Web – Click VLAN, 802.1Q VLAN, Static List. To create a new VLAN, enter the
VLAN ID and VLAN name, mark the Enable checkbox to activate the VLAN, and
then click Add.
CLI – This example creates a new VLAN.
Console(config)#vlan database
Console(config-vlan)#vlan 2 name R&D media ethernet state active
Console(config-vlan)#end
Console#show vlan
Vlan ID:
Type:
Name:
Status:
Ports/Port channel:
5(S)
10(S)
15(S)
20(S)
25(S)
Vlan ID:
Type:
Name:
Status:
Ports/Port Channel:
Console#

Adding Static Members to VLANs (VLAN Index)

Use the VLAN Static Table to configure port members for the selected VLAN index.
Assign ports as tagged if they are connected to 802.1Q VLAN compliant devices, or
untagged they are not connected to any VLAN-aware devices. Or configure a port
as forbidden to prevent the switch from automatically adding it to a VLAN via the
GVRP protocol.
Notes: 1.
You can also use the VLAN Static Membership by Port page to configure
VLAN groups based on the port index (page 3-131). However, note that this
configuration page can only add ports to a VLAN as tagged members.

Figure 3-74 Configuring a VLAN Static List

1
Static
DefaultVlan
Active
Eth1/ 1(S) Eth1/ 2(S) Eth1/ 3(S) Eth1/ 4(S) Eth1/
Eth1/ 6(S) Eth1/ 7(S) Eth1/ 8(S) Eth1/ 9(S) Eth1/
Eth1/11(S) Eth1/12(S) Eth1/13(S) Eth1/14(S) Eth1/
Eth1/16(S) Eth1/17(S) Eth1/18(S) Eth1/19(S) Eth1/
Eth1/21(S) Eth1/22(S) Eth1/23(S) Eth1/24(S) Eth1/
Eth1/26(S)
2
Static
R&D
Active
VLAN Configuration
4-167
4-168
4-175
3-129
