pellet stoves User manUal
UK
Comfort mini, Comfort mini Crystal
MADE
IN
ITALY
design & production
004276519 - Rev 005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Comfort Mini and is the answer not in the manual?

Questions and answers

Related Manuals for Extraflame Comfort Mini

Summary of Contents for Extraflame Comfort Mini

  • Page 1 User manUal Comfort mini, Comfort mini Crystal MADE ITALY design & production 004276519 - Rev 005...
  • Page 2 ENGLISH...

  • Page 3: Table Of Contents

    attENtIoN SurfacES caN bEcoME vEry Hot! aLWayS uSE ProtEctIvE GLovES! During combustion, thermal energy is released that significantly increases the heat of surfaces, doors, handles, controls, glass, exhaust pipes, and even the front of the appliance. Avoid contact with those elements if not wearing protective clothing (protective gloves included).

  • Page 4: English

    We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner or user, or if transferred to another place.

  • Page 5: Routine Maintenance

    Š DO NOT LEAVE THE PACKAGING ELEMENTS WITHIN REACH OF CHILDREN OR UNASSISTED DISABLED PERSONS. Š THE HEARTH DOOR MUST ALWAYS BE CLOSED DURING NORMAL FUNCTIONING OF THE PRODUCT. Š WHEN THE APPLIANCE IS FUNCTIONING AND HOT TO THE TOUCH, ESPECIALLY ALL EXTERNAL SURFACES, ATTENTION MUST BE PAID Š...

  • Page 6: Installation

    InstallatIon general The flue gas exhaust and hydraulic connections must be carried out by qualified personnel who must issue installation conformity documentation compliant with national standards. the installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);...
  • Page 7 In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: Š they must be protected with grids, metal mesh, etc., but without reducing the net useful section; Š...

  • Page 8: Installation

    INSTALLATION The insert is supplied with an iron sliding base that allows to install it in a pre-existing flue. This sliding base allows the easy extraction of the insert both for pellet feeding inside the feed-box and for any maintenance or cleaning at the end of the season.

  • Page 9: Pedestal Assembly (Optional)

    ). Further information on the accessories is available on the website: www.extraflame.it/support, in the category "accessories". AIr CIrCuLATION pIpES It is necessary to create air recirculation inside the structure that covers the insert for correct functioning. This prevents the appliance from over-heating.
  • Page 10 The following measurements must be respected: Š LOwEr pArT (COLD AIr INLET) wITh TOTAL mINImum SurFACE 550 Cm². Š uppEr pArT (hOT AIr OuTLET) wITh TOTAL mINImum SurFACE 500 Cm². ThIS vENTILATION SySTEm IS TOTALLy INDEpENDENT FrOm ThE AIr INTAkE FOr COmBuSTION!! Minimum 5 cm ThE INSErT muST LIE AT LEAST 1 Cm ABOvE ThE FIrE SurFACE IN COvErINg mArBLE.

  • Page 11: Insert Extraction

    For correct functioning of the insert, during construction of the flue the measurements between the insert and internal walls of the flue must be respected (figure below). From the clearance measurements of the stove given in the technical features, it is necessary to consider at least 50 mm of air in the upper part and on the 2 sides.

  • Page 12: Mounting The Frames

    Š EN pLuS - uNI EN 14961 - 2 (uNI EN ISO 17225-2) class A1 - A2 Extraflame recommends the use of pellets with a 6 mm diameter with its products. Open the tank lid and load the pellets using a scoop.

  • Page 13: The Remote Control

    THE REMOTE CONTROL The display changes in relation to the status of the stove or the menu shown. In the rest status the display shows the following items: DispLay TiME: The current time is stated. The regulation of the same is found inside the weekly programmer (see SET CLOCK menu).

  • Page 14: General Features

    GENERaL FEaTuREs The user interface is provided with a backlit LCD display. The backlighting lasts about 4 seconds. Display backlighting time can be set. Press keys 1 and 7 simultaneously to access. After having accessed, use keys 1 or 2 to select the time in seconds from 0 to 9. Direct controls for ignition/switch-off, power change, room temperature.

  • Page 15: Menu Structure

    MENu sTRuCTuRE kEys 1 & 2: to set - enable data and parameters. kEy 3: to confirm the parameter and exit. kEy 4: to adjust the thermostat setting kEy 5: to adjust the power setting kEy 6: to go back in the menu. kEy 7: to go forwards in the menu.

  • Page 16: Commissioning Settings

    COMMissiONiNG sETTiNGs Once the power cable at the back of the stove has been connected, move the switch to (I). The stove switch powers the stove board. The stove remains off and a first screen appears on the panel reading OFF . MaiNs FREquENCy 50/ 60Hz In the event the stove is installed in a country with 60hz frequency, the stove will display "frequenza rete errata"...

  • Page 17: Adjusting Language

    aDjusTiNG LaNGuaGE COnTROLS PROCEDuRE Press key 7 for a few seconds, until SET CLOCK appears. Š Press key 2 twice until set Language appears. Š Confirm using key 7. Š Select the language using key 1 or 2. Š Press key 3 several times to confirm and exit the Menu. Š...

  • Page 18: Functioning And Logic

    FuNCTiONiNG aND LOGiC iGNiTiON 20:00 Once the points listed previously have been checked, press 21° key 3 for three seconds to ignite the stove. 15 minutes are available for the ignition phase. After START ignition and having reached the control temperature, the stove interrupts the ignition phase and passes to STARTIng.

  • Page 19: Room Probe And Stand By Function

    ROOM pRObE aND sTaND by FuNCTiON: The STBY function is used if immediate stove switch-off is required when the set temperature has been reached. in the factory the sTby function is always set at OFF (sTby indicator light off) sTby FuNCTiON sET aT OFF (FACTORY SETTIng) If the STBY function is not active (OFF), if the stove reaches the room temperature set, it will go to minimum, modulating and displaying MODuLATIOn.

  • Page 20: User Menu

    STBY FunCTIOn SET AT OFF (FACTORY SETTIng) If the STBY function is not active (OFF), if the stove reaches the room temperature set, it will go to minimum, modulating and displaying MODuLATIOn. When the room temperature is lower by 2°C than the setting, the stove will start to work again at the power set on the display, showing WORK.

  • Page 21: V1- Fan

    Follow the procedure on the display to perform this adjustment: FiRsT iGNiTiON COuLD EvEN FaiL as THE auGER is EMpTy aND is NOT aLWays abLE TO LOaD Press key 7 for a few seconds, until SET CLOCK appears. Š THE buRN pOT WiTH THE REquiRED aMOuNT Press key 2 several times to reach Š...

  • Page 22: Keys Locked

    kEys LOCkED The function allows to lock the display keys (like mobile phones). Follow these instructions to activate key locking: Š Press key 7 for a few seconds, until the text SET CLOCK APPEARS. Š Press key 2 several times to reach SET uSER. Š...

  • Page 23: Programming Example

    pROGRaMMiNG ExaMpLE Let's suppose that the weekly Programmer function is to be used and 4 time slots are to be used in the following way: - 1st time slot: from 08:00 to 12:00 every day of the week, with room temperature at 19°C, excluding saturday and sunday - 2nd time slot: from 15:00 to 22:00 only on saturday and sunday, with room temperature at 21°C COnTROLS PROCEDuRE: 1ST TIME SLOT SWITCh-OFF...

  • Page 24: Cleaning And Maintenance

    cLeanIng anD MaIntenance aLwaYS foLLow the InStructIonS In MaxIMuM SafetY conDItIonS! Š Make sue the power cable is unplugged since the generator could be programmed to start. Š That the generator is cold in its entirety. Š The ashes are completely cold. Š...
  • Page 25 Open the door - Clean the glass with a damp cloth Never spray the detergent or any other liquid used for cleaning directly on the ceramic glass cLeanIng the burn pot anD coMbuStIon chaMber 1. Vacuum the residues in the burn pot 2.

  • Page 26: Ash Drawer

    everY 3/4 DaYS - weekLY aSh Drawer Every 3-4 days check the ash drawer and empty it at least one/twice a week. If there is a lower door, open/remove it. Take out the removable ash drawer and empty it in a special container. Vacuum the area underneath the removable ash drawer.
  • Page 27 ENGLISH...

  • Page 28: Routine Maintenance Carried Out By Authorised Technicians

    routIne MaIntenance carrIeD out bY authorISeD technIcIanS routine maintenance must be performed at least once a year. As the generator uses pellets as solid fuel, it needs an annual routine maintenance interval that needs to be performed by an authorised technician by only using original spare parts.

  • Page 29: Displays

    Displays Display Reason solution Stove off staRt The start-up phase is in progress pellet feeDing The feeding of the pellet during the ignition phase is in progress ignition The ignition phase is in progress BuRning The start-up phase is in progress opeRant The normal work phase is in progress MoDulation...

  • Page 30: Alarms

    alaRMs explanation solution Display On: indicates the presence of an alarm Off: indicates the absence of alarms Flashing: indicates the deactivation of the depression sensor. Indicates the presence of an alarm. The alarm can be reset by pressing key 1 for 3 seconds only if the fumes motor has stopped and if 15 minutes have passed from displaying the same alarm.

  • Page 31: Guarantee Terms

    Extraflame S.p.A. cannot be held liable for injury or damage which may - either directly or indirectly - be caused to persons, animals and property ensuing from failure to observe all the instructions provided in the relevant instruction manual and the warnings regarding installation, use and maintenance of the product, that can also be downloaded on the website.
  • Page 32 AddITIONAL wARNINGs Š Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator. Š Do not use the product as a ladder or supporting structure. Š Do not place laundry on the product to dry it. Any clothes-horse or similar objects must be kept at due distance from the product. Danger of fire or damage to the coating.
  • Page 33 ENGLISH...
  • Page 34 ENGLISH...
  • Page 35 ENGLISH...
  • Page 36 Extraflame S.p.A. Via Dell’Artigianato, 12 36030 - MONTECCHIO PRECALCINO (VI) - ITALY   +39.0445.865911 -  +39.0445.865912 -  info@extraflame.it - www.lanordica-extraflame.com MADE ITALY design & production TO FIND THE SERVICE CENTRE NEAREST TO YOU CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM...
