Advantech UNO-2372G V2 Startup Manual

UNO-2372G V2 Intel® Celeron J6412 Edge
Intelligent Gateway for Automation
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. UNO-2372G V2
2. 2-pin connector for power wiring
3. 1 x SATA cable
4. 4 x PCS screws for wall mounting bracket
5. Startup manual
6. China RoHs sheet
7. Warranty card
If any of these items are missing or damaged, please contact
your distributor or sales representative immediately.
Note:
Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: get.adobe.
com/reader (Acrobat is a trademark of Adobe)
Caution: DANGER OF EXPLOSION IF BATTERY IS IN-
CORRECTLY REPLACED. REPLACE ONLY WITH
THE SAME OR EQUIVALENT TYPE RECOM-
MENDED BY THE MANUFACTURER, DISCARD
USED BATTERIES ACCORDING TO THE MANU-
FACTURER'S INSTRUCTIONS.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for UNO-2372G V2 at:
Register your products on our website and get 2
months extra warranty for Free at:
http://www.register.advantech.com
This manual is for the UNO-2372G V2.
Part No. 2041237210
Packing List (Cont.)
Attention: DANGER D'EXPLOSION SI LA BATTERIE EST
Specifications
Processor System
• Intel® Celeron J6412 4 Core, up to 2.60 GHz 6W
Memory
• Built in 8GB DDR4 3200MHz, supports up to 32GB (Single
socket)
Graphics
• Intel® UHD Graphics
Serial Ports
• 4 x RS-232/422/485 (50 to 115.2Kbps)
Ethernet
• 2 x RJ45, 10/100/1000 Mbps IEEE 802.3u
Storage
• 1 x M.2 M key 2242 (PCIex2/SATA signal)
• 1 x 2.5" SATA SSD
Expansion
• 1 x Full size mPCIe slot (PCIe/USB2.0 Signal)
• 1 x M.2 B key 3042/3052 (USB3.0 signal)
• 1 x Nano SIM card slot
External I/O
• Display: 1 x DP, 1 x HDMI
• USB: 3 x USB 3.2, 1 x USB 2.0
Power Requirement
• Power type: ATX
• Power Input Voltage: 10-36 V
• Power Connector: 1 x 2-pin Terminal block
• Power Input: 10-36 V
This product is intended to be supplied by a UL certified
power supply or UL certified DC source rated 10-36 Vdc 5 A
minimum, TMA 50 °C minimum (Safety certificate operation
temperature 40 °C), if you need further assistance, please
contact Advantech for further information.
1st Edition
May 2025
INEXACTEMENT REMPLACÉE. REMPLACEZ
SEULEMENT AVEC LA MÊME CHOSE OU LE
TYPE ÉQUIVALENT RECOMMANDÉ PAR LE
FABRICANT, JETTENT LES BATTERIES UTILI-
SÉES INSTRUCTIONS DE S SELON FABRICANT
DES'.
DC
5.1 A - 1.42 A
DC
UNO-2372G V2 Startup Manual 1
