3
Intel
Characteristics
This chapter describes the characteristics of the Intel
Figure 4
Jumper
J1
J2
J4
J6
Intel® RAID Controller SASMF8I Hardware User's Guide
®
RAID Controller SASMF8I
displays the connectors and headers on the controller and
J1 J2

Table 1. Jumper Descriptions

Description
Drive Fault LED 8x2 header
header
Port activity LED 8 x 2
header header
Universal 4-pin
Asynchronous connector
Receiver/
Transmitter (UART)
Internal SAS/SATA SFF8087
port connector,
ports 4-7
®
J3
J9
J4
Figure 4. Card Layout
Type
LED signal to control front panel LEDs to reflect
the faulty drive.
LED signal for activity per port.
For factory and debug use.
Connection to SAS/SATA devices.
RAID Controller SASMF8I.
Table 1 describes them.
Ports 4-7
Ports 0-3
AF002652
s
Comments
11
