATION PREMIsEs Ventilation, in the case of a non-watertight generator and/or non-watertight installation, must be carried out respecting the minimum area indicated below (considering the largest of the values suggested: Percentage of the Minimum net opening value of the Appliance categories Reference standard net opening section with respect to the...

  • Page 11: Connection To The Electricity Grid

    shAREd ChIMNEY fluE Check on the CE Technical Data Sheet whether the product is suitable for installation in a shared chimney flue (i.e. with multiple connection). Suitable devices can be installed in shared flue systems provided that: Š installation in a shared chimney flue (i.e. with multiple connection) is allowed in the place of installation; Š...

  • Page 12: Hermetically Sealed Installation

    Hermetically sealed installation The generator is a fully sealed product with respect to the environment in which it is installed. This means that it is ideal for passive houses because it does not take air in from within the house. combustion air To ensure the stove remains hermetically sealed, the connection pipe for the combustion air must be directly connected to the exterior, using special pipes and sealed connectors.

  • Page 13: Hydraulic System

    Standards in force, national, regional and municipal, as well as these instructions. For Italy, installation must be carried out by professionally qualified staff (Ministerial Decree dated 22.01.08 n°37). Extraflame S.p.A. declines all responsibility for damage to objects and/or persons caused by the system. TYPE OF SYSTEM Š...

  • Page 14: Anti-Condensation Device (Mandatory)

    DISTANCES OF SAFETY DEVICES ACCORDINg TO THE STANDARD The temperature safety sensors must be in place on the machine at a distance no greater than 30 cm from the flow connection. Whenever the generators lack a device, those missing can be installed on the generator flow pipe, within a distance no greater than 1 m from the machine. COMMISSIONINg CHECkS Before connecting the boiler: a) wash all system piping thoroughly in order to remove any residues which might compromise the correct functioning of certain system...

  • Page 15: Details Costanza Idro 5.0

    Details COstaNZa iDRO 5.0 Room air outlet Display Door handle Pellet hopper Access to the ash pressurised closure drawer Room air outlet Combustion air inlet Rearming fumes exhaust On/Off fuse Power supply 230v HyDRauliC iNstallatiON 3 bar safety drain Boiler flow/output...

  • Page 16: Features

    featuRes Water content of the thermo-product heat exchanger (l) volume of expansion vessel integrated into thermo-product (l) 3 bar safety valve integrated into the thermo-product Minimum and maximum pressure switch integrated into the thermo-product PWM Pump integrated into the thermo-product Pump max.

  • Page 17: Stove Positioning

    stOve pOsitiONiNg for correct product functioning, it is recommended to position it in a way that it is perfectly level, with the aid of a spirit level. NOte fOR CORReCt OpeRatiON EnsUrE ThE hoppEr is propErly closED BEforE TUrning on ThE DEvicE! Pellet hopper lid DUring sTarT-Up: The generator performs a check on the combustion air flow during the START phase.

  • Page 18: Pellets And Loading

    PELLETS AND LOADING Pellets are made by subjecting wood shavings i.e. the rejects of pure unpainted wood from sawmills, carpentry products and products from other activities connected to wood working and transformation, to very high pressures. This type of fuel is fully ecological as no glues are used for its compaction. In fact, pellet compactness is guaranteed over time by a natural substance found in wood: lignin.

  • Page 19: Remote Control

    Remote contRol The remote control can be used to adjust the main stove functions. Transmitter Select air mode* Display Lock keyboard On/off stove (hold for 3 seconds) Degrees Celsius / Fahrenheit Set power Press the button once to enable or disable the chrono Set switch-off delay: The button allows to set the switch- off delay.

  • Page 20: Remote Control Icons

    Remote contRol Icons Air mode selected: * Enable chrono Flashing COMFORT Light on = activated On AUTO Light off = deactivated Indicates the transmission of the radio signal Set switch-off delay * On = during all radio communication Off = radio communication absent Battery low Keys locked Set power level.

  • Page 21: Touch Screen Display

    TOUCH SCREEN DISPLAY The stove is equipped with a modern touch screen display with WiFi technology that allows for the individual functions of the unit to be adjusted by the user in an easy and intuitive manner. Touch the buttons (icons) on the display to activate the actions. The touch screen display reacts with the touch of you fingers. CAUTION! Š...

  • Page 22: Control Board

    CONTROL BOARD vieWing oF vArious TexT messAges Water temperature (h2o) Temperature detected in detected in the boiler environment on/off stove. increase operating power / scroll through the menus. Decrease operating power / scroll through the menus. increase operating thermostat set / scroll through the menus. Decrease operating thermostat set / scroll through the menus.

  • Page 23: General Menu

    gENERAL mENU go back - exit scroll parameters: next (3); previous (2) modify data settings: increase (4); decrease (5) confirm - access menu vENTILATION ENABLINg SPEED EASY SETUP SET THERMOSTAT CHRONO ENABLINg PRg1 PRg2 SETTINgS DATE-TIME PRg3 LANgUAgE PRg4 DISPLAY STAND-BY FIRST LOAD OUTLET AIR...

  • Page 24: Commissioning Settings

    COmmISSIONINg SETTINgS Once the power cable at the back of the stove has been connected, move the switch, also located on the back, to (I). The switch at the back of the stove powers the stove board. DATE-TImE This menu allows the date and time to be set. conTroLs proceDure Š...

  • Page 25: Operation And Logic

    OPERATION AND LOgIC IgNITION once the points listed previously have been checked, press key 1 for three seconds to ignite the stove. 15 minutes are available for the ignition phase. After ignition and having reached the control temperature, the stove interrupts the ignition phase and passes to sTArTing. PREPARATION During the start-up phase, the stove stabilises combustion, increasing it progressively, to then start ventilation and pass on to WorK.

  • Page 26: Additional Thermostat

    ADDITIONAL THERmOSTAT N.B. : INSTALLATION mUST BE PERfORmED BY AN AUTHORISED TECHNICIAN There is a possibility to control the temperature of a room adjacent to the room where the stove has been placed; simply connect a thermostat following the procedure described in the following section (it is advisable to place the optional mechanical thermostat at a height from the ground equal to 1.50m).

  • Page 27: Ventilation

    vENTILATION The menu allows you to enable and adjust the speed (-2, -1, 0, +1, +2) of the front fan. enABLing conTroLs proceDure Š press key 6. Š press 3 until vENTILATION appears and confirm by pressing 6. Š confirm enABLing by pressing the 6 key. Š...

  • Page 28: Chrono

    CHRONO This function allows the stove's ignition and switch-off to be automatically programmed. The factory setting for chrono is off. The chrono allows the programming of 4 time slots within a day, which can be used every day of the week. Ignition and switch-off times can be set for each time slot, along with the specific days of application for the programmed time slot, the desired temperature and power setting.
  • Page 29 EXAMPLE OF CHRONO OvERLAPPINg TIME/SLOTS Time sLoT 02:00 08:00 16:30 23:00 seT poWer 02:00 08:00 16:30 23:00 seT h2o 72°C 68°C 02:00 08:00 16:30 23:00 start 02:00 Time slot 1 power 3 - seT h2o 72°c stop 23:00 start 08:00 Time slot 2 power 1 - seT h2o 68°c stop 16:30...

  • Page 30: Settings

    SETTINgS • DATE-TImE • LANgUAgE See chapter: commiSSioning SettingS. • SET DEgREES DISPLAY This menu allows you to adjust the brightness of the display. The values range from oFF, 1 to 20. if set to oFF, the display backlighting is set to maximum brightness and then, turns off after a 60 second delay.

  • Page 31: Wi-Fi

    This allows remote management and control of the stove using the dedicated App for smartphones, “Totalcontrol 2.0” (Apple store / play store). Follow the instructions given in the specific manual. Visit the website: https://www.lanordica-extraflame.com/sites/default/files/documenti_temp/004281060-000_istr.app_total_control_2.0.pdf. Wi-Fi enABLing conTroLs proceDure Š press key 6.

  • Page 32: Cleaning And Maintenance

    TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM cleaning and maintenance alwayS follow the inStructionS in complete Safety! Š Make sure that the power cord is unplugged because the generator may have been programmed to switch on.
  • Page 33 burn pot and combuStion chamber: Š Open the fire door. Š Suck the ash deposited between the partition and the fire door. Š Remove the resistor assembly. Š Remove the burn pot. Š Clean the combustion chamber and the bottom of the burn pot completely, using a suitable vacuum cleaner.

  • Page 34: Routine Maintenance Performed By Qualified Technicians

    So aS to avoid all riSkS. TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM routine maintenance performed by Qualified technicianS routine maintenance must be performed at least once a year.
  • Page 35 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES ONLY. Fumes motor (disassembly and cleaning and fumes pipe and "T"), new silicone in the provided points...
  • Page 36 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES ONLY. Fumes motor (disassembly and cleaning and fumes pipe and "T"), new silicone in the provided points...

  • Page 37: Displays

    Displays Display Reason Generator off sTaRT The start-up phase is in progress pelleT loaDinG Continuous pellet feeding is in progress during the ignition phase iGniTion The ignition phase is in progress pRepaRaTion The PREPARATION phase is in progress WoRK The normal work phase is in progress MoDUlaTion The generator is working at minimum **BURn poT CleaninG...

  • Page 38: Alarms

    alaRMs Display eXplanaTion solUTion On: indicates the presence of an alarm Flashing: indicates the deactivation of the depression sensor. The alarm can be reset only if the fumes motor has stopped and 15 minutes Indicates the presence of an alarm. have passed since the alarm was displayed, by pressing the key ON/OFF for 3 seconds.
  • Page 39 The automatic cleaning of the burn pot is Check that the door closes correctly. Check that the burn pot is clear and blocked. **TRapDooR BloCKeD clean. The automatic cleaning of the burn pot is blocked. Burn pot dirty/clogged If the problem persists, contact the service centre. The door is not closed correctly.

  • Page 40: Disposal

    Disposal InformatIon for management of electrIc and electronIc applIance waste contaInIng batterIes or accumulators This symbol, which is used on the product, batteries, accumulators or on the packaging or documents, means that at the end of its useful life, this product, the batteries and the accumulators included must not be collected, recycled or disposed of together with domestic waste. Improper management of electric or electronic waste or batteries or accumulators can lead to the leakage of hazardous substances contained in the product.

  • Page 41: Symbol En 16510-1

    Symbol EN 16510-1 EN 16510-1 EXPLANATION Symbol Nominal heat output part Part load heat output CON / INT Appliance operation, Continuos (CON) or Intermittent (INT) / CO Carbon dioxide emission 2 nom 2 part / CO Carbon monoxide emission part Minimum distances to combustible materials - bottom Minimum distances to combustible materials - ceiling Minimum distances to combustible materials - floor in front...
