pEllET sTOvEs usER MANuAl
UK
DAHIANA - DAHIANA plus
MADE
IN
ITALY
TEOREMA
design & production
004280386 - Rev 000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAHIANA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Extraflame DAHIANA

Summary of Contents for Extraflame DAHIANA

  • Page 1 MANuAl DAHIANA - DAHIANA plus MADE ITALY TEOREMA design & production 004280386 - Rev 000...
  • Page 2 ENGLISH...

  • Page 3: Table Of Contents

    PREPARATIONS FOR MAINTENANCE ........................................9 tEorEMa dEtaILS ......................................11 daHIaNa dEtaILS ......................................12 daHIaNa pLuS dEtaILS ....................................13 Hot aIr ductING (daHIaNa pLuS) ................................14 AddITIONAl ThERMOSTAT TO CONTROl ThE duCT MOTOR ...............................14 bulb ThERMOSTAT REACTIvATION ........................................14 FuSE ....................................................14 StovE poSItIoNING ..................................... 15 NotE for corrEct opEratIoN ................................
  • Page 4 ATENÇÃO - OBrIgATÓrIO ATTENZIONE TASSATIVO ANTES dE mOVImENTAr A SAlAmANdrA, rE- PrImA dI mOVImENTArE lA STufA TOglIErE lE TIrAr AS cErâmIcAS INdIcAdAS PArA EVITAr mAIOlIchE INdIcATE PEr EVITArE dANNI. dANOS. ATTENTION - cOmPulSOrY TÄhElEPANu! BEfOrE mOVINg ThE STOVE, kINdlY TAkE ThE ENNE Ahju lIIguTAmIST EEmAldAgE SEllElT cErAmIcS Off IN OrdEr TO NÄIdATud kErAAmIlISEd OSAd, ET VÄlTIdA...
  • Page 5 TEOREMA ENGLISH...

  • Page 6: English

    We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner...
  • Page 7 CHILDREN) WITH REDUCED PHYSICAL, SENSORY AND MENTAL CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY. Š THE CLEANING AND MAINTENANCE REQUIRED BY THE USER MUST NOT BE PERFORMED BY CHILDREN WITHOUT SUPERVISION.

  • Page 8: Routine Maintenance

    SYSTEMS. Š IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE BRIGADE. Š THIS APPLIANCE MUST NOT BE USED TO BURN WASTE Š DO NOT USE ANY FLAMMABLE LIQUIDS FOR IGNITION Š...

  • Page 9: Installation

    InstallatIOn general The flue gas exhaust and hydraulic connections must be carried out by qualified personnel who must issue installation conformity documentation compliant with national standards. The installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);...
  • Page 10 In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: Š they must be protected with grids, metal mesh, etc., but without reducing the net useful section; Š...

  • Page 11: Teorema Details

    TEorEmA DETAIls Ambient air outlet Pellet hopper Bulb thermostat reactivation On/Off Access to combustion chamber Combustion air inlet fuse and ash drawer 230V power supply Rear fumes exhaust Additional thermostat Upper fumes exhaust input Ambient probe ENGLISH...

  • Page 12: Dahiana Details

    DAHIANA DETAIls On/Off Access to combustion chamber Bulb thermostat reactivation fuse and ash drawer 230V power supply Pellet hopper Combustion air inlet Ambient probe Additional thermostat Ambient air outlet Rear fumes exhaust input ENGLISH...

  • Page 13: Dahiana Plus Details

    DAHIANA plus DETAIls Access to combustion chamber Combustion air inlet Ambient probe and ash drawer Additional thermostat Rear fumes exhaust input Pellet hopper Ducting additional Bulb thermostat reactivation thermostat input On/Off Ambient air outlet fuse Ducting outlet 230V power supply...

  • Page 14: Hot Air Ducting (Dahiana Plus)

    HoT AIr DuCTING (DAHIANA plus) The pipe used for ducting the hot air must have an internal diameter of 80 mm and it must also be insulated or at least be protected against heat dispersion. features: Š possibility to thermostat the ducting Š...

  • Page 15: Stove Positioning

    sTovE posITIoNING To ensure the stove works correctly, it should always be positioned so that it is perfectly level, using a spirit level. NoTE For CorrECT opErATIoN Pellet hopper lid The following indications must be respected for correct pellet stove operation: Both during stove operation and when it is not used, all hatches (pellet hopper, door, ash drawer) must remain closed at all times.

  • Page 16: Pellets And Loading

    Pellets and loading Pellets are made by subjecting wood shavings i.e. the rejects of pure unpainted wood from sawmills, carpentry products and products from other activities connected to wood working and transformation, to very high pressures. This type of fuel is fully ecological as no glues are used for its compaction. In fact, pellet compactness is guaranteed over time by a natural substance found in wood: lignite.

  • Page 17: Remote Control

    Remote contRol The remote control can be used to adjust the main stove functions. Transmitter Select air mode Display Lock keyboard On/off stove (hold for 3 seconds) Degrees Celsius / Fahrenheit Set power Press the button once to enable or disable the chrono Set switch-off delay: The button allows to set the switch- off delay.

  • Page 18: Remote Control Icons

    Remote contRol Icons Air mode selected: Enable chrono Flashing COMFORT Light on = activated On AUTO Light off = deactivated Indicates the transmission of the radio signal Set switch-off delay On = during all radio communication Off = radio communication absent Battery low Keys locked Set power level.

  • Page 19: Control Board

    Control Board ViewiNg OF VariOUs TO aCCess ON/OFF TexT messages THe meNU BUTTON OPeraTiNg POwer TemPeraTUre ICon key indicates the presence of an alarm. indicates the weekly programming status Off: indicates there are no alarms Off: deactivated. On: indicates the presence of an alarm On: activated.

  • Page 20: General Menu

    Stand BY dELta-t FirSt Load dEgrEES rESEt EaSY controL *DAHIANA PLUS ONLY **StoVE StatuS **TECHNICIANS ONLY **tEcH mEnu General warninGs advice to follow for the first start-ups of the product: Before turning on the product, it is necessary to perform the...

  • Page 21: First Ignition Settings

    FIRST IGNITION SeTTINGS Once the power cord at the back of the stove has been connected, move the switch, also located on the back, to (I). The switch at the back of the stove powers the stove board. The stove remains off and a first screen appears on the panel reading OFF . DaTe-TIme This menu allows the date and time to be set.

  • Page 22: Operation And Logic

    operatIon and loGIC IGnItIon Once the previously listed points have been checked, press key 1 for three seconds to ignite the stove. During ignition, the stove will check for a flame for a period of 15 minutes. when the right temperature is reached, the stove will switch from ignition to PreParaTiON. preparatIon During the preparation phase, the stove stabilises combustion, increasing it progressively, to then start ventilation and switch to wOrK work...

  • Page 23: Front Air

    front aIr This menu allows you to set the front air motor speed. range: (COMFORT, AuTO). when COMFORT mode is selected, the front air speed is reduced with respect to AuTO mode. The front air is normally excluded when the product is set to minimum power, once the appropriate temperature conditions have been guaranteed.

  • Page 24: Chrono

    Chrono This function allows stove ignition and switch-off to be automatically programmed. The factory setting for CHRONO is off. The chrono allows the programming of 4 time slots per day, which can be used every day of the week. for each time slot, it is possible to set ignition and switch-off times, specific days of application, desired temperature and set power. Current day and time settings are essential for the correct operation of the Chrono.
  • Page 25 EXAMPLE OF CHRONO OVERLAPPINg TIMES/SLOTS TIME SLOT 02:00 08:00 16:30 23:00 SET POWER 02:00 08:00 16:30 23:00 SET THERMOSTAT 22° 18° 02:00 08:00 16:30 23:00 start 02:00 Time slot 1 power 3 - seT THermOsTaT 22°C stop 23:00 start 08:00 Time slot 2 power 1 - seT THermOsTaT 18°C stop 16:30...

  • Page 26: Settings

    settInGs • date-tIme • lanGuaGe See chapter: firSt ignition SettingS • deGrees DISPLAY This menu allows you to adjust the brightness of the display. The values range from OFF, 1 to 20. if set to OFF, the display backlighting is set to maximum brightness and turns off after a 60 second delay.

  • Page 27: Additional Thermostat

    addItIonal thermostat n.B. : InstallatIon must Be performed By an authorIsed teChnICIan it is possible to control the temperature of a room adjacent to the room where the stove is positioned; simply connect a thermostat following the procedure described in the following section (it is advisable to place the optional mechanical thermostat at a height off the ground equal to 1.50 m).

  • Page 28: Additional Functions

    EASY CONTROL The functions allows for two values to be set: Š OFF (disabled - factory default) Š ON (enabled) activation (easY CONTrOL = ON) is recommended in the event that there is an excessive formation of combustion residues in the flue during operation at reduced power (see FLUe exHaUsT chapter).

  • Page 29: Cleaning And Maintenance

    TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM Cleaning and maintenanCe always follow the instruCtions in Complete safety! Š Make sure that the power cord is unplugged because the generator may have been programmed to switch on.
  • Page 30 burn pot and Combustion Chamber: Š Vacuum the residue in the burn pot Š Remove the burn pot completely from the relevant compartment; Š Vacuum the ash from the burn pot slot, ignition plug pipe holder and combustion chamber. Š Clear/clean all the holes in the burn pot. Š...

  • Page 31: Routine Maintenance Performed By Qualified Technicians

    BURN POT HOLES TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM routine maintenanCe performed by Qualified teChniCians routine maintenance must be performed at least once a year. Since the generator uses pellets as solid fuel, it requires annual routine maintenance, which must be performed by a Qualified technician, using only original spare parts.
  • Page 32 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM DAHIANA - DAHIANA PLUS THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. Fumes motor (dismantle and clean the smoke duct and "T"), new seal where required...
  • Page 33 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM TEOREMA THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. * Not supplied by the manufacturer. Fumes motor (dismantle and clean the smoke duct and "T"), new seal where required...

  • Page 34: Displays

    Displays Display Reason Generator off sTaRT The start-up phase is in progress pelleT loaDinG Continuous pellet loading is in progress during the ignition phase iGniTion The ignition phase is in progress pRepaRaTion The preparation phase is in progress WoRk The normal work phase is in progress MoDulaTion The generator is working at minimum final cleaninG...

  • Page 35: Guarantee Terms

    EXTRAFLAME S.p.A. cannot be held liable for injury or damage which may - either directly or indirectly - be caused to persons, animals and property ensuing from failure to observe all the instructions provided in the relevant instruction manual and the warnings regarding installation, use and maintenance of the product, that can also be downloaded on the website.

  • Page 36: Disposal

    AddITIONAL wARNINGs Š Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator. Š Do not use the product as a ladder or supporting structure. Š Do not place laundry on the product to dry it. Any clothes-horse or similar objects must be kept at due distance from the product. Danger of fire or damage to the coating.
  • Page 37 ENGLISH...
  • Page 38 ENGLISH...
  • Page 39 ENGLISH...
  • Page 40 ExtraflamE S.p.a. Via Dell’Artigianato, 12 36030 - MONTECCHIO PRECALCINO (VI) - ITALY   +39.0445.865911 -  +39.0445.865912 -  info@extraflame.it - www.lanordica-extraflame.com MADE ITALY design & production TO FIND THE SERVICE CENTRE NEAREST TO YOU CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM...
