Summary of Contents for Holy Stone HS790
- Page 1 HS790 Instructions For Use V 1.0 Dare to fly.Soar to live. usa@holystone.com (USA) eu@holystone.com (EU) +1(833)766-4733 au@holystone.com(AU) ca@holystone.com (CA) www.holystone.com...
-
Page 2: Table Of Contents
CONTENTS Operation Guide Product Profile Package Contents Charging Pre-Flight Checklist Diagram of the Drone Preparing the Transmitter Flight Diagram of the Transmitter Preparing the Drone Appendix Drone Functions Flight Functions Specifications Compliance Information Contact Us Stabilization Functions APP Functions Troubleshooting... -
Page 3: Recommended Steps
Reading Guidance Access Tutorial Videos To ensure you're using the product safely and correctly, scan the QR code below to view our tutorial videos. Icon “ ” essential precautions. “ ” tips for operation and usage. Recommended Steps Download the HS GPS V5 App Our product offers both tutorial videos and the following resources: Simply scan the QR code below. -
Page 4: Package Contents 09 Charging
1.2 Diagram of the Drone >> Drone Propeller A Propeller B Gimbal and Camera Gimbal Cover Drone Battery Propeller B HS790 Instructions For Use V 1.0 Drone Status Indicators Propeller A Optical Flow Positioning Lens usa@holystone.com (USA) eu@holystone.com (EU) +1(833)766-4733 www.holystone.com... - Page 5 PRODUCT PROFILE PRODUCT PROFILE 1.3 Diagram of the Transmitter >> The Transmitter Phone Holder Takeoff/Landing: short press Front： Top： GPS Switch: short press Left Joystick Headless Mode: long press Compass Calibration: long press Connection Cable Return to Home(RTH): short press Right Joystick Speed Switch: short press Power Switch: long press...
- Page 6 PRODUCT PROFILE PRODUCT PROFILE 1.3 Diagram of the Transmitter >> LCD Screen Flight Speed RTH Indicator Takeoff/Landing Indicator Optical Flow Positioning GPS mode Indicator Photo/Record Indicator Indicator Transmitter Signal Strength GPS Signal Strength Headless Mode Drone Battery Level Transmitter Battery Level Flight Distance Flight Height...
- Page 7 PRODUCT PROFILE PRODUCT PROFILE 1.3 Diagram of the Transmitter >> Joystick Mode MODE 1: (Press and hold the takeoff button while powering on the transmitter to switch to Mode 1.) MODE 2: (The default setting, i.e., left joystick as the throttle joystick.) Forward Ascend Forward...
- Page 8 OPERATION GUIDE OPERATION GUIDE 2.1 Charging >> Charging of the Drone Battery： Remove the battery from the drone and connect it to a USB charging cable. Plug the USB charging cable into a USB charging port on a power bank or a USB adapter USB Adapter (5-12V/2A, Supports QC &...
-
Page 9: Preparing The Transmitter
OPERATION GUIDE OPERATION GUIDE 2.2 Preparing the Transmitter >> Extend the phone holder. Take the joysticks out of the storage slots and mount them onto the transmitter. Extend the phone holder. Choose the appropriate transmitter adapter cable for your phone (Type-C or Lightning), and connect one end of the adapter cable to the transmitter. -
Page 10: Installation
OPERATION GUIDE OPERATION GUIDE 2.3 Preparing the Drone >> 2.3 Preparing the Drone >> Gimbal Cover TF Card Drone Battery To store your photos and videos, insert a TF Installation: Turn the drone upside down and card (not included) into the slot before Removal: carefully pull the cover outward to *Before installing the battery, please check ... -
Page 11: Pre-Flight Checklist
OPERATION GUIDE OPERATION GUIDE 2.3 Preparing the Drone >> 2.4 Pre-Flight Checklist >> Propellers Installation: Removal: Make sure the transmitter, the Make sure that the camera Make sure that there is nothing mobile phone and the drone is clean. obstructing the motors. battery are fully charged. -
Page 12: Flight
OPERATION GUIDE OPERATION GUIDE 2.5 Flight >> Pairing and Run the APP Auto-pairing : It takes about 20 seconds to pair the Make sure that you go outdoor to an open area to operate the drone. transmitter with the drone. During the pairing, the transmitter will keep on beeping. - Page 13 OPERATION GUIDE OPERATION GUIDE 2.5 Flight >> Compass Calibration STEP 1: STEP 3: Point the head of the drone upward, and spin the Long press the to enter compass calibra- ×3 drone three times till the transmitter emits a tion. The transmitter will beep once, indicating double beep, which means that you have suc- that the calibration has started.
- Page 14 OPERATION GUIDE OPERATION GUIDE 2.5 Flight >> GPS Signal Search After calibrating the compass, put the drone on a flat surface. Make sure there are no external sources of signal interference around. Please don't use the GPS mode when you are indoors. The drone will automatically perform a search for GPS signals.
- Page 15 OPERATION GUIDE OPERATION GUIDE 2.5 Flight >> 2.5 Flight >> Gyro-Calibration Unlocking the Motors Make sure to place the drone on a level surface before calibrating the gyro. Push the joysticks towards the inner lower corners. The motors start to spin, the Simultaneously push the left joystick and the right joystick to the bottom right drone is unlocked.
- Page 16 OPERATION GUIDE OPERATION GUIDE 2.5 Flight >> Takeoff/Landing * Transmitter Communication Range When operating the drone, it's important to periodically adjust the orientation and Remember to unlock the motors before takeoff. distance between the transmitter and the drone to ensure that the drone always remains within the optimal communication range.
-
Page 17: Flight Functions
DRONE FUNCTIONS DRONE FUNCTIONS 3.1 Flight Functions >> 3.1 Flight Functions >> Gimbal Dial Take Photo/Record Video The 3-axis gimbal stabilizes the camera, allowing you to capture clear, stable images and video. The control tilt range is -90° to 0° . Use the gimbal dial( ) to control the tilt of the camera. -
Page 18: Camera Mode
DRONE FUNCTIONS DRONE FUNCTIONS 3.1 Flight Functions >> 3.1 Flight Functions >> Speed Switch Headless Mode The Headless Mode is a great training tool for beginner pilots. It is also useful when the drone is too far from the pilot (which makes it difficult to tell its orientation). It This drone offers two speed modes: keeps the drone traveling forward, backward, left, or right when you move the right joystick in those directions, regardless of which way the front of the drone is pointed. - Page 19 DRONE FUNCTIONS DRONE FUNCTIONS 3.1 Flight Functions >> Headless Mode * Why is the orientation of the drone important? In normal flying mode, the control of the drone movement can sometimes be counter-intuitive for beginners. For instance, when the drone is in the air with its head pointing to your right, if you push the right joystick forward, the drone will fly to your right, instead of flying forward.
- Page 20 DRONE FUNCTIONS DRONE FUNCTIONS 3.1 Flight Functions >> Return to Home (RTH) Failsafe RTH : The Failsafe RTH will be activated when: 1. The connection between the transmitter and the drone is lost for more than 15 seconds. The Return to Home function brings the drone back to the recorded Home Point. 2.
- Page 21 DRONE FUNCTIONS DRONE FUNCTIONS 3.1 Flight Functions >> 3.2 Stabilization Functions >> Return to Home(RTH) Altitude-Hold Function Low Voltage RTH : When the flight battery is too low or there is not enough power to return home, the user should land the drone as soon as possible to avoid damage to the drone or other hazards. To prevent unnecessary risks due to insufficient battery power, the low voltage RTH function will be automatically triggered when the drone battery is low.
- Page 22 DRONE FUNCTIONS DRONE FUNCTIONS 3.2 Stabilization Functions >> Optical Flow Positioning Optical Flow Module The Optical Flow Positioning System The Optical Flow Positioning System is consists of a camera module, which typically used in an indoor environ- acquires the position information of the ment when the GPS signal is weak or drone through visual images to ensure unavailable.
-
Page 23: App Functions
DRONE FUNCTIONS DRONE FUNCTIONS 3.3 App Functions >> App Interface Back Tap this icon to return to the main menu. Flight Parameters: Flight Altitude Vertical distance from the Home Point. Flight Distance Horizontal distance from the Home Point. Drone's speed in the vertical direction. Vertical Speed Drone's speed in the horizontal direction. -
Page 24: Drone Battery
4.1 Specifications >> App Interface DRONE： Return to Home The drone returns to the last recorded Home Point. Model: HS790 Weight: 377g/13.3oz Multi-functions Max Flight Time: about 30 minutes The drone stays at a distance from the operator and follows the... -
Page 25: Usb Charging Cable
APPENDIX APPENDIX 4.1 Specifications >> 4.1 Specifications >> CAMERA： TRANSMITTER： Operating Frequency: 5745-5825MHz Operating Frequency: 5745-5825MHz Photo Resolution: 5700*3200P 1280*720P (when stored in TF card) (when stored in cellphone) Battery Type: 3.7V 3600mAh Lithium-ion battery Video Resolution: 3840*2160P@30fps 1280*720@30fps (when stored in TF card) (when stored in cellphone) Operating Temperature Range: 32°... -
Page 26: Troubleshooting
APPENDIX APPENDIX 4.3 Troubleshooting >> 4.4 Compliance Information >> Possible Causes Issues Suggested Solutions FCC Notice： This device complies with part 15 of the FCC Rules. Operation is subject to the following two (1)Ensure you're operating in an area with strong GPS reception. conditions: Weak GPS signal. - Page 27 3. Declaration of Conformity. operation of the device. We, Xiamen Huoshiquan Import & Export CO.,LTD hereby, declare that the UAS HS790 is of class C1, and in compliance with the RED Directive 2014/53/EU, the RoHS Directive L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR 2011/65/EU, Machinery Directive 2006/42/EC and UAS Delegated Regulation 2019/945/EU amended by d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio...
- Page 28 Battery Charging Hub User Guide V1.0 +1(833)766-4733 www.holystone.com usa@holystone.com (USA) ca@holystone.com (CA) au@holystone.com(AU) eu@holystone.com (EU)
-
Page 29: Mode Button
Please read this document in its entirety and all safe and legal practices before use. Place the charging hub on a flat, stable surface when in use. Ensure that the unit is well insulated to prevent a fire hazard. DO NOT attempt to touch the metal terminals on the hub. Clean the metal terminals with a clean, dry cloth if there is any noticeable buildup. - Page 30 Usage The battery charging hub can charge and store the drone battery for maintenance, and can also charge external devices such as remote control or cell phone. It is divided into the following three functions. Charging Intelligent Flight Battery 1. As shown in Figure (1)-a, Insert the batteries into the charging hub. 2.
-
Page 31: Specifications
(1)-a (1)-b Specifications Size 116x51x85mm Net weight 117g Input(USB-C) 5-12V, Max. 2A (Support QC & PD) Output(USB-C) 5V/1A Charging time About 110 minutes per battery (Shortest)
