Stufe a Pellet User manual Cleopatra Read the instructions carefully before installation, use and maintenance. The instruction book is an integral part of the product.
Page 3
AUTHORISED SPECIALIST COMPANY _________________________________________________________________ Mr. _______________________________________________________________________ STREET NAME __________________________________________N°. __________________ Post code _______ TOWN/CITY _________________ COUNTY ______________________ TELEPHONE _________________________ FAX __________________________________ Cleopatra has been realised according to the Directive: 89/106 EEC (Construction Products) and the Standard: EN 13240...
Do not leave the packaging elements within has been installed. reach of children or unassisted disabled persons. Extraflame S.p.A. cannot be held responsible for the failure to comply with such precautions. The hearth door must always be closed during normal functioning of the product.
Chapter 2 TECHNICAL FEATURES Features U.M. Cleopatra Weight Height 1165 Width Depth Flue exhaust pipe diameter Air intake pipe diameter Max. heating volume Max. global heat output 10.0 Max. useful heat output - useful output power to the air - useful output power to the water Min.
Page 7
Chapter 2 fi gure 2.1 TECHNICAL FEATURES...
Chapter 3 WHAT IS THE PELLET? Pellets are realised by subjecting wood shavings i.e. the rejects of pure wood (without paint) sawmill, carpenter products and products from other activities connected to working and transforming wood, to very high pressures. This type of fuel is absolutely ecological as no glues are used to hold it together. In fact, the compactness of the pellets is guaranteed through time by a natural substance that is found in wood: lignite.
Chapter 3 PELLET FEEDING Initially open the lateral door to access the mechanics that allow to feed the pellets and check the correct positioning of lever A. Open the handle of the tank lid. Start position of the lever fi gure 3.1 fi gure 3.2 fi gure 3.3 On opening the tank lid, there is a compartment...
Page 10
Chapter 3 At this point close the tank lid, also closing the handle to guarantee sealing. Press point B slightly to allow movement of knob A in the direction indicated by the arrow: in this way the pellets in the compartment will descend into the tank.
Chapter 4 ASSEMBLY AND INSTALLATION INSTRUCTIONS The installation must be in compliance with: UNI 10683 (2005) heat generators fed with wood and other solid fuels: installation. The chimneys have to be in compliance with: UNI 9731 (1990) chimneys: classifi cation based on thermal resistance. EN 13384-1 (2006) chimneys thermal and fl uid-dynamics calculation method.
Chapter 4 SMOKE EVACUATION SYSTEMS Flue gas exhaust system independent from the appliance constituted by a fitting or smoke channel, chimney or individual flue and chimney cap. NATURAL DRAUGHT Draught which determinates in a chimney/flue for effect of the volume mass difference existing between smoke (hot) and surrounding atmosphere air, without any mechanical intake aid installed inside it or at its peak.
Chapter 4 CONNECTION OF THE SMOKE CHANNEL OR FITTINGS TO THE FLUE GAS EXHAUST SYSTEM To mount the smoke channels, non-fl ammable elements will have to be used, ideal for resisting fuel products and their eventual condensing. The use of fl exible metal and asbestos cement pipes to connect the appliances to the fl ue is forbidden, even for pre-existing smoke channels.
Chapter 4 CHIMNEY OR INDIVIDUAL FLUE The chimney or individual fl ue must respond to the following requisites: sealed from combustion products, impermeable and suitably isolated and insulated; to the similar conditions of use; be realised with materials which resist the normal mechanical stresses, heat, action of the fuel products and any condensing;...
Chapter 4 APPLIANCE CONNECTION TO THE FLUE AND EXHAUST OF THE COMBUSTION PRODUCTS The fl ue must receive the discharge from only one heat generator. The direct discharge towards closed spaces is forbidden, even with clear sky. The direct discharge of the fuel products must be at roof and the smoke pipe must have the features provided in the “Chimney or individual fl ue”...
Chapter 4 CHIMNEY CAPS, DISTANCES AND POSITIONING Distance between the Minimum chimney height Roof inclination ridge and the chimney (measured from outlet) β A (m) H (m) < 1,85 0,50 m above the ridge 15° > 1,85 1,00 m of the roof <...
This appliance must not be used to burn waste. AIR REGISTER The Cleopatra stove has a register for the regulation of primary air for combustion: the regulation knob is accessible on the left of the ash drawer by opening the lower door. The register allows to regulate the inlet air used for combustion of the pellet that determines consumption and the consequent heat output supplied (e.g.
SWITCH-OFF Cleopatra is supplied with a system that interrupts pellet supply to the burner: using a lever it is possible to block the natural sliding of the pellet towards the burner. In this way it is possible to “switch the stove off ”, which will continue its functioning once the pellets have fi nished, which is under the blocking lever.
Chapter 6 CLEANING Maintenance operations guarantee correct functioning of the product through time. Failure to comply with these operations can jeopardise the safety of the product. USING THE GRATE SHAKER COMBS During normal stove functioning the cinders must be shaken to prevent stratifi cation of the ash. To do this use the grate shaker combs, whose lever is accessible GRATE SHAKER by opening the lower box: hook the supplied irons...
Chapter 6 INSPECTING THE LIDS If the stove has diffi culty with perfect combustion of the pellets, check the correct positioning of the upper inspection lid or open the lateral inspection lid (fi xed with 4 winged nuts) and clean the pellet tank. Upper inspection lid Lateral inspection lid fi gure 6.4...
Chapter 7 RECOMMENDATIONS FOR USE Problem Possible cause Possible solution Check that the fl ue is not obstructed by soot, that the butterfl y for draught regulation is not completely Butterfl y valve in the closed fl ue closed and that draught between 14 and 20 Pa is Flue gas exhaust pipe blocked by guaranteed soot...
Page 22
Chapter 7 Regulate draught to between 14 and 20 Pa using The fi re burns well but Excessive fl ue draught the butterfl y in the fl ue the stove and the room Room of installation too big or with Insulate the room as well as possible in order to do not heat up dispersion points of excessive heat.
Chapter 8 WARRANTY EXTRAFLAME S.p.A. You are reminded that the manufacturer is the owner of the rights envisioned by the Legislative Decree dated 2 February 2002, n. 24 and the following warranty does jeopardise these rights. This warranty certifi cate, granted by Extrafl ame S.p.A., with offi ces in Montecchio Precalcino (VI), via dell’Artigianato 10, refers to all stove components supplied by Extrafl ame S.p.A.
Page 24
In case of replacing particulars, the warranty is not extended. No compensation will be paid for the time the product is ineffi cient. This is the only valid warranty and no one is authorised to issue others in name or on behalf of EXTRAFLAME S.p.A..
Chapter 9 Chapter 9 QUALITY CONTROL Document to be kept and produced if an intervention is requested under warranty Name Surname Address Post code Municipality of residence Province Telephone Model Serial N°. Dealer Date of Purchase IMPORTANT: I accept I do not accept Information note for the purpose and eff ect of Legislative Decree 196/2003 - Your personal data is processed by the company with full respect of the Legislative Decree 196/2003 for the entire duration of the contractual relationship and subsequently, in order to fulfi l all legal requirements as well as to effi ciently manage the commercial relationships.
