To enable or disable snapping:
•
Select View > Grid > Snap to Grid.
To change grid settings:
Select View > Grid > Grid Settings.
1
The Grid Settings dialog box appears.
Set options as desired.
2
For more information, click the Help button in the dialog box.
Click OK.
3
Related topics
•
"Resizing layers" on page 157
•
"Moving layers" on page 158
•
"Aligning layers" on page 158

Using a tracing image

You can use a tracing image as a guide to re-create a page design that was created in a graphics
application such as Macromedia Freehand or Fireworks.
A tracing image is a JPEG, GIF, or PNG image that is placed in the background of the Document
window. You can hide the image, set its opacity, and change its position.
To place a tracing image in the Document window:
Do one of the following:
1
Select View > Tracing Image > Load.
Select Modify > Page Properties, then click the Browse button next to the Tracing
Image text box.
In the dialog box that appears, select an image file, then click Select (Windows) or
2
Choose (Macintosh).
The Page Properties dialog box appears.
Specify the transparency for the image by dragging the Image Transparency slider, then
3
click OK.
To switch to another tracing image or change the transparency of the current tracing image at any
time, select Modify > Page Properties.

Using a tracing image

161
