- Page 1 pellet stoves UseR MANUAl IC mInI, mInI Crystal, p80 eNGlIsH/INGlese...
- Page 2 ENGLISH...
-
Page 3: Table Of Contents
............................................11 Fumes eXhaust system product requIrements ..............................12 combustIon products outlet quota ..................................12 technIcal InstallatIon documentatIon ................................13 coMfort Mini/p80/Mini cryStaL uSed inStaLLation ......................14 assembly wIth slIdInG base ......................................14 pedeStaL aSSeMbLy (optionaL) ..............................15 front peLLet feedinG kit (optionaL) ............................16 air circuLation pipeS .................................. -
Page 4: English
Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner or user, or if transferred to another place. If it is damaged or lost, request another copy from the area technician. -
Page 5: Devices
devices TeRMs ANd deFiNiTioNs (in the relevant models) Aeration: Air renewal is required both for the disposal of the combustion products, and to prevent mixtures with a door micro switch: With the door open, the operation of the hazardous content of non-combusted gases. burn pot cleaning system is blocked closed hearth appliance: Appliance designed for operation with closed combustion chamber. -
Page 6: General
FUNcTioNAl oPeRATioNs diAgRAM State of the art installation and proper system operation include a series of activities: 1. Preliminary activities: Š Verification of the suitability of the power of the heat generator based on the characteristics of the system Š verification of the suitability of the installation site, Š... -
Page 7: Installation
iNsTAllATioN Installation in premises with fire hazards is forbidden. Installation in residential premises (except for sealed operation appliances) is also forbidden: Š in which there are liquid fuel-operated appliances with continuous or intermittent operation, which draw the combustion air in the room in which they are installed, or Š... -
Page 8: Fumes Exhaust System
veNTilATioN ANd AeRATioN oF The iNsTAllATioN PReMises Ventilation is deemed sufficient when the room is equipped with air inlets according to the table: Air inlet See figure 2 Percentage of the net opening section with Minimum net opening value of Appliance categories Reference standard respect to the appliance fumes... -
Page 9: Smoke Duct
Š nominal diameter; Š distance from combustible materials, indicated in millimetres, followed by the arrow and flame symbol; Š installer data and date of installation. Every time one must cross combustible materials, the following indications must be complied with: sYMbol descRiPTioN qUoTA[MM] Minimum distance of combustible materials from the intrados of the framework/floor/wall... - Page 10 Š counter-slope sections are not allowed; Š the smoke ducts must have, along their entire length, a diameter that is no less than that of the attachment of the appliance exhaust pipe; any section changes are allowed only on the inlet to the chimney; Š...
-
Page 11: Chimney
exAMPles oF coRRecT coNNecTioN To The chiMNeY Protection from rain Protection from rain and wind and wind Steel plate, airtight Max 3 mt 3 - 5% Insulated "T" fitting with inspection plug "T" fitting with "T" fitting with inspection plug inspection plug it is mandatory to use airtight pipes. -
Page 12: Fumes Exhaust System Product Requirements
coMbUsTioN PRodUcTs oUTleT qUoTA The outlet quota is determined by measuring the minimum height between the roof covering and the lower point of the fumes expulsion section into the atmosphere; this quota must be outside the reflux area and at an adequate distance from obstacles which hinder or make the expulsion of the combustion products difficult or from openings or accessible areas. -
Page 13: Technical Installation Documentation
coverings and finishings The coverings and finishings must only be applied after having verified the proper operation of the appliance according to the indicated modalities TechNicAl iNsTAllATioN docUMeNTATioN When installation is complete, the installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);... -
Page 14: Comfort Mini/P80/Mini Crystal Used Installation
COMFORT MINI/p80/MINI CRYSTAL USED INSTALLATION The insert is supplied with an iron sliding base that allows to install it in a pre-existing flue. This sliding base allows the easy extraction of the insert both for pellet feeding inside the feed-box and for any maintenance or cleaning at the end of the season. -
Page 15: Pedestal Assembly (Optional)
pEDESTAL ASSEMBLY (OpTIONAL) Position the base in the desired point and use the feet to adjust the desired height (the bolts are positioned in the four external sides of the pedestal in the lower part). Envision a current socket on the rear of the pedestal so that the plug is accessible once installation is completed. Fix the pedestal to the floor using strong steel plugs with a diameter of 8 mm. -
Page 16: Front Pellet Feeding Kit (Optional)
(operation that requires machine switch-off ). Further information on the accessories is available on the website: www.extraflame.it/support, in the category "accessories". AIR CIRCULATION pIpES It is necessary to create air recirculation inside the structure that covers the insert for correct functioning. This prevents the appliance from over-heating. - Page 17 Minimum 5 cm Minimum 5 cm ThE INSERT MUST LIE AT LEAST 1 CM ABOvE ThE FIRE SURFACE IN COvERINg MARBLE. 5 cm 5 cm 5 cm 5 cm 5 cm 5 cm It is just as important to guarantee the minimum distance of 5 cm on both sides as shown in the figures above. Reference A Š...
-
Page 18: Insert Extraction
For correct functioning of the insert, during construction of the flue the measurements between the insert and internal walls of the flue must be respected (figure below). From the clearance measurements of the stove given in the technical features, it is necessary to consider at least 50 mm of air in the upper part and on the 2 sides. -
Page 19: Mounting The Frames
Š EN pLUS - UNI EN 16961 - 2 classe A1 - A2 Š Ö-NORM M 7135 Š DIN pLUS 51731 Extraflame recommends the use of pellets with a 6 mm diameter with its products. Open the tank lid and load the pellets using a scoop. -
Page 20: The Remote Control
THE REMOTE CONTROL The display changes in relation to the status of the stove or the menu shown. In the rest status the display shows the following items: DispLay TiME: The current time is stated. The regulation of the same is found inside the weekly programmer (see SET CLOCK menu). -
Page 21: General Features
GENERaL FEaTuREs The user interface is provided with a backlit LCD display. The backlighting lasts about 4 seconds. Display backlighting time can be set. Press keys 1 and 7 simultaneously to access. After having accessed, use keys 1 or 2 to select the time in seconds from 0 to 9. Direct controls for ignition/switch-off, power change, room temperature. -
Page 22: Menu Structure
MENu sTRuCTuRE kEys 1 & 2: to set - enable data and parameters. kEy 3: to confirm the parameter and exit. kEy 4: to adjust the thermostat setting kEy 5: to adjust the power setting kEy 6: to go back in the menu. kEy 7: to go forwards in the menu. -
Page 23: Commissioning Settings
COMMissiONiNG sETTiNGs Once the power cable at the back of the stove has been connected, move the switch to (I). The stove switch powers the stove board. The stove remains off and a first screen appears on the panel reading OFF . MaiNs FREquENCy 50/ 60Hz In the event the stove is installed in a country with 60hz frequency, the stove will display "frequenza rete errata"... -
Page 24: Adjusting Language
aDjusTiNG LaNGuaGE COnTROLS PROCEDuRE Press key 7 for a few seconds, until SET CLOCK appears. Š until set Language appears. Press key 2 twice Š Confirm using key 7. Š Select the language using key 1 or 2. Š Press key 3 several times to confirm and exit the menu. Š... -
Page 25: Functioning And Logic
FuNCTiONiNG aND LOGiC iGNiTiON Once the points listed previously have been checked, press key 1 for three seconds to ignite the stove. 15 minutes 20:00 are available for the ignition phase. After 21° ignition and having reached the control temperature, the stove interrupts the ignition phase and passes to STARTIng. -
Page 26: Room Probe And Stand By Function
ROOM pRObE aND sTaND by FuNCTiON: The STBY function is used if immediate stove switch-off is required when the set temperature has been reached. in the factory the sTby function is always set at OFF (sTby indicator light off) sTby FuNCTiON sET aT OFF (FACTORY SETTIng) If the STBY function is not active (OFF), if the stove reaches the room temperature set, it will go to minimum, modulating and displaying mODuLATIOn. -
Page 27: Installation And Activation Of Room Probe (Optional)
STBY FunCTIOn SET AT OFF (FACTORY SETTIng) If the STBY function is not active (OFF), if the stove reaches the room temperature set, it will go to minimum, modulating and displaying mODuLATIOn. When the room temperature is lower by 2°C than the setting, the stove will start to work again at the power set on the display, showing WORK. -
Page 28: V1- Fan
Follow the procedure on the display to perform this adjustment: FiRsT iGNiTiON COuLD EvEN FaiL as THE auGER Press key 7 for a few seconds, until SET CLOCK appears. Š is EMpTy aND is NOT aLWays abLE TO LOaD Press key 2 several times to reach Š... -
Page 29: Keys Locked
kEys LOCkED The function allows to lock the display keys (like mobile phones). Follow these instructions to activate key locking: Š Press key 7 for a few seconds, until the text SET CLOCK APPEARS. Š Press key 2 several times to reach SET uSER. Š... -
Page 30: Programming Example
pROGRaMMiNG ExaMpLE Let's suppose that the weekly Programmer function is to be used and 4 time slots are to be used in the following way: - 1st time slot: from 08:00 to 12:00 every day of the week, with room temperature at 19°C, excluding saturday and sunday - 2nd time slot: from 15:00 to 22:00 only on saturday and sunday, with room temperature at 21°C COnTROLS PROCEDuRE:... -
Page 31: Maintenance
MaIntenance MaIntenance warnIngS Inspection and maintenance operations must be carried out by specialised technicians who are aware of the directions reported in this manual. Before carrying out any work, make sure that: Š The power cable's plug has been pulled out, as the stove might have been programmed to turn on. Š... - Page 32 cLeanIng the burn pot anD coMbuStIon chaMber 1. Vacuum the residues in the burn pot 2. Take out the burn pot from the designated compartment; 3. Vacuum the ash from the burn pot's seat and the combustion chamber (3.1) 4. Use the special poker supplied to clear the holes in the burn pot. 5.
- Page 33 everY 3/4 DaYS - weekLY aSh Drawer Every 3-4 days check the ash drawer and empty it at least one/twice a week. If there is a lower door, open/remove it. Take out the removable ash drawer and empty it in a special container. Vacuum the area underneath the removable ash drawer.
- Page 34 cLeanIng the Lower SuMp (IF there IS one) Some stove models have an inspection sump behind the ash drawer or underneath the combustion chamber. In this case, just open, remove the clamping screws and vacuum the ash inside. ENGLISH...
-
Page 35: Routine Maintenance
routIne MaIntenance In order to guarantee proper functioning and safety of the device, the operations indicated below must be performed every season or more often when necessary. Door, aSh Drawer anD burn pot gaSketS The gaskets ensure the tightness of the stove and its consequent proper operation. They must be checked periodically: in the event they are worn or damaged they must be replaced immediately. -
Page 36: Displays
Displays Display Reason solution Stove off staRt The start phase is in progress pellet feeDing The feeding of the pellet during the ignition phase is in progress ignition The ignition phase is in progress staRt-up The start phase is in progress WoRk The normal work phase is in progress MoDulation... -
Page 37: Alarms
alaRMs Display explanation solution On: indicates the presence of an alarm Off: indicates the absence of alarms Flashing: indicates the deactivation of the depression sensor. Indicates the presence of an alarm. The alarm can be reset by pressing key 3 for 3 seconds only if the fumes motor has stopped and if 15 minutes have passed from displaying the same alarm. - Page 38 ENGLISH...
- Page 39 ENGLISH...
- Page 40 Extraflame S.p.A. Via Dell’Artigianato, 12 36030 - MONTECCHIO PRECALCINO (VI) - ITALY +39.0445.865911 - +39.0445.865912 - info@extraflame.it - www.lanordica-extraflame.com The Manufacturer reserves the right to vary the features and data shown in this booklet at any time and without prior notice, in order to improve its products.
