- Page 1 HS290 User Manual V 1.1 Gebrauchsanweisung Dare to fly.Soar to live. (833)766-4733 usa@holystone.com (USA) eu@holystone.com (EU) au@holystone.com(AU) www.holystone.com ca@holystone.com (CA) jp@ holystone.com (JP)
-
Page 2: Table Of Contents
CONTENTS Operation Guide Product Profile English 01-48 Package Contents Battery Preparation Flight Diagram of the Drone Pre-Flight Preparations Diagram of the Transmitter Pre-Flight Checklist Deutsch 49-94 Drone Functions Appendix 95-137 Compliance Information Flight Functions Specifications Attitude Adjustment Contact Us Stabilization Functions Troubleshooting APP Operation Instruction... -
Page 3: Recommended Steps
Reading Guidance Access Tutorial Videos To ensure you're using the product safely and correctly, scan the QR code below to view our tutorial videos. Icon “ ” essential precautions. “ ” tips for operation and usage. Recommended Steps Our product offers both tutorial videos and the following resources: Download the HS FPV App Disclaimer and Safety Guidelines Simply scan the QR code below. -
Page 4: Package Contents
PRODUCT PROFILE PRODUCT PROFILE 1.1 Package Contents >> 1.2 Diagram of the Drone >> Drone Propeller A Propeller B Camera Power Switch: long press Propeller B Propeller A Optical Flow Positioning Lens Drone Battery Drone Transmitter Propellers USB Charging Cable Indicator Drone Battery Screwdriver... -
Page 5: Diagram Of The Transmitter
PRODUCT PROFILE PRODUCT PROFILE 1.3 Diagram of the Transmitter >> The Transmitter Front： Power Switch: Phone Holder Left Joystick long press Top： Speed Switch: short press Headless Mode: Trimmer: long press long press Right Joystick Takeoff/Landing: Emergency Stop: short press long press Camera Angle Adjustment Take Photo:... - Page 6 PRODUCT PROFILE PRODUCT PROFILE 1.3 Diagram of the Transmitter >> Joystick Mode MODE 1 : To enter MODE 1, turn on the transmitter while holding the button. (Please do not release the button until the transmitter is powered on.) MODE 2 : (The default setting.) Ascend Forward...
-
Page 7: Battery Preparation
OPERATION GUIDE OPERATION GUIDE 2.1 Battery Preparation >> 2.1 Battery Preparation >> Drone Battery Changing Transmitter Batteries USB Adapter (5V/2A) Power Bank Remove the battery from the drone and connect it to a USB charging cable. Plug the USB charging cable into a USB charging port on a power bank or a USB adapter (5V/2A). -
Page 8: Installation
OPERATION GUIDE OPERATION GUIDE 2.2 Pre-Flight Preparations >> 2.2 Pre-Flight Preparations >> Arms Phone Holder Propellers Removal: Installation: HEAD The drone will not fly unless the correct For propeller removal, use a screwdriver (provid - propeller is installed on the correct motor ed) to rotate the screws counter-clockwise and shaft. -
Page 9: Pre-Flight Checklist
OPERATION GUIDE OPERATION GUIDE 2.2 Pre-Flight Preparations >> 2.3 Pre-Flight Checklist >> Drone Battery Installation: Removal: Make sure the transmitter, the Make sure that the camera is Make sure that there is nothing mobile phone and the drone clean. obstructing the motors. battery are fully charged. -
Page 10: Auto-Pairing
OPERATION GUIDE OPERATION GUIDE 2.4 Flight >> Pairing Turning on the Transmitter · All of the operations shown in this manual are demonstrated using MODE 2. Long press the power switch on the transmit - · You must keep your drone in visual line of sight all the time. If you can't see it, ter to turn it on;... - Page 11 OPERATION GUIDE OPERATION GUIDE 2.4 Flight >> Wi-Fi Connection Make sure the pairing has finished before going to the Wi-Fi settings on your phone. · Connecting your phone to the drone's Wi-Fi may take some time. Please remain patient and wait for the connection to be established successfully. ·...
- Page 12 OPERATION GUIDE OPERATION GUIDE 2.4 Flight >> 2.4 Flight >> Gyro-Calibration Unlocking the Motors Make sure to place the drone on a level surface before calibrating the gyro. Simulta- neously push the left joystick and the right joystick to the bottom left corner to cali - brate the gyro.
-
Page 13: Drone Functions
OPERATION GUIDE DRONE FUNCTIONS 2.4 Flight >> 3.1 Flight Functions >> Camera Angle Adjustment Takeoff/Landing Remember to unlock the motors before takeoff. 0° -90° Takeoff Short press the button, the drone will take off automatically and hover at 5 ft. Now you can control the drone by using the joysticks. - Page 14 DRONE FUNCTIONS DRONE FUNCTIONS 3.1 Flight Functions >> 3.1 Flight Functions >> Take Photo/Record Video High Speed Rotation Take Photo: Short press the button on the transmitter to take a photo. The transmitter will beep once, signaling that a photo has been taken. Short press the button, the drone will enter the High Speed Rotation mode.
- Page 15 DRONE FUNCTIONS DRONE FUNCTIONS 3.1 Flight Functions >> 3.1 Flight Functions >> Circle Fly 360° Flips 10 ft After you get familiar with all the functions of the drone, you can try this amazing flip mode. When the drone is at least 10 ft from the ground, press down on the Long press the button, the drone will enter the Circle Fly mode.
- Page 16 DRONE FUNCTIONS DRONE FUNCTIONS 3.1 Flight Functions >> 3.1 Flight Functions >> Speed Switch Headless Mode The Headless Mode is a great training tool for beginner pilots. It is also useful when the drone is too far from the pilot (which makes it difficult to tell its orientation).
- Page 17 DRONE FUNCTIONS DRONE FUNCTIONS 3.1 Flight Functions >> Headless Mode * Why is the orientation of the drone important? In normal flying mode, he control of the drone movement can sometimes be counter-intuitive for beginners. For instance, when the drone is in the air with its head pointing to your right, if you push the right joystick forward, the drone will fly to your right, instead of flying forward.
- Page 18 DRONE FUNCTIONS DRONE FUNCTIONS 3.1 Flight Functions >> Emergency Stop After the drone hits the ground, The drone indicator will keep on flashing. Please put the drone on a level surface again, and push the left joystick downward. The drone indicator then turn from flashing to solid, which indicates that you can use the drone now.
-
Page 19: Attitude Adjustment
DRONE FUNCTIONS DRONE FUNCTIONS 3.2 Attitude Adjustment >> Trimming F/B Sideward Trim: Trim adjustments are designed to counter drifts not caused by airflow. If the drone drifts forward, push the right joystick downward. If the drone drifts backward, push the right joystick upward. Initiate Trim Mode: Long press the button. -
Page 20: Stabilization Functions
DRONE FUNCTIONS DRONE FUNCTIONS 3.3 Stabilization Functions >> 3.3 Stabilization Functions >> Altitude-Hold Function Optical Flow Positioning Optical Flow Module The Optical Flow Positioning System consists of a camera module, which acquires the position information of the drone through visual images to ensure precise positioning of the drone. -
Page 21: App Operation Instruction
DRONE FUNCTIONS DRONE FUNCTIONS 3.3 Stabilization Functions >> 3.4 APP Operation Instruction >>... - Page 22 DRONE FUNCTIONS DRONE FUNCTIONS 3.4 APP Operation Instruction >> 3.4 APP Operation Instruction >> Return: Tap to return to APP main screen. Voice Control: Tap to activate the voice control mode for the drone. There are six voice Altitude-Hold Function Optical Flow Positioning One Key Takeooff/Landing: The same feature as the one on transmitter.
-
Page 23: Specifications
Altitude-Hold Function VR Split Screen: This feature requires a VR device (sold separately, not necessarily be of Holy Model: HS290 Weight: 128g/4,5oz Stone brand). Tap to switch to VR mode and mount the phone onto the VR device. The drone cannot be controlled via VR devices. - Page 24 >> 4.2 Contact Us >> TRANSMITTER ： Please do not hesitate to contact us if you need further support. Model: HS290-YK Operating Frequency: 2452-2474MHz Max Flight Distance: 328ft/100m Battery Type: 3 × AAA Battery (not included) (outdoor and unobstructed) Operating Temperature Range: 32° to 104°F (0° to 40°C) usa@holystone.com (America)
-
Page 25: Troubleshooting
APPENDIX APPENDIX 4.3 Troubleshooting >> 4.4 Compliance Information >> FCC Notice ： Issue Suggested Solutions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: Transmitter battery is low. It is recommended to replace the transmitter Lag in the drone's batteries. - Page 26 L'exploitation est autorisée aux deux conditions suivantes: (1) I'appareil ne doit pas produire de brouillage; et We, Xiamen Huoshiquan Import & Export CO.,LTD hereby, declare that the UAS HS290 is of class C0, (2) I'utillsateur de I'appareil doit accepterbrouillage radioélectrique subi meme si le brouillage est and in compliance with the RED Directive 2014/53/EU, the RoHS Directive 2011/65/EU, Toy Directive susceptible d'encompromettre le fonctionnement.
- Page 27 4. If the drone disconnects from the transmitter, the indicator light on the drone will continuously flash. The drone will HS290 is a quadrotor drone. The MTOM of HS290 is 128g, including the propellers, the flight slowly descend at its current position until it lands. During the landing process, the drone cannot be manually controlled.
