SMC Networks MY1B-Z1 Series Operation Manual

Mechanically jointed rodless cylinder basic type
Hide thumbs

Advertisement

Quick Links

Download this manual
Doc. no.DOC1120098
PRODUCT NAME
Mechanically jointed rodless cylinder
Basic type
MODEL / Series / Product Number
MY1B-*Z1 Series

Advertisement

loading
Need help?

Need help?

Do you have a question about the MY1B-Z1 Series and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks MY1B-Z1 Series

Summary of Contents for SMC Networks MY1B-Z1 Series

  • Page 1 Doc. no.DOC1120098 PRODUCT NAME Mechanically jointed rodless cylinder Basic type MODEL / Series / Product Number MY1B-*Z1 Series...
  • Page 2 Contents Safety Instructions --------------------------------P. 2 1. Product Specifications 1.1 Specifications -----------------------------P. 4 2. Operation and Mounting 2.1 Air Supply ---------------------------------P. 6 2.2 Operating Environment ----------------P. 6 2.3 Design -------------------------------------P. 7 2.4 Mounting and Installation -------------P. 8 2.5 Piping --------------------------------------P. 11 2.6 Speed Control ---------------------------P.
  • Page 3 Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
  • Page 5 1. Product Specifications 1-1 Specifications 1-1-1. MY1B-Z1 series ø25～ø40 Fluid Proof pressure 1.2 MPa Max. operating pressure 0.8 MPa Min. operating pressure 0.1 MPa Ambient and fluid +5 to +60 temperature (No freezing) Lubrication Not required (non-lube) 2700 or less +1.8 0 ㎜...
  • Page 6 Caution 1. Air leakage due to removal of the seal belt Mechanical joint type rodless cylinders may have a temporary external air leakage in some operating conditions due to the product construction when negative pressure is generated inside the cylinder with external force, inertial force, or etc.
  • Page 7 2. Operation and Mounting 2-1. Air supply The compressed air supplied to the cylinder should be filtered by SMC AF series air filter and regulated to the specified set pressure by SMC AR series regulator. Warning 1. Use clean air. Do not use compressed air that contains chemicals, synthetic oils including organic solvents, salts or corrosive gases etc., as this can cause damage or malfunction.
  • Page 8 7. Avoid storing the product in high temperature and/or humid conditions. Rust may be generated or the sealing parts may be deteriorated in such an environment. 8. This product is not designed for use in clean rooms. 9. Do not mount the product in locations where it is exposed to radiant heat. 10.
  • Page 9 11. Do not disassemble the product or make any modifications, including additional machining. Do not disassemble the product or make any modifications, including additional machining. Doing so may cause human injury and/or an accident. 12. Refer to the Auto Switches Precautions for using with an auto switch. 13.
  • Page 10 2-4-2. Mounting - Two mounting methods are available for this cylinder: Choose the mounting method according to the mounting surface and the mounting place conditions. ◎ ◎ Fig. 1: Holding the product from the top Fig. 2: Holding the product from the bottom (Head cover at both ends) (Head cover) - At least 5mm of both ends of the cylinder tube have to contact with the attachment point.
  • Page 11 Fig. 7 - Refer to the figures below for how to install the holding bolt for the floating bracket. Fig. 8 Table-1. Tightening Torque for Holding Bolts Part no. Tightening torque[N･m] MY-J25 MY-J32 MY-J40 - When using the product that has a stroke that exceeds the stroke fine adjustment range, use an intermediate fixing spacer.
  • Page 12 Warning 1. Secure all the mounting screws firmly to mount the slide table. If not, the slide table and/or the mounting screws may be damaged, and the workpiece may drop. 2. Carefully lift the cylinder to avoid injuries to hands and fingers. Use crane for raising heavy cylinders with large port or long stroke.
  • Page 13 Table-3.Plug part number (order number) Port size 1/16 TB00058 CYP025-08B29449A TB00057 TB00043 CYP040-08B29451A TB00056 TB00003 - Refer to Table 4 below for the dimensions of mating parts when bottom ported. Table-4. Mating part dimensions (mm) Head cover Bore size ø25 ø32 ø40 O-ring...
  • Page 14 Caution 1. Use a speed controller to adjust the cylinder drive speed, gradually increasing from a low speed to the desired speed setting. 2. Performance using at constant speed Mechanical joint type rodless cylinder has a larger fluctuation in speed compared to the rod air cylinder due to its construction.
  • Page 15 Warning 1. Do not operate the product when the cushion capacity that exceeds the allowable value. Operation while exceeding the allowable cushion capacity may damage the cylinder and may cause injury or damage to equipment. If operation requires a larger cushion capacity, install an external absorber to prevent impact to the cylinder body.
  • Page 16 5. The cylinder, eguipment and/or workpieces might be destroyed if the table collides the end of the stroke without being buffered properly by the shock absorber. See below for the number of cycles that are possible within the catalog usage range (model selection graph range), and check the operating conditions periodically, adjusting or replacing the shock absorber when necessary.
  • Page 17 2-9-1. Using switch spacer 1. Hold the switch spacer then push it into the groove. (Fig. 15) 2. Ensure that the switch spacer fits in the correct position. 3. After checking the detecting position, tighten the mounting screw (M2.5) to fix the auto switch. Fig.15 Note) For the tightening of the mounting screws, use a precision screwdriver with a handle diameter of approximately 5 to 6 mm.
  • Page 18 Caution 1. For the handling of the auto switch, refer to the Operation Manual of the auto switch. 2. Do not let objects drop onto the product or apply with an excessive impact to the product when handling. 3. Avoid wiring that applies repeated bending stress and/or tensile force on the lead wire.
  • Page 19 4. Basic Circuit for Cylinder Operation The basic circuit for operating the product with air filter, regulator, solenoid valve and speed controller is shown in the following figure. Fig. 17 5. Maintenance 5-1. Inspections 5-1-1. Daily Check 1) Smoothness of the operation 2) Changes in piston speed and cycle time 3) Smooth movement of the slide table for the entire stroke 5-1-2.
  • Page 20 Refer to Table 9 for disassembly and assembly procedures for each replacement part. Table-9. Disassembly and assembly procedure Replacement Parts Disassembly Procedure Assembly Procedure Dust seal band ①～③ ⑬～⑲ Seal belt ①～⑦ ③～⑲ Seal kit ①～⑧ ①～⑲ Disassembly Procedure ①Remove the two thin head screws on head plates, and remove the head plate and the belt clamp. (Fig.
  • Page 21 ④Remove the three hexagon socket head bolts that secure the head cover, and then remove the head cover. (Fig. 21) Hexagon socket head cap screw Head cover Cushion boss Slide member assembly Seal belt Fig.21 ⑤Pull out the cushion boss from the cylinder tube. ⑥Pull out the slide member assembly from the cylinder tube.
  • Page 22 b) Assembly Procedure ①Apply grease to the new seals. ②Mount the seals. Note that piston seals, cushion seals and scrapers have orientations for mounting .(Fig. 23) Mount with the lip Facing outside Mount with the ribs on the upper side Arrow viewing A Piston seal Mount with the lip...
  • Page 23 ④Insert the seal belt into the slide member assembly and place the long side of seal belt inside of cylinder tube. (Fig.24) Fit the seal belt Seal belt Slide member assembly Fig.24 ⑤Mount the seal belt to the opening of cylinder tube end surface to which the slide member assembly is inserted.
  • Page 24 ⑭Mount the dust seal band so that the end of dust seal band is in a mounting position midway between the M3 thread and the projection on the top surface of the head cover. Dust seal band：Install so that the end face is middle between the head cover protrusion and the screw hole.
  • Page 25 6. Troubleshooting Failure Major causes Countermeasures Operation is not Misalignment of the Realign workpiece and cylinder smooth. workpiece and Confirm that the cylinder operates smoothly without air cylinder axis, or the supplied to the cylinder. Consider using a Floating Bracket The speed or guide axis of the (available from SMC) or connecting pipes using a floating...
  • Page 26 Failure Major causes Countermeasures Air leak Air leak in the MY cylinders have a special seal structure that uses a seal belt, so if the air leakage amount is as below, it is a good standard value product. Allowable air leakage Low pressure (0.1MPa): 300cm³/min(ANR) or less High pressure (0.8MPa): 425cm³/min(ANR) or less Damage to the...
  • Page 27 Revision history Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
