- Page 1 ® Intel Integrated RAID Module SROMBSASMR (AXXROMBSASMR) Hardware User’s Guide Intel Order Number: E58607-003...
- Page 2 Intel may make changes to specifications and product descriptions at any time, without notice. Intel is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. *Other names and brands may be claimed as the property of others.
-
Page 3: Preface
• Chapter 2 describes the procedures for installing and configuring the RAID module. ® • Chapter 3 provides the characteristics and technical specifications for the Intel Integrated RAID Module SROMBSASMR. • Appendix A explains drive roaming and drive migration. •... - Page 4 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide...
-
Page 5: Table Of Contents
Appendix B: ........Installation / Assembly Safety Instructions 19 English ..........................21 Deutsch ..........................22 Français ..........................23 Español ..........................25 Italiano ..........................26 Appendix C: Regulatory and Certification Information ........29 Product Safety and EMC Compliance .................29 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... - Page 6 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide...
-
Page 7: List Of Figures
Figure 1. Installing the Snap Standoff ..................8 ® Figure 2. Installing the Intel Integrated RAID Module SROMBSASMR ........9 Figure 3. Connecting Cable between the RAID Module and Drives/Backplane...... 10 Figure 4. Card Layout......................13 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... - Page 8 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide viii...
-
Page 9: List Of Tables
List of Tables Table 1. Jumper Description ....................13 Table 2. Technical Specifications ....................14 Table 3. Array Performance Features ..................14 Table 4. Fault Tolerance Features ..................15 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... - Page 10 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide...
-
Page 11: Chapter 1: Overview
SATA or high performance SAS media. ® As a third generation PCI Express* storage controller, the Intel Integrated RAID Module SROMBSASMR addresses the demand for increased data throughput and scalability requirements across entry level, midrange, and enterprise server platforms. -
Page 12: Intel Integrated Raid Module Srombsasmr
Note: Additional Intel Server Boards and Systems may be supported. For the most up-to-date ® list, see the Compatibility section under the link for this Intel RAID Module at http://support.intel.com/support/motherboards/server/. The SAS controller supports the ANSI Serial Attached SCSI (SAS) Standard, Version 1.0 and the Serial ATA (SATA) protocol defined by the Serial ATA Specification, Version 1.0a. -
Page 13: Usability
The operating systems supported may not be supported by your server board. See the Tested operating system list for your server board at http://support.intel.com/support/motherboards/server/. To make sure the RAID module supports your operating system, see also the Tested ® Hardware and Operating System List for the Intel Integrated RAID Module SROMBSASMR. Usability •... -
Page 14: Sas/Sata Features
• Failures are logged from controller and drive firmware, and SMART monitor. ® • Failures are logged in NVRAM, viewable from OS Event Log, Intel RAID Web Console 2, CIM, and LEDs. • Multiple cache options allow configuration-specific performance optimization: —... -
Page 15: Online Capacity Expansion And Raid Level Migration Rules
Migrations supported are RAID 1 to RAID 0, RAID 5 to RAID 0, RAID 6 to RAID • With OCE, migrations supported are RAID 0 to RAID 1, RAID 0 to RAID 5, RAID 1 to RAID 5. Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... - Page 16 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide...
-
Page 17: Chapter 2: Intel ® Integrated Raid Module Srombsasmr Hardware Installation
“Installing the RAID Module”) Note: Intel Corporation strongly recommends using an uninterruptible power supply (UPS). Installing the RAID Module To install the RAID Module, follow these steps: 1. Turn off the power to the system, all drives, enclosures, and system components. -
Page 18: Figure 1. Installing The Snap Standoff
3 (see Figure 5. Press down gently but firmly to ensure that the card is properly seated in the connector. Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... -
Page 19: Figure 2. Installing The Intel ® Integrated Raid Module Srombsasmr
✧ You may connect one device per SATA/SAS cable either as a device or as an expander. ✧ Route SAS cables carefully. ✧ Use only “straight” SAS cables, not “cross-over” SAS cables. . Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... -
Page 20: Figure 3. Connecting Cable Between The Raid Module And Drives/Backplane
AF003046 Figure 3. Connecting Cable between the RAID Module and Drives/Backplane 7. Install the server system cover and connect the power cords. See your server system documentation for instructions. Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... -
Page 21: Configuring The Raid Module
After you press the keys to enter the Intel RAID BIOS Console 2 software, the ® firmware takes several seconds to initialize and then display the Intel Integrated RAID Module SROMBSASMR number and firmware version. The numbering of the RAID module follows the PCI slot scanning order used by the server board. - Page 22 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide...
-
Page 23: Chapter 3: Intel ® Integrated Raid Module Srombsasmr Characteristics
Universal Asynchronous 4-pin connector Not populated and should not be used. Receiver/Transmitter (UART) Keyed I C Connector 3-pin keyed Out-of-band enclosure management (SES2) connector Debug Connector 4-pin connector Reserved Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... -
Page 24: Technical Specifications
Host data transfer rate 2.5 Gigabit/sec per PCI Express* lane Drive data transfer rate 3 Gigabit/sec per lane Maximum scatter / gather 26 elements Maximum size of I/O requests 6.4 Mbytes in 64 Kbyte stripes Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... -
Page 25: Fault Tolerance
Parity generation and checking, automatic consistency checking • Patrol reads • Activity and fault LEDs • Multiple retries • ® Logs in NVRAM, event log, CIM, Smart, Intel RAID Web Console 2 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... -
Page 26: Electrical Characteristics
RAID Smart Battery AXXRSBBU3. ® The voltage level used in the charging circuitry for the battery pack on the optional Intel RAID Smart Battery AXXRSBBU3 is +12 V. During fast charging of the battery pack, expected power consumption is 230 mA rise in +12V current. -
Page 27: Appendix A: Drive Roaming And Drive Migration Install
6. Install the server cover. For instructions, see your server system documentation. 7. Plug in and power on the system. The controller detects the RAID configuration from the configuration data on the drives (COD). Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... -
Page 28: Drive Migration
9. Install the server cover. For instructions, see your server system documentation. 10. Plug in and power on the system. When you start the system, the controller detects the RAID configuration from the configuration data on the drives. Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... - Page 29 When working inside your computer: • Do not attempt to service the computer system yourself, except as explained in this guide and elsewhere in Intel documentation. Always follow installation and service instructions closely. • Turn off your computer and any peripherals.
- Page 30 When transporting a sensitive component, first place it in an antistatic container or packaging. • Handle all sensitive components in a static-safe area. If possible, use antistatic floor pads and workbench pads. Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide...
-
Page 31: English
4. Insert and lock the padlock to the system to prevent unauthorized access inside the system. 5. Connect all external cables and the AC power cord(s) to the system. Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... -
Page 32: Deutsch
Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor Sie eine der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu Intel-Serverplatinen und -Servergehäusen auf der Ressourcen-CD oder unter http://support.intel.com/support/motherboards/server/sb/cs-010770.htm. Der Wechselstrom des Systems wird durch den Ein-/Aus-Schalter für Gleichstrom nicht ausgeschaltet. -
Page 33: Français
Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce ® document avant de suivre toute instruction. Consultez Intel Server Boards and Server Chassis Safety Information sur le CD Resource CD ou bien rendez-vous sur le site http://support.intel.com/support/motherboards/server/sb/cs-010770.htm... - Page 34 4. Remettez le cadenas en place et verrouillez-le afin de prévenir tout accès non autorisé à l'intérieur du système. 5. Rebranchez tous les cordons d'alimentation c. a. et câbles externes au système. Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide...
-
Page 35: Español
Para ello: 1. Desbloquee y extraiga el bloqueo de seguridad de la parte posterior del sistema, si se ha instalado uno. 2. Extraiga y guarde todos los tornillos de las tapas.Extraiga las tapas. Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... -
Page 36: Italiano
Il cavo è considerato il dispositivo d'interruzione dell'alimentazione principale (in c.a.). La presa alla quale si collega il sistema deve essere installata vicino all'unità e deve essere facilmente accessibile. Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide... - Page 37 Se il sistema è stato a lungo in funzione, il microprocessore e il dissipatore di calore potrebbero essere surriscaldati. Fare attenzione alla presenza di piedini appuntiti e parti taglienti sulle schede e sul telaio. È consigliabile l'uso di guanti di protezione. Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide...
- Page 38 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide...
-
Page 39: Appendix C: Regulatory And Certification Information
® This Intel RAID Module has been evaluated for regulatory compliance as an Intel end system, and is included as part of the end system certification. For information on end system certification, refer to the product regulatory certification for the end system level product. - Page 40 Intel® Integrated RAID Module SROMBSASMR Hardware User’s Guide...
