- Page 1 BLACK MODULAR GRILLE GUARD FOR GMC SIERRA 1500LD 07-13 INSTALLATION INSTRUCTIONS BLACK MODULAR GRILLE GUARD FOR GMC SIERRA 1500LD 07-13 PART #17GS10MA Page 1 of 8...
-
Page 2: Parts List
BLACK MODULAR GRILLE GUARD FOR GMC SIERRA 1500LD 07-13 PARTS LIST: QTY Description QTY Description 1 Front Guard 12mm x 24mm OD x 2.5mm STD Flat Washers 1 Right Brush Guard 12 12mm x 32mm OD x 3mm Large Flat Washers 1 Left Brush Guard 12mm Nylon Lock Nuts 1 Driver/Left Top Bracket... - Page 3 BLACK MODULAR GRILLE GUARD FOR GMC SIERRA 1500LD 07-13 a. Line up the Mounting Bracket with the outside of the frame, (Figure 4). Slide the Mounting Bracket over the long factory bolt and attach with the factory hex nut. Do not tighten at this time.
- Page 4 BLACK MODULAR GRILLE GUARD FOR GMC SIERRA 1500LD 07-13 12. Do periodic inspections to the installation to make sure that all hardware is secure and tight. To protect your investment, wax this product after installing. Regular waxing is recommended to add a protective layer over the finish.
- Page 5 BLACK MODULAR GRILLE GUARD FOR GMC SIERRA 1500LD 07-13 Long tow Short tow hook bolt hook bolt Short factory Long factory tow hook bolt tow hook bolt Front 12mm x 30mm Hex Bolt and Hardware (Fig 5) Passenger side Brackets pictured Long factory tow hook bolt Front...
- Page 6 BLACK MODULAR GRILLE GUARD FOR GMC SIERRA 1500LD 07-13 Front Use a pair of needle nose pliers to carefully pinch the top and bottom tab on the clip to release and remove the grille Front (Fig 9) Pull back the rubber splash guard (if equipped) to locate the factory hex bolt in the top of the frame (passenger side pictured) Passenger Side...
- Page 7 BLACK MODULAR GRILLE GUARD FOR GMC SIERRA 1500LD 07-13 (3) 12mm x 30mm Hex Bolts (6) 12mm x 32mm Large Flat Washers (3) 12mm Nylon Lock Nuts 8mm Hex Bolt 8mm Lock Washer 8mm Flat Washer Factory bumper bracket bolt (Fig 13) Passenger side pictured.
- Page 8 BLACK MODULAR GRILLE GUARD FOR GMC SIERRA 1500LD 07-13 8-1.25mm Nylon Lock Nuts 8mm x 25mm Button Head Bolt 8mm x 24mm x2mm Flat Washers Left Brush Guard Same to the right side Complete Installation Page 8 of 8...
