- Page 1 Instructions For Use Gebrauchsanweisung V 4.0 HS175D www.holystone.com +1(855) 888-6699 eu@holystone.com (EU) usa@holystone.com (USA) ca@holystone.com (CA)
- Page 3 English 01-36 Deutsch 37-70...
-
Page 4: Table Of Contents
Contents 1.0 Disclaimer & Warning ................. 2.0 Safety Guidelines ................... 3.0 Maintenance ....................4.0 Package Contents ................... 5.0 Drone Details ....................6.0 Transmitter Details ..................7.0 Mode Switch ..................... 8.0 Installation 8.1 Propellers ....................8.2 TF Card ......................8.3 Drone Battery ................... 8.4 Antenna ...................... - Page 5 11.0 Functions Details 11.1 Camera Angle Adjustment ............... 11.2 Speed Switch ..................11.3 Trimmer Function ................11.4 Take Photo/Video ................11.5 Headless Mode ................... 11.6 Return to Home (RTH) ................ 11.7 Emergency Stop ..................11.8 Optical Flow Positioning ..............12.0 Specifications .................... 13.0 Trouble Shooting ..................
-
Page 6: Disclaimer & Warning
1.0 DISCLAIMER & WARNING 1. Please read this Disclaimer & Warning and Safety Guidelines carefully before using our product. This product is not recommended for people under the age of 14. By using this product, you hereby agree to this disclaimer and signify that you have read it fully. - Page 7 ④ Please perform a thorough check of the product before each use. Inspect the integrity of the parts, any signs of cracks and wear off on the propellers, battery power and effectiveness of the indicator, etc. If after doing a complete check of the drone any problems are found, please refrain from using it until the problem has been resolved.
- Page 8 2.3 Operation Requirements ① DO NOT use this product to follow any moving vehicles. ② During the flight, turn off the motors only in case of an emergency. ③ Fly the drone back to you as soon as you are notified that the battery is running low.
- Page 9 ⑦ Only use the USB charging cable that comes with the drone to charge the battery. ⑧ DO NOT connect the battery directly to wall outlets or car cigarette -lighter sockets as this will damage your battery as they are a different voltage.
-
Page 10: Maintenance
3.0 MAINTENANCE ① Clean the product after each use with a clean, soft cloth. ② Avoid prolonged exposure to direct sunlight and avoid buildup of heat on the drone or batteries. ③ This device is not waterproof and must not be submerged or subjected in water under any circumstance. -
Page 11: Package Contents
4.0 PACKAGE CONTENTS Drone Transmitter Drone Battery USB Charging USB Charging Cable Propeller Cable for Drone for Transmitter Instructions For Use Gebrauchsanweisung V 4.0 HS175D +1(855) 888-6699 www.holystone.com usa@holystone.com (USA) eu@holystone.com (EU) ca@holystone.com (CA) Screwdriver Instructions For Use -06-... -
Page 12: Drone Details
5.0 DRONE DETAILS Power Indicator Propeller A Power Switch Propeller B Propeller B Propeller A HD Camera Optical Flow Lens Drone Battery -07-... -
Page 13: Transmitter Details
6.0 TRANSMITTER DETAILS Phone Holder Take Photo Lens Up Record Video Lens Down Right Joystick/ Left Joystick Speed Switch Folded Handle Power Switch Charging Port One Key Takeoff/ Return to Home Landing Headless Mode (Short Press) Calibrating the Compass (Long Press) Antenna -08-... -
Page 14: Mode Switch
7.0 MODE SWITCH 7.1 MODE 2 (Left hand throttle MODE 2 will be default setting.) Left Joystick Right Joystick Forward Ascend Descend Down Backward Down Left Right Right Left Fly to Fly to Rotate Right Rotate Left Left Right - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7.2 MODE 1 To enter MODE 1, turn on the transmitter while holding the “Record Video”... -
Page 15: Installation
8.0 INSTALLATION 8.1 Propellers HEAD Connect each propeller to its corresponding motor shaft, either position “A/B” , then lock the propeller to the motor shaft with two screws. Attention: Pay attention to the “A” “B” is printed on the each propeller. -
Page 16: Drone Battery
8.3 Drone Battery Pic.1 Pic.2 Installation: Push the battery correctly into the drone battery compartment. Make sure that you hear a click sound indicating the battery is firmly installed. (Pic.1) Removal: Press the lock button on the battery and pull it back to remove the battery from the fuselage. -
Page 17: Charging
9.0 CHARGING 9.1 Drone Battery USB Adapter (5V/2.0A) Power Bank 1) When the drone battery runs low, the indicator lights on the drone will flashes continuously. 2) Remove the battery and connect the USB charging cable to the battery charging interface. 3) Plug the USB charging cable into a USB charging port on the power bank or USB adapter (5V/2.0A). -
Page 18: Transmitter Battery
9.2 Transmitter Battery Unfold the transmitter Fold the transmitter USB Adapter (5V/2.0A) Power Bank 1) When the transmitter battery runs low, the transmitter will continue to sound the “DiDiDi...” alarm. 2) Connect the USB charging cable to the charging interface. 3) Plug the USB charging cable into a USB charging port on power bank or USB adapter (5V/2.0A). -
Page 19: Operation Guide
10.0 OPERATION GUIDE 10.1 Download APP Android APP on Google play Scan the QR code, corresponding to either App Store™ or Google Play™ Store and download the HS GPS V5 app for free. Required Operating Systems: iOS 8.0 or later/Android 5.0 or later 10.2 Connect to Wi-Fi Connect your phone to the Wi-Fi network created by the drone. -
Page 20: Pairing
All of the operations shown in this manual are demonstrated using MODE 2. 10.3 Pairing ① Long press the power switch to turn on the drone and the indicator lights on the drone begin to flash. HEAD ② Place the drone on a flat and level surface with the head forward and the tail towards the pilot. -
Page 21: Calibrating The Compass
10.4 Calibrating the Compass ① Long press Compass Calibration button to enter the compass calibration state. ② Hold the drone horizontally and rotate it until the rear indicator lights change from flashing slowly to flashing quickly. ③ Hold the drone vertically and rotate it until the rear indicator lights change from flashing quickly to solid -16-... -
Page 22: Gps Searching
10.5 GPS Searching HEAD Place the drone on a flat and dry surface where is unobstructed and lit area. When the indicator lights change from red to green, it means that the search for GPS signal is completed. This process may take about one minute. -
Page 23: Calibrating The Gyro
10.6 Calibrating the Gyro Simultaneously push the left joystick and the right joystick to the bottom left corner to calibrate the gyro. When the indicator lights on the drone blink quickly and turn solid on, indicating calibration is completed. Tip: To ensure a stable flight, we suggest that the pilot calibrates the gyro every time after pairing the drone and after a crash. -
Page 24: One Key Takeoff/Landing
10.8 One Key Takeoff/Landing Please unlock the motor before take-off. ① ② Take-off Landing ① After unlocking the drone, short press the One Key Takeoff button, the drone will automatically take off and hover at 5 feet altitude. ② When the drone is flying, short press the One Key Landing button, the drone will automatically land on the ground. -
Page 25: Functions Details
11.0 FUNCTION DETAILS 11.1 Camera Angle Adjustment 90° As shown in the figure above, you can adjust the camera to tilt up or down through the two buttons “ ” and “ ”. (The camera has an 90° tilt range.) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11.2 Speed Switch This drone comes with 2 speed modes (Low/High). -
Page 26: Trimmer Function
11.3 Trimmer Function F/B Sideways Drift Trim: If the drone tends to drift forward, press the Throttle joystick and push the Direction joystick down at the same time to re-balance the drone. If the drone tends to drift backward, press the Throttle joystick and push the Direction joystick up at the same time to re-balance the drone. -
Page 27: Take Photo/Video
11.4 Take Photo/Video Take Photo: Short press the Photo button on the transmitter to take pictures. One beep can be heard from the transmitter, indicating the camera has successfully taken one photo. Record Video: Short press the Video button on the transmitter, two beeps from the transmitter will be heard. -
Page 28: Headless Mode
11.5 Headless Mode The Headless Mode is a great training tool for beginner pilots. It is also useful when the drone is too far from the pilot (which makes it difficult to tell its orientation). It keeps the drone traveling forward, backward, left, or right when you move the right joystick in those directions, regardless of which way the front of the drone is pointed. -
Page 29: Return To Home (Rth)
11.6 Return to Home (RTH) The Return to Home (RTH) function brings the drone back to the last recorded take-off point. This function can only be achieved in GPS mode. There are three types of RTH: Smart RTH/Low Voltage RTH/Failsafe RTH. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11.6.1 Smart RTH Short press the Return to Home button to enter the return procedure. -
Page 30: Emergency Stop
11.6.3 Failsafe RTH If the GPS signal is available and the take-off point is recorded previously. Failsafe RTH will be triggered if the transmitter signal is lost for more than 20 seconds. The drone will automatically start the return procedure and it will fly back to the last recorded take-off point. -
Page 31: Optical Flow Positioning
11.8 Optical Flow Positioning Optical Flow Lens The Optical Flow Positioning System consists of optical flow lens modules, which acquires the position information of the drone through visual images to ensure precise positioning of the drone. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - The Optical Flow Positioning System is typically used in indoor environ- ment when GPS is weak or unavailable. - Page 32 1. Fly fast at an altitude below 0.5m. 2. Fly over monochrome surfaces (like pure black, pure red, pure red and pure green). 3. Fly over strong light reflective surfaces or surfaces prone to reflection. 4. Fly over water or transparent object surfaces. 5.
-
Page 33: Specifications
12.0 SPECIFICATIONS DRONE Model: HS175D Weight: 215g/7.58oz Max Flight Time: 23 minutes (per battery) Operating Temperature Range: 32° to 104°F Size: 145 × 65 × 63 mm (Folded) 275 × 210 × 63 mm (Unfolded) DRONE BATTERY Capacity: 1700 mAh Voltage: 7.6 V... - Page 34 CAMERA Operating Frequency: 5500-5700MHz Photo Resolution: 4096×3072P (stored in TF card) 4096×3072P (stored on mobile phone) Video Resolution: 2688×1512P (stored in TF card) 1920×1080P (stored on mobile phone) Lens: FOV 110° Max Transmission Distance: 984 feet/300m (outdoor and unobstructed) Live View Quality: 720p@25fps Photo Formats: JPEG Video Formats: AVI/MP4 Supported TF Cards: Supports a TF Card...
-
Page 35: Trouble Shooting
13.0 TROUBLE SHOOTING Problem Solution 1. Charge the drone battery. The drone does not respond. 2. Charge the transmitter battery. 1. Change the batteries. The drone’s response is intermit- 2. Move to a different area where tent. there is no interference. Place the drone on a flat, level The drone drifts to one side while surface and repeat the gyro... -
Page 36: General Information
15.0 GENERAL INFORMATION FCC Notice: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interfer- ence that may cause undesired operation. - Page 37 WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. RF Exposure The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with a minimum distance of 20cm between the radiator &...
- Page 38 CAN NMB-003 (B) RF Exposure Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operat- ed with a minimum distance of 20cm between the radiator & your body. Déclaration d'exposition aux radiations: Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non contrôlé.
- Page 39 BATTERY WARNING: 1. Failure to follow all the instructions may result in serious injury, irreparable damage to the battery may cause a fire, smoke or explosion as well. 2. Always check the battery’s condition before charging or using it. 3. Please replace the battery if the battery is dropped or has any peculiar smell, overheating, discolouration, deformation or leakage happens.
- Page 40 13. Batteries MUST be inserted with the correct polarity. 14. The supply terminals MUST not to be short-circuited. Regular examina- tion of transformer or battery charger for any damage to their cords, plugs, enclosures and other parts MUST be done. If there is damage, they MUST not be used until the damage has been repaired.
- Page 41 Directive 2009/48/EC have been fully fulfilled on our product with indication below: Product Name: Remote control four axis series Model/Mark : HS175D/HOLYSTONE The Statement of compliance is available at the following address: http://www.holystone.com/Download/CE/HS175D _EU_DOC.pdf This product can be used among EU member states.
