- Page 1 ® Intel Integrated RAID Module RMS2MH080 (AXXRMS2MH080) Hardware User’s Guide Intel Order Number: E93117-002...
- Page 2 Intel may make changes to specifications and product descriptions at any time, without notice. Intel is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. *Other names and brands may be claimed as the property of others.
-
Page 3: Preface
• Chapter 2 describes the procedures for installing and configuring the RAID module. ® • Chapter 3 provides the characteristics and technical specifications for the Intel Integrated RAID Module RMS2MH080. • Appendix A explains drive roaming and drive migration. •... - Page 4 Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
-
Page 5: Table Of Contents
SAS/SATA Features ...................... 5 Online Capacity Expansion and RAID Level Migration Rules ........5 ® Intel Integrated RAID Module RMS2MH080 Hardware Installation ...... 7 Requirements ........................7 Installing the RAID Module ....................7 Configuring the RAID Module ....................10 Replacing a Controller, Resolving a Config Mismatch ............10 ®... - Page 6 B. Installation/Assembly Safety Instructions ............31 English ..........................33 Deutsch ..........................34 Français ..........................35 Español ..........................37 Italiano ..........................38 C. Regulatory and Certification Information ............41 Product Safety and EMC Compliance ................. 41 Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
- Page 7 RAID Smart Battery AXXRSBBU7 ..............14 ® Figure 7. Intel Integrated RAID Module RMS2MH080 SAS/SATA Connectors ....15 Figure 8. SFF8087 to Four-port Internal Cable ............... 17 Figure 9. PCI Interface ......................20 Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
- Page 8 Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
- Page 9 Table 5. Host Board Interface Connector Pin-Out ..............21 Table 6. Technical Specifications ....................22 Table 7. Array Performance Features ..................23 Table 8. Fault Tolerance Features ..................24 Table 9. RAID Physical Drive Status ..................27 Table 10. RAID Virtual Drive Status ..................27 Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
- Page 10 Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
-
Page 11: Overview
As a second generation PCI Express* storage controller, the Intel Integrated RAID Module RMS2MH080 addresses the growing demand for increased data throughput and scalability requirements across entry level, midrange, and enterprise server platforms. The controller can be connected to up to eight drives directly and allows the use of expanders to connect to additional drives. -
Page 12: Intel Integrated Raid Module Rms2Mh080
Note: Additional Intel Server Boards and Systems may be supported. For the most up-to-date ® list, see the Compatibility section under the link for this Intel RAID Module at http://www.intel.com/support/go/motherboards/server/index.htm. The SAS RAID controllers support the SAS protocol as described in the Serial Attached SCSI Standard, Version 2.0. -
Page 13: Operating System Support
Caution: Exceeding 50% rate may cause operating system errors due to waiting for controller access. • Background operating mode can be set for Rebuilds, Consistency Checks, Initialization (auto restarting Consistency Check on redundant volumes), Migration, OCE, and Patrol Read. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 14: Redundancy And Error Handling
• Failures are logged from controller and drive firmware, and SMART monitor. ® • Failures are logged in NVRAM, viewable from OS Event Log, Intel RAID Web Console 2, CIM, and LEDs. • Multiple cache options allow configuration-specific performance optimization: —... -
Page 15: Sas/Sata Features
Migrations supported are RAID 1 to RAID 0, RAID 5 to RAID 0, RAID 6 to RAID • With OCE, migrations supported are RAID 0 to RAID 1, RAID 0 to RAID 5, RAID 1 to RAID 5. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... - Page 16 Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
-
Page 17: Intel Integrated Raid Module Rms2Mh080 Hardware Installation
“Installing the RAID Module”) Note: Intel Corporation strongly recommends using an uninterruptible power supply (UPS). Installing the RAID Module To install the RAID Module, follow these steps: 1. Turn off the power to the system, all drives, enclosures, and system components. -
Page 18: Figure 1. Installing The Barrel Standoff
Figure 1. Installing the Barrel Standoff ® 4. Attach the Intel Integrated RAID Module RMS2MH080 module card to the matching server/workstation board connector, and press the module card firmly to engage the barrel standoffs installed in step 3 (see Figure 5. -
Page 19: Figure 3. Connecting Cable Between The Raid Module And Drives/Backplane
Use only “straight” SAS cables, not “cross-over” SAS cables. . AF003483 Figure 3. Connecting Cable between the RAID Module and Drives/Backplane 7. Install the server system cover and connect the power cords. See your server system documentation for instructions. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 20: Configuring The Raid Module
® firmware takes several seconds to initialize and then display the Intel Integrated RAID Module RMS2MH080 number and firmware version. The numbering of the RAID module follows the PCI slot scanning order used by the server board. ® 3. Follow the instructions in the Intel... -
Page 21: Intel ® Integrated Raid Module Rms2Mh080 Characteristics
Enables support for RAID Premium Feature. Header UART debug header 4-pin connector Factory use only (may be removed in future) Bootstrap CONFIG header 4-pin connector Factory use only (may be removed in future) Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 22: Major Components
PCI Express* bus operating at 6.0 Gbps serial transfer rate • Spread Spectrum Clocking (SSC) • SAS/SMP/STP/SATA support • Supports SAS and SATA devices • Initiator and Target mode (SSP) • Wide port support • T10 End-to-End Data Protection (EEDP) Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 23: Flash Rom
® The Intel Integrated RAID Module RMS2MH080 includes 512 MB of integrated DDR2 800 MHz ECC SDRAM memory. This DIMM is connected directly to the memory controller interface bus of the ROC and serves as storage for the executable code transferred from the flash. -
Page 24: Diagnostic Components
The drive failure tones repeat until the problem is corrected, or until the alarm is silenced or disabled. The alarm can be silenced or disabled on the controller’s properties page in ® the BIOS Console or by using the failed drive options pane in the Intel RAID Web Console 2. -
Page 25: Sas/Sata Connectors
Color) to indicate a board error. SAS/SATA Connectors ® The Intel Integrated RAID Module RMS2MH080 provides two internal SFF8087 SAS/SATA signal connectors. Each SFF8087 connector provides support for four SAS/SATA ports. The sideband signals are configured to adhere to the SFF-8485 Specifications for SGPIO support. -
Page 26: Table 2. Sff8087 Connector To Four Single Port Connectors Pin-Out
Pin Definition Connector Port 0 RX0+ RX0- TX0+ TX0- Port 1 RX1+ RX1- TX1+ TX1- Sideband 0 Sideband 1 Sideband 2 Sideband 3 Sideband 4 Sideband 5 Sideband 6 Sideband 7 Port 2 Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 27: Figure 8. Sff8087 To Four-Port Internal Cable
Controller Pin-out Backplane Pin-out Port SATA SFF8087 Pin Definition Pin Definition Connector RX2+ RX2- TX2+ TX2- Port 3 RX3+ RX3- TX3+ TX3- Figure 8. SFF8087 to Four-port Internal Cable Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 28: Bbu Connector Pin-Out
BBU Connector Pin-out Table 3. BBU Connector Pin-out BBU Connector Pin-out Pin Number Description P12V_STBY BBU_RMT_PRSNT_R_N P1V8 P3V3 P1V8_BB P3V3_AUX SMB_BBU_BUF_SCL_R SMB_BBU_BUF_SDA_R BBU_PFAIL_N BBU_BBE BBU_STB BBU_BBSTATUS_RMT_R Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 29: I2C Connector Pin-Out
Host Board Interface ® The Intel Integrated RAID Module RMS2MH080 board interfaces with the host system through two custom board-to-board interface that implements two x4 PCI Express* lanes signaling as defined in the PCI Express Specification 2.0. These interfaces also provide +3.3 V power to the board. -
Page 30: Figure 9. Pci Interface
Figure 9. PCI Interface Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 31: Table 5. Host Board Interface Connector Pin-Out
PE_TX_DP<0> PE_TX_DN<4> PE_TX_DN<0> PE_TX_DP<5> PE_TX_DP<1> PE_TX_DN<5> PE_TX_DN<1> PE_TX_DP<6> PE_TX_DP<2> PE_TX_DN<6> PE_TX_DN<2> PE_TX_DP<7> PE_TX_DP<3> PE_TX_DN<7> PE_TX_DN<3> PU_FM_SAS_PRSNT TP_PE_WAKE_N TP_SMB_LAN_3V3SB_CLK FM_SAS_DISABLE_R_N TP_SMB_LAN_3V3SB_DAT P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3_AUX P3V3_AUX PE_RX_DP<4> PE_RX_DP<0> PE_RX_DN<4> PE_RX_DN<0> Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 32: Technical Specifications
LED_HDD_ACT_N TP_SAS_P47 P3V3 P3V3 P3V3 P3V3 P3V3 P3V3 Technical Specifications Table 6. Technical Specifications ® Specification Intel Integrated RAID Module RMS2MH080 Processor LSI* 2108 Integrated RAID-on-Chip, 800 MHz Operating voltage +3.3 V Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 33: Array Performance Features
As many as the drive can accept drive Stripe sizes 8, 16, 32, 64, 128, 256, 512, or 1024 KB Maximum concurrent 1024 - 16 commands Support for multiple initiators Performance Native command queuing Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 34: Fault Tolerance
+3.3 V rail is used by the 3.3 V logic circuitry and also used to generate the other required voltage rails of +1.0V, +1.2V, and +1.8 V. The +3.3 V auxiliary voltage is used to generate ® the +12 V standby for the Intel RAID Smart Battery AXXRSBBU7. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 35: Thermal And Atmospheric Characteristics
® The voltage level used in the charging circuitry for the battery pack on the optional Intel RAID Smart Battery AXXRSBBU7 is +12 V. During fast charging of the battery pack, expected power consumption is 230 mA rise in +12V current. -
Page 36: Sas Expander Support
® The Intel Integrated RAID Module RMS2MH080 supports LSI* expanders, Vitesse SAS expanders, and PMC expanders that are used as a component in Intel enclosures. Other expanders may be supported post launch, based on market conditions and customer requirements. Support for Non-Hard Disk Drive Devices As SAS-based non-hard drive devices were not available when this controller was in development, support for these devices will be determined as they become available. -
Page 37: Table 9. Raid Physical Drive Status
The drive operating condition is not optimal because one of the configured drives has failed or is offline. Offline Offline The drive is not available to the operating system and is unusable. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 38: Sas Bus And Id Mapping
RAID Controller Drive Limitations Only drives that comply with the SAS and SATA specification extensions are supported. SAS Bus and ID Mapping Devices on the SAS bus are persistently mapped based on a SAS address. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 39: Drive Roaming And Drive Migration Install
6. Install the server cover. For instructions, see your server system documentation. 7. Plug in and power on the system. The controller detects the RAID configuration from the configuration data on the drives (COD). Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 40: Drive Migration
9. Install the server cover. For instructions, see your server system documentation. 10. Plug in and power on the system. When you start the system, the controller detects the RAID configuration from the configuration data on the drives. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 41: Installation/Assembly Safety Instructions
When working inside your computer: • Do not attempt to service the computer system yourself, except as explained in this guide and elsewhere in Intel documentation. Always follow installation and service instructions closely. • Turn off your computer and any peripherals. - Page 42 When transporting a sensitive component, first place it in an antistatic container or packaging. • Handle all sensitive components in a static-safe area. If possible, use antistatic floor pads and workbench pads. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
-
Page 43: English
4. Insert and lock the padlock to the system to prevent unauthorized access inside the system. 5. Connect all external cables and the AC power cord(s) to the system. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 44: Deutsch
5. Tragen Sie ein geerdetes Antistatik Gelenkband, um elektrostatische Ladungen (ESD) über blanke Metallstellen bei der Handhabung der Komponenten zu vermeiden. 6. Schalten Sie das System niemals ohne ordnungsgemäß montiertes Gehäuse ein. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 45: Français
Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce ® document avant de suivre toute instruction. Consultez Intel Server Boards and Server Chassis Safety Information sur le CD Resource CD ou bien rendez-vous sur le site http://support.intel.com/support/motherboards/server/sb/cs-010770.htm Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... - Page 46 4. Remettez le cadenas en place et verrouillez-le afin de prévenir tout accès non autorisé à l'intérieur du système. 5. Rebranchez tous les cordons d'alimentation c. a. et câbles externes au système. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
-
Page 47: Español
Para ello: 1. Desbloquee y extraiga el bloqueo de seguridad de la parte posterior del sistema, si se ha instalado uno. 2. Extraiga y guarde todos los tornillos de las tapas.Extraiga las tapas. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... -
Page 48: Italiano
Il cavo è considerato il dispositivo d'interruzione dell'alimentazione principale (in c.a.). La presa alla quale si collega il sistema deve essere installata vicino all'unità e deve essere facilmente accessibile. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide... - Page 49 Se il sistema è stato a lungo in funzione, il microprocessore e il dissipatore di calore potrebbero essere surriscaldati. Fare attenzione alla presenza di piedini appuntiti e parti taglienti sulle schede e sul telaio. È consigliabile l'uso di guanti di protezione. Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
- Page 50 Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
-
Page 51: Regulatory And Certification Information
® This Intel RAID Module has been evaluated for regulatory compliance as an Intel end system, and is included as part of the end system certification. For information on end system certification, refer to the product regulatory certification for the end system level product. - Page 52 Intel® Integrated RAID Module RMS2MH080 Hardware User’s Guide...
