Doc no. 1098381

PRODUCT NAME

Magnet gripper

MODEL / Series / Product Number

MHM-32(TF)D1-X7776

Need help?

Do you have a question about the MHM-32D1-X7776 and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Networks MHM-32D1-X7776

Page 1 Doc no. 1098381 PRODUCT NAME Magnet gripper MODEL / Series / Product Number MHM-32(TF)D1-X7776...
Page 2 Contents Product outline Attracts and holds heavy objects with a magnet Transfers steel plates without a vacuum Holding force (Attraction force) can be adjusted. Safety Instructions ............................3 1.Specifications ............................... 5 2.Installation ..............................5 2-1.Design ..............................5 2-2 Mounting ..............................6 2-3.Environment ............................
Page 3 Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing business. Use in non-manufacturing business is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
Page 5 1.Specifications Model MHM-32(TF)D1-X7776 MHM-32D1-X7776 Rc1/8 Pilot port MHM-32TFD1-X7776 G1/8 Fluid Action 3 positions Operating pressure 0.35～0.6MPa Proof pressure 0.9MPa Ambient and fluid temperatures -10～60℃(No freezing) Workpiece thickenss:2mm 250N Holding force*1 Workpiece thickeness:6mm 500N Residual holding force 0.3N or less Lubrication...
Page 6 Caution 1. If pressure is applied to the external magnet gripper parts, there is a possibility that air will get inside the cylinder from the rod seal section. ( Example : inside a chamber, etc.) 2. Keep away from objects which are influenced by magnets. As the body magnets are built-in, do not allow close contact with magnetic disks, magnetic cards, or magnetic tapes.
Page 7 Lateral mounting Tightening Max screw-in torque Applicable bolt depth (N･m) L(mm) M5x0.8 4. The pressing load applied to the workpiece should be smaller than the allowable pressing load. Allowable pressing load(N) 5. Do not apply impact load to the center of the magnetic attraction surface. Otherwise, it may result in a breakage or malfunction.
Page 8 2-3.Environment Warning 1. Do not use in an atmosphere containing corrosive gases, chemicals, sea water, water, water steam, or where there is direct contact with any of these. Refer to each construction drawing for information on the materials of air grippers. 2.
Page 9 2-5.Piping 1. Preparation before piping Before piping is connected, it should be thoroughly blown out with air (flushing) or washed to remove chips, cutting oil, and other debris from inside the pipe. 2. Winding of sealant tape When screwing piping or fittings into ports, ensure that chips from the pipe threads or sealing material do not enter the piping.
Page 10 2-7.Auto Switch Mounting Auto Switch Mounting Position Setting 1) Detect the magnet position for 2)Detect the magnet position for Detection example workpiece holding. workpiece release. Position to be detected Head side Piston Piston Magnet Magnet Workpiece Workpiece Attraction side Step 1) Hold the workpiece. Step 1) Release the workpiece.
Page 11 At C3 in the waveform chart, the magnet position cannot be detected. C1: Detection area of the magnet position for workpiece release C2: Detection area of the magnet position for workpiece holding C3: Area where the magnet position cannot be Detected Magnet position Attraction...
Page 12 Auto switch Mounting position Table below shows the mounting positions and dimensions of the auto switch. Some auto switches may protrude from the end surface of the body. Refer to the table below for the space. D-M9□V D-M9□ Holding D-M9□WV D-M9□W D-P3DWA□...
Page 13 Auto Switch Mounting Method 1.Auto switch mounting tool When tightening the auto switch mounting screw(included with the auto switch), use a screwdriver with a handle diameter of about 5 to 6 mm. Tightening Torque for Auto Switch Mounting screws(n･m) Auto switch model Tightening torque D-M9□(V) D-M9□W(V)
Page 14 2.keep a gap wider than the value listed in the table when arranging the magnet grippers side by side or when placing the magnet grippers close to magnetic objects such as iron. Required Gap(mm) Auto switch connections and Examples Sink Input Specifications Source Input Specifications Connect according to the applicable PLC input specifications, as the connection method will vary depending on the PLC input specifications.
Page 15 When using solid state auto switches, ensure the application is set up so the signals for the first 50 ms are invalid. Depending on the operating environment, the product may not operate properly. 2-8.Other 1)Refer to the Fittings and Tubing Precautions (Web catalog) for handling One-touch fittings. 2) Ensure the mounting bracket or peripheral parts are not protruded from the magnetic attraction surface.
Page 16 Caution 3) When multiple magnet grippers are used side by side, mount them so that the attraction surfaces are not uneven. Otherwise, adequate holding force is not available, and the workpiece may slip or fall. 3.How to use 3-1.Holding force Adjustment ①Secure the stopper with a ➁With the workpiece ③Secure the stopper with a...
Page 17 Tightening Holding force Width across flats torque for adjustment range Adjustment bolt Stopper nut (N・m) 0～24 Caution 1. Do not apply external forces to the holding force adjusting part other than for the purpose of Holding force holding force adjustment. adjusting part Do not fix the holding force adjusting part to the outside or attempt to rotate it.
Page 18 3-3.Example of operating procedure Examples of operation from single workpiece pick-up to transfer are shown below. < STEP 1 > Standby (Release) Valve 1 : OFF、Valve 2 : ON < STEP 2 > Pick Workpiece up (adjustable holding force) Valve 1 : ON、 Valve 2 : OFF <...
Page 19 4.How to order...
Page 20 5.Maintenance 5-1.Maintenance or inspection Warning 1. Perform maintenance and inspection according to the procedures indicated in the operation manual. If handled improperly, human injury and/or malfunction or damage of machinery and equipment may occur. 2. Maintenance work If handled improperly, compressed air can be dangerous. Assembly, handling, repair, and element replacement of pneumatic systems should be performed by a knowledgeable and experienced person.
Page 21 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
