Smartrise HYDRO:EVOLVED Installation Manual
Hide thumbs
Also See for HYDRO:EVOLVED:
- User manual (357 pages) ,
- Startup manual (28 pages) ,
- Startup manual (24 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Smartrise HYDRO:EVOLVED
Summary of Contents for Smartrise HYDRO:EVOLVED
- Page 1 Document HYDRO:EVOLVED History INSTALLATION GUIDE VERSION 1.0...
- Page 2 Document History Date Version Summary of Changes July 8, 2025 Initial Release...
-
Page 3: Table Of Contents
Table of Contents__ Review Job Specifications ..........................1 Implement Safe and Effective Grounding ......................1 Review Voltage Settings ............................. 1 Mount Controller ..............................1 Set Up Main Power ............................. 1 Set Up Construction Mode ..........................2 Set Up Soft Starter & Valves ..........................3 Primary Soft Starter Configuration ........................ - Page 4 Page intentionally left blank.
-
Page 5: Review Job Specifications
For instance, if the door operator for a specific job operates at 240 VAC but Smartrise was not informed during the engineering phase, the DR breaker (door operator voltage supply) will be set to 120 VAC by default as a safety precaution. -
Page 6: Set Up Construction Mode
3. Jump LRT, LRM, and LRB to L120 (Rear). 4. Jump MM to M24. 5. Wire the temporary run box as shown in the Hydro:Evolved Electrical Drawing, Car Tables Sheet. 6. Set the inspection switch on the MR (SR-3032) to the inspection position. -
Page 7: Set Up Soft Starter & Valves
SS Fault: If a fault occurs in the soft starter, a fault signal is sent to the MR board. Refer to Hydro:Evolved Electrical Drawing, Starter and Valve Sheet for detailed wiring information. Refer to Soft Starter Startup Manual Siemens Hydraulic Installation and Soft Starter Startup Manual Sprecher + Schuh Hydraulic Installation for details. -
Page 8: Over Current
Defines the maximum allowable temperature before the system enters recovery mode and shuts down the motor. To Set the Overtemperature Limit: 1. Navigate to Main Menu. 2. Go to Setup. 3. Go to Hydro. 2025 © Smartrise Engineering, Inc. All Rights Reserved... -
Page 9: Secondary Soft Starter Configuration
Defines the time required for the secondary soft starter to reach full voltage, minimizing torque and mechanical stress. To Set the Ramp Up Time: 1. Navigate to Main Menu. 2. Go to Setup. 3. Go to Hydro. 4. Go to Soft Starter. 5. Go to Secondary. 2025 © Smartrise Engineering, Inc. All Rights Reserved... -
Page 10: Vmax
2. Go to Setup. 3. Go to Hydro. 4. Go to Soft Starter. 5. Go to Secondary. 6. Select Over Current. 7. Enter the maximum allowable current. 8. Scroll right and press Save. 2025 © Smartrise Engineering, Inc. All Rights Reserved... -
Page 11: Over Temperature
1. Navigate to Main Menu. 2. Go to Setup. 3. Go to Hydro. 4. Go to Soft Starter. 5. Go to Third. 6. Select Enable Third. 7. Set to ON. 8. Scroll right and press Save. 2025 © Smartrise Engineering, Inc. All Rights Reserved... -
Page 12: Run With One Soft Starter Configuration
Secondary Valve Board A secondary valve is required when a dual-motor configuration is used for high-capacity elevators. Only the SR Valve type supports secondary valve control. To Enable the Secondary Valve Board: 2025 © Smartrise Engineering, Inc. All Rights Reserved... -
Page 13: Third Valve Board
To Enable the Fourth Valve Board: 1. Navigate to Main Menu. 2. Go to Setup. 3. Go to Hydro. 4. Go to Fourth Valve Board. 5. Set to ON. 6. Scroll right and press Save. 2025 © Smartrise Engineering, Inc. All Rights Reserved... -
Page 14: Set Up Wiring
..Hydro:Evolved Installation Guide_ 8 Set Up Wiring Set up all wiring per the Hydro:Evolved Electrical Drawing. 9 Mount Car Top Position and secure the Car Top assembly in accordance with the applicable state and local codes for the job. 10 Set Up Normal Mode Set the controller to Normal mode by disconnecting the jumper between MM and M24, then switch the Inspection/Normal toggle to the NORMAL position. -
Page 15: Inspection Speed
This speed is influenced by valve regulation and the car’s weight. Increased load may reduce leveling speed and prolong the leveling process if valves are not properly adjusted. Adjustment Range: 1–20 FPM Default: 10 FPM Unit: FPM To Set Leveling Speed: 2025 © Smartrise Engineering, Inc. All Rights Reserved... -
Page 16: Set Up Floors & Openings
5. Set the correct number of floors. NOTE: This total should include any express zones that are serviced by other cars in the group. The opening map will reflect only the floors served by the selected car. 2025 © Smartrise Engineering, Inc. All Rights Reserved... -
Page 17: Learn The Hoistway
If the car is at the top landing, press and hold Enable + Down until the car starts moving. If the car is at the bottom landing, press and hold Enable + Up until the car starts moving. 2025 © Smartrise Engineering, Inc. All Rights Reserved... -
Page 18: Set Up Fire
8. On the MR board, turn OFF DIP switch 5A. 14 Set Up Fire Install the fire service jumpers as shown in the Hydro:Evolved Electrical Drawing, Riser Board Connections Sheet. 15 Set Up Hall Board Configure the Hall Board DIP switch setting according to the Hydro:Evolved Electrical Drawing, Hall Call Dip Switches Sheet. - Page 19 13. After 15 minutes, Navigate to Main Menu. 14. Go to Debug. 15. Go to DebugRuns. 16. Select Clear Debug Runs. 17. Select Yes. Refer to the Floor Level Adjustments for detailed information. 2025 © Smartrise Engineering, Inc. All Rights Reserved...
