Channel Commands

Use channel commands to program pan/tilt, servomotor positional, servomotor speed, and motor
mode functions.

Pan/tilt functions

Pan/Tilt Functions
Channel
31
32
35
36
40
41
42
43
44
45
46
47
Servomotor mode lens functions
Servomotor Mode Lens Functions
Channel
1
3
4
5
7
8
10
12
13
14
16
17
18
20
21
22
24
25
AXB-PT15 PosiTrack Camera Controller
State Function
On Pan right at current speed
On Tilt down at current speed
On Pan left at current speed
On Tilt up at current speed
On Pan right at maximum speed (100%)
On Pan left at maximum speed (100%)
On Tilt down at maximum speed (100%)
On Tilt up at maximum speed (100%)
On Pan right at medium speed (50%)
On Pan left at medium speed (50%)
On Tilt down at medium speed (50%)
On Tilt up at medium speed (50%)
State Function
On Iris (+) at current rate
On Zoom (+) at current rate (increases output voltage)
On Focus (+) at current rate
On Iris (-) at current rate
On Zoom (-) at current rate (decreases output voltage)
On Focus (-) at current rate
On Iris (+) at maximum speed
On Zoom (+) at maximum speed (output minimum voltage)
On Focus (+) at maximum speed
On Iris (-) at maximum speed
On Zoom (-) at maximum speed (output maximum voltage)
On Focus (-) at maximum speed
On Iris (+) at 50% speed
On Zoom (+) at 50% speed
On Focus (+) at 50% speed
On Iris (-) at 50% speed
On Zoom (-) at 50% speed
On Focus (-) at 50% speed
