Summary of Contents for TP-Link TL-SG2216
- Page 1 TL-SG2216/TL-SG2424 Gigabit Smart Switch Rev: 1.0.0 1910010667...
- Page 2 Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
-
Page 3: Table Of Contents
CONTENTS Preface ......................1 Chapter 1 Using the CLI ..................3 1.1 Accessing the CLI......................3 1.2 CLI Command Modes......................4 1.3 Security Levels ........................6 1.4 Conventions ........................7 1.4.1 Format Conventions ....................7 1.4.2 Special Characters ....................7 1.4.3 Parameter Format....................7 Chapter 2 User Interface ..................8 enable............................8 enable password ........................8 disable .............................9... - Page 4 show interface link-aggregation.....................19 Chapter 5 User Manage Commands..............20 user add ..........................20 user remove ..........................21 user modify status .........................21 user modify type ........................22 user modify password......................22 user access-control disable ....................23 user access-control ip-based....................23 user access-control mac-based.....................24 user access-control port-based .....................24 user max-number ........................25 user idle-timeout ........................25 show user account-list ......................26...
- Page 5 system-time dst predefined ....................40 system-time dst date ......................41 system-time dst recurring ......................42 ip address..........................43 ip management-vlan ......................43 ip dhcp-alloc ..........................44 ip bootp-alloc .........................44 reset ............................45 reboot ............................45 user-config backup ........................45 user-config load........................46 user-config save ........................46 firmware upgrade ........................47 ping ............................47 tracert ............................48 loopback ..........................49 show system-info........................49...
- Page 6 show interface status......................59 show interface counters......................60 show storm-control ethernet ....................60 show port rate-limit ........................61 Chapter 10 QoS Commands................. 62 qos ............................62 qos dot1p config ........................62 qos dscp enable ........................63 qos dscp config ........................64 qos scheduler ........................65 show qos port-based ......................66 show qos dot1p ........................66 show qos dscp........................66 show qos scheduler.......................67...
- Page 7 show spanning-tree msti config .....................81 show spanning-tree msti port ....................82 show spanning-tree security tc-defend ..................82 show spanning-tree security port-defend................83 Chapter 14 IGMP Commands................84 igmp-snooping global ......................84 igmp-snooping config ......................84 igmp-snooping vlan-config-add .....................85 igmp-snooping vlan-config.....................86 igmp-snooping multi-vlan-config....................87 igmp-snooping static-entry-add .....................88 igmp-snooping filter-add ......................89 igmp-snooping filter-config ....................89 igmp-snooping filter .......................90...
- Page 8 snmp-rmon event owner......................105 snmp-rmon event enable.....................105 snmp-rmon alarm config......................106 snmp-rmon alarm owner......................107 snmp-rmon alarm enable.....................108 show snmp global-config .....................108 show snmp view ........................109 show snmp group ........................109 show snmp user ........................109 show snmp community ......................110 show snmp destination-host ....................110 show snmp-rmon history .....................
-
Page 9: Preface
Preface This Guide is intended for network administrator to provide referenced information about CLI (Command Line Interface). The device mentioned in this Guide stands for TL-SG2216/TL-SG2424 Gigabit Smart Switch. Overview of this Guide Chapter 1: Using the CLI Provide information about how to use the CLI, CLI Command Modes, Security Levels and some Conventions. - Page 10 Chapter 13: MSTP Commands Provide information about the commands used for configuring the MSTP (Multiple Spanning Tree Protocol). Chapter 14: IGMP Commands Provide information about the commands used for configuring the IGMP Snooping (Internet Group Management Protocol Snooping). Chapter 15: SNMP Commands Provide information about the commands used for configuring the SNMP (Simple Network Management Protocol) functions.
-
Page 11: Chapter 1 Using The Cli
Chapter 1 Using the CLI 1.1 Accessing the CLI You can log on to the switch and access the CLI by logging on to the switch remotely by a Telnet through an Ethernet port. To log on to the switch by a Telnet connection, please take the following steps: Make sure the switch and the PC are in the same LAN. -
Page 12: 1.2 Cli Command Modes
Type telnet 192.168.0.1 in the command prompt shown as Figure 1-3, and press the Enter button. Figure 1-3 Connecting to the Switch Type the User name and Password (the factory default value for both of them is admin) and press the Enter button, then you can use the CLI now, which is shown as Figure1-4. Figure 1-4 Log in the Switch 1.2 CLI Command Modes The CLI is divided into different command modes: User EXEC Mode, Privileged EXEC Mode,... - Page 13 Prompt mode Primary mode once it Use the exit command to disconnect User EXEC is connected with the the switch TP-LINK> switch. Use the enable command to access Mode Privileged EXEC mode. enable Use the exit command to disconnect command to enter this...
-
Page 14: 1.3 Security Levels
Global Configuration Mode: In this mode, global commands are provided, such as the Spanning Tree, Schedule Mode and so on. Interface Configuration Mode: In this mode, users can configure one or several ports, different ports corresponds to different commands a). -
Page 15: 1.4 Conventions
1.4 Conventions 1.4.1 Format Conventions The following conventions are used in this Guide: Items in square brackets [ ] are optional Items in braces { } are required Alternative items are grouped in braces and separated by vertical bars. For example: speed ... -
Page 16: Chapter 2 User Interface
—— super password，which can contains 16 characters at most, composing digits, English letters and underdashes only. By default, it is empty. Command Mode Global Configuration Mode Example Set the super password as admin to access Privileged EXEC Mode from User EXEC Mode: TP-LINK(config)# enable password admin... -
Page 17: Disable
EXEC Mode. Syntax disable Command Mode Privileged EXEC Mode Example Return to User EXEC Mode from Privileged EXEC Mode: TP-LINK# disable TP-LINK> configure Description The configure command is used to access Global Configuration Mode from Privileged EXEC Mode. Syntax configure... -
Page 18: End
Any Configuration Mode Example Return to Global Configuration Mode from Interface Configuration Mode, and then return to Privileged EXEC Mode: TP-LINK(config-if)# exit TP-LINK(config)#exit TP-LINK# Description The end command is used to return to Privileged EXEC Mode. Syntax Command Mode Any Configuration Mode... -
Page 19: Ieee 802.1Q Vlan Commands
Syntax vlan database Command Mode Global Configuration Mode Example Access VLAN Configuration Mode: TP-LINK(config)# vlan database TP-LINK(config-vlan)# vlan Description The vlan command is used to create IEEE 802.1Q VLAN. To delete the IEEE 802.1Q VLAN, please use no vlan command. -
Page 20: Interface Vlan
——VLAN ID, ranging from 1 to 4094. Command Mode Global Configuration Mode Example Configure the VLAN 2: TP-LINK(config)# interface vlan 2 description Description The description command is used to assign a description string to a VLAN. To clear the description, please use no description command. -
Page 21: Switchport Type
Command Mode Interface Configuration Mode ( interface ethernet / interface range ethernet ) Example Specify the Link Type of port 5 as general: TP-LINK(config)# interface ethernet 5 TP-LINK(config-if)#switchport type general switchport allowed vlan Description The switchport allowed vlan command is used to add the desired port to IEEE 802.1Q VLAN, or to remove a port from the corresponding VLAN. -
Page 22: Switchport Pvid
TP-LINK(config-if)# switchport allowed vlan add 2 switchport pvid Description The switchport pvid command is used to configure the PVID for the switch ports. Syntax switchport pvid vlan-id Parameter vlan-id —— VLAN ID, ranging from 1 to 4094. Command Mode Interface Configuration Mode (interface ethernet / interface range ethernet ) -
Page 23: Show Vlan
Command Mode Any Configuration Mode Example Display the information of vlan 5: TP-LINK(config)# show vlan 5 show interface switchport Description The show interface switchport command is used to display the IEEE 802.1Q VLAN configuration information of the specified port or all ports. -
Page 24: Chapter 4 Lag Commands
Command Mode Global Configuration Mode Example Access the Interface Link-aggregation Mode and configure the aggregation group 1: TP-LINK(config)# interface link-aggregation 1 TP-LINK(config-if)# interface range link-aggregation Description The interface range link-aggregation command is used to access the Interface range Link-aggregation Mode, and you can configure some aggregation groups at the same time. -
Page 25: Link-Aggregation
——The aggregation group list. You can configure some aggregation groups at the same time. Example Access the Interface range Link-aggregation Mode and configure the aggregation group 1,4-6: TP-LINK(config)# interface range link-aggregation 1,4-6 TP-LINK(config-if)# link-aggregation Description The link-aggregation command is used to add the current Ethernet port to an aggregation group. -
Page 26: Link-Aggregation Hash-Algorithm
Command Mode Global Configuration Mode Example Configure the Aggregate Arithmetic for LAG as src_dst_mac: TP-LINK(config)# link-aggregation hash-algorithm src_dst_mac description Description The description command is used to set a description for an aggregation group. To remove the description of an aggregation group, please use no description command. -
Page 27: Show Interface Link-Aggregation
TP-LINK(config)# interface link-aggregation 1 TP-LINK(config-if)# description movie server show interface link-aggregation Description The show interface link-aggregation command is used to display the configuration information of the Aggregate Arithmetic and the aggregation groups. Syntax show interface link-aggregation [group-num] Parameter group-num ——The LAG number, ranging from1 to 6. By default, the LAG configuration information of all the Ethernet ports is displayed. -
Page 28: Chapter 5 User Manage Commands
Admin: can edit, modify and view all the settings of different functions. disable | enable ——Enable/disable the user. Command Mode Global Configuration Mode Example Add and enable a new admin user named tplink, and of which the password is password: TP-LINK(config)#user add tplink password password confirm-password password admin enable... -
Page 29: User Remove
The current user can't be modified by itself. Syntax user modify status user-name {disable | enable} Parameter user-name —— The existing user name. disable | enable ——Disable/enable the user. Command Mode Global Configuration Mode Example Enable the status of user “tplink”: TP-LINK(config)# user modify status tplink enable... -
Page 30: User Modify Type
Command Mode Global Configuration Mode Example Change the access level of tplink to admin: TP-LINK(config)# user modify type tplink admin user modify password Description The user modify password command is used to modify the password for the existing user. -
Page 31: User Access-Control Disable
Command Mode Global Configuration Mode Example Modify the password of tplink as newpwd: TP-LINK(config)# user modify password tplink password newpwd newpwd user access-control disable Description The user access-control disable command is used to cancel the user access-control. Syntax user access-control disable... -
Page 32: User Access-Control Mac-Based
00:00:13:0A:00:01: TP-LINK(config)# user access-control mac-based 00:00:13:0A:00:01 user access-control port-based Description The user access-control port-based command is used to limit the ports for login. Only the users connected to these ports you set here are allowed for login. -
Page 33: User Max-Number
Global Configuration Mode Example Enable the access-control of the port 2, port 4, port 5, port 6,and port 10: TP-LINK(config)# user access-control port-based 2,4-6,10 user max-number Description The user max-number command is used to configure the number of the users logging on at the same time. -
Page 34: Show User Account-List
10. Command Mode Global Configuration Mode Example Configure the timeout time of the switch as 15 minutes: TP-LINK(config)# user idle-timeout 15 show user account-list Description The show user account-list command is used to display the information of the current users. - Page 35 Command Mode Any Configuration Mode Example Display the security configuration information of the users: TP-LINK(config)# show user configuration...
-
Page 36: Chapter 6 Log Commands
By default, it is 7 indicating that all the log information will be saved in the log buffer. disable | enable —— Disable or enable the log buffer. By default, it is enabled. Command Mode Global Configuration Mode Example Enable the log buffer function and set the severity as 6: TP-LINK(config)# logging local buffer 6 enable... -
Page 37: Logging Local Flash
Command Mode Global Configuration Mode Example Enable the log file function and set the severity as 7: TP-LINK(config)# logging local flash 7 logging clear Description The logging clear command is used to clear the information in the log buffer and log file. -
Page 38: Logging Loghost
| enable ——Disable or enable the log host. By default, it is disabled. Command Mode Global Configuration Mode Example Enable the log host 2 and set the IP address 192.168.0.148, the level 5: TP-LINK(config)# logging loghost index 2 192.168.0.148 5 enable... -
Page 39: Show Logging Local-Config
——The index of the log host whose configuration will be displayed. Display the configuration of all the log hosts by default. Command Mode Any Configuration Mode Example Display the configuration of the log host 2: TP-LINK(config)# show logging loghost 2... -
Page 40: Show Logging Buffer Level
Any Configuration Mode Example Display the log information from level 0 to level 5 in the log buffer: TP-LINK(config)# show logging buffer level 5 show logging flash level Description The show logging flash level command is used to display the log information in the log file according to the severity level. - Page 41 Display the log information with the level marked 0~3 in the log file: TP-LINK(config)# show logging flash level 3...
-
Page 42: Chapter 7 Address Commands
Chapter 7 Address Commands Address configuration can improve the network security by configuring the Port Security and maintaining the address information by managing the Address Table. bridge address port-security Description The bridge address port-security command is used to configure port security. To return to the default configuration, please use no bridge address port-security command. -
Page 43: Bridge Address Static
—— The Port number of your desired entry. Command Mode Global Configuration Mode Example Add a static Mac address entry to bind the MAC address 00:02:58:4f:6c:23, VLAN1 and Port1 together: TP-LINK(config)# bridge address static mac 00:02:58:4f:6c:23 vid 1 port 1... -
Page 44: Bridge Aging-Time
Command Mode Global Configuration Mode Example Configure the aging time as 500 seconds: TP-LINK(config)# bridge aging-time 500 bridge address filtering Description The bridge address filtering command is used to add the filtering address entry. To delete the corresponding entry, please use no bridge address filtering command. -
Page 45: Show Bridge Port-Security
Global Configuration Mode Example Add a filtering address entry whose VLAN ID is 1 and MAC address 00:1e:4b:04:01:5d: TP-LINK(config)# bridge address filtering 00:1e:4b:04:01:5d 1 show bridge port-security Description The show bridge port-security command is used to configure the Port Security for each port, such as configure the Max number of MAC addressed that can be learned on the port and the Learn Mode. -
Page 46: Show Bridge Aging-Time
Example Display the information of all Address entries: TP-LINK(config)# show bridge address all show bridge aging-time Description The show bridge aging-time command is used to display the Aging Time of the MAC address. Syntax show bridge aging-time Command Mode Any Configuration Mode... -
Page 47: Chapter 8 System Commands
—— Contact Information. It consists of 32 characters at most. By default, it is empty. Command Mode Global Configuration Mode Example Configure the System Contact as www.tp-link.com.cn: TP-LINK(config)# system-descript contact-info www.tp-link.com.cn system-time manual Description The system-time manual command is used to configure the system time manually. -
Page 48: System-Time Dst Predefined
Command Mode Global Configuration Mode Example Configure the system mode as manual, and the time is 12/20/2010 17:30:35 TP-LINK(config)# system-time manual 12/20/2010-17:30:35 system-time dst predefined Description The system-time dst predefined command is used to select a daylight saving time configuration from the predefined mode. The configuration can be used recurrently. -
Page 49: System-Time Dst Date
Example Configure the daylight saving time as USA standard: TP-LINK(config)#system-time dst predefined USA system-time dst date Description The system-time dst date command is used to configure the one-off daylight saving time. The start date is in the current year by default. The time range of the daylight saving time must shorter than one year, but you can configure it spanning years. -
Page 50: System-Time Dst Recurring
30 minutes: TP-LINK(config)# system-time dst date Apr 1 00:00 Oct 1 00:00 30 system-time dst recurring Description The system-time dst recurring command is used to configure the recurring daylight saving time. It can be configured spanning years. To disable DST function, please use no system-time dst command. -
Page 51: Ip Address
Configure the daylight saving time from 2:00am, the first Sunday of May to 2:00am, the last Sunday of Oct and the offset is 45 minutes: TP-LINK(config)# system-time dst recurring first Sun May 02:00 last Sun Oct 02:00 45 ip address... -
Page 52: Ip Dhcp-Alloc
Command Mode Global Configuration Mode Example Set the VLAN 6 as IP management VLAN: TP-LINK(config)# ip management-vlan 6 ip dhcp-alloc Description The ip dhcp-alloc command is used to enable the DHCP Client function. When this function is enabled, the switch will obtain IP from DHCP Client server. -
Page 53: Reset
Syntax reset Command Mode Privileged EXEC Mode Example Reset the software of the Switch: TP-LINK# reset reboot Description The reboot command is used to reboot the Switch. To avoid damage, please don’t turn off the device while rebooting. Syntax reboot... -
Page 54: User-Config Load
Privileged EXEC Mode Example Backup the configuration files by TFTP server with the IP 192.168.0.148 and name this file config.cfg: TP-LINK# user-config backup filename config.cfg ip-address 192.168.0.148 user-config load Description The user-config load command is used to download the configuration file to the switch by TFTP server. -
Page 55: Firmware Upgrade
Command Mode Privileged EXEC Mode Example Upgrade the switch system via the TFTP server with the IP 192.168.0.148: TP-LINK# firmware upgrade filename firmware.bin ip-address 192.168.0.148 ping Description The ping command is used to test the connectivity between the switch and one node of the network. -
Page 56: Tracert
192.168.0.131, please specify the count (-l) as 512 bytes and count (-i) as 1000 milliseconds. If there is not any response after 8 times’ Ping test, the connection between the switch and the network device is failed to establish: TP-LINK# ping 192.168.0.131 –n 8 –l 512 tracert Description The tracert command is used to test the connectivity of the gateways during its journey from the source to destination of the test data. -
Page 57: Loopback
Command Mode User EXEC Mode and Privileged EXEC Mode Example Do a Internal-type loopback test for port 4: TP-LINK# loopback 4 internal show system-info Description The show system-info command is used to display System Description, Device Name, Device Location, System Contact, Hardware Version, Firmware Version, System Time, Run Time and so on. -
Page 58: Show System-Time
Syntax show ip address Command Mode Any Configuration Mode Example Display the IP Address of the system TP-LINK# show ip address show system-time Description The show system-time command is used to display the time information of the switch. Syntax show system-time... -
Page 59: Show System-Time Source
TP-LINK# show system-time dst show system-time source Description The show system-time source command is used to display the time source of the switch. Syntax show system-time source Command Mode Any Configuration Mode Example Display the time source of the switch... -
Page 60: Chapter 9 Ethernet Configuration Commands
Command Mode Global Configuration Mode Example Enter the Interface Configuration Mode and configure Ethernet port 2: TP-LINK(config)# interface ethernet 2 interface range ethernet Description The interface range ethernet command is used to enter the Interface Configuration Mode and configure multiple Ethernet ports at the same time. -
Page 61: Description
Example Enter the Interface Configuration Mode, add ports 1-3, 6-9 to the port-list and configure them: TP-LINK(config)# interface range ethernet 1-3,6-9 description Description The description command is used to add a description to the Ethernet port. To clear the description of the corresponding port, please use no description command. -
Page 62: Flow-Control
Command Mode Interface Configuration Mode（interface ethernet / interface range ethernet） Example Disable Ethernet port 3: TP-LINK(config)# interface ethernet 3 TP-LINK(config-if)# shutdown flow-control Description The flow-control command is used to enable the flow-control function for a port. To disable the flow-control function for this corresponding port, please use no flow-control command. -
Page 63: Storm-Control
Command Mode Interface Configuration Mode（interface ethernet / interface range ethernet） Example Configure the Negotiation Mode as 100M full-duplex for Ethernet port 5: TP-LINK(config)# interface ethernet 5 TP-LINK(config-if)# negotiation 100f storm-control Description The storm-control command is used to configure the Storm Control function. -
Page 64: Storm-Control Disable Bc-Rate
Enable the Storm Control function for port 5 and specify the bc-rate as 128kbps, mc-rate as 512kbps and ul-rate as 2Mbps: TP-LINK(config)# interface ethernet 5 TP-LINK(config-if)# storm-control bc-rate 128k mc-rate 512k ul-rate 2m storm-control disable bc-rate Description The storm-control disable bc-rate command is used to disable the Broadcast packets control. -
Page 65: Storm-Control Disable Ul-Rate
TP-LINK(config)# interface ethernet 5 TP-LINK(config-if)# storm-control disable mc-rate storm-control disable ul-rate Description The storm-control disable ul-rate command is used to disable the UL-Frame control. Syntax storm-control disable ul-rate Command Mode Interface Configuration Mode（interface ethernet / interface range ethernet） Example Disable the UL-Frame control for port 5:... -
Page 66: Port Rate-Limit Disable Ingress
Example Configure the ingress-rate as 1Mbps and egress-rate as 10Mbps for port 5: TP-LINK(config)# interface ethernet 5 TP-LINK(config-if)# port rate-limit ingress 1024 egress 10240 port rate-limit disable ingress Description The port rate-limit disable ingress command is used to disable the ingress-rate limit. -
Page 67: Show Interface Configuration
Command Mode Any Configuration Mode Example Display the configurations of port 5: TP-LINK# show interface configuration ethernet 5 show interface status Description The show interface status command is used to display the connective-status of an Ethernet port or all Ethernet ports. -
Page 68: Show Interface Counters
Command Mode Any Configuration Mode Example Display the statistic information of Ethernet port 3: TP-LINK(config)# show interface counters ethernet 3 show storm-control ethernet Description The show storm-control ethernet command is used to display the storm-control information of an Ethernet port or all Ethernet ports. -
Page 69: Show Port Rate-Limit
Parameter port —— The port number selected to display the rate-limit information. By default, the rate-limit information of all ports is displayed. Command Mode Any Configuration Mode Example Display the rate-limit information of all Ethernet ports: TP-LINK(config)# show port rate-limit... -
Page 70: Chapter 10 Qos Commands
CoS value of the ingress port and the mapping relation between the CoS and TC in IEEE 802.1P. Example Configure the priority of port 5 as 3: TP-LINK(config)# interface ethernet 5 TP-LINK(config-if)# qos 3 qos dot1p config Description The qos dot1p config command is used to configure the mapping relation between IEEE 802.1P Priority and Egress Queue. -
Page 71: Qos Dscp Enable
Among the priority levels TC0-TC3, the bigger value, the higher priority. Example Map tag value 0 to TC3: TP-LINK(config)# qos dot1p config 0 3 qos dscp enable Description The qos dscp enable command is used to enable the mapping relation between DSCP Priority and Egress Queue. -
Page 72: Qos Dscp Config
DSCP priorities are mapped to the corresponding 802.1p priorities. IP datagram will determine its egress queue based on the mapping relation between 802.1p priority and priority levels. Example Map DSCP values 10,11,15 to CoS0: TP-LINK(config)# qos dscp config 10,11,15 0... -
Page 73: Qos Scheduler
—— Equal-Mode. In this mode, all the queues occupy the bandwidth equally. The weight value ratio of all the queues is 1:1:1:1. Command Mode Global Configuration Mode Example Specify the Schedule Mode as Weight Round Robin Mode: TP-LINK(config)# qos scheduler wrr... -
Page 74: Show Qos Port-Based
Command Mode Any Configuration Mode Example Display the configuration of QoS for port 5: TP-LINK# show qos port-based 5 show qos dot1p Description The show qos dot1p command is used to display the configuration of IEEE 802.1P Priority. -
Page 75: Show Qos Scheduler
Command Mode Any Configuration Mode Example Display the configuration of DSCP Priority: TP-LINK# show qos dscp show qos scheduler Description The show qos scheduler command is used to display the schedule rule of the egress queues. Syntax... -
Page 76: Chapter 11 Port Mirror Commands
Configure port 3 as mirrored port, port 4 as mirroring port, the mirror mode as both and group number as 1 : TP-LINK(config)# mirror add 3 4 both 1 User Guidelines The mirroring port is corresponding to current interface configuration mode. -
Page 77: Mirror Remove Group
{mirrored port} {group-num} Parameter mirrored port —— The port to be monitored. group-num —— The group number of mirrior group. Command Mode Global Configuration Mode Example Remove mirrored port 1,2-4 from mirror group 1: TP-LINK(config)# mirror remove mirrored 1,2-4 1... -
Page 78: Show Mirror
The show mirror command is used to display the configuration of a specified mirror group or all mirror groups. Syntax show mirror [group-num] Parameter group-num —— The group number of mirrior group. Command Mode Any Configuration Mode Example Display configuration of mirror group 1: TP-LINK# show mirror 1... -
Page 79: Chapter 12 Port Isolation Commands
Command Mode Interface Configuration Mode Example Configure port 1 and port 2 can only forward packets to port 6 and port 13: TP-LINK(config)# interface range ethernet 1-2 TP-LINK(config-if)# port isolation 6,13 show port isolation Description The show port isolation command is used to display the forward portlist of a port or all ports. - Page 80 Example Display the forward-list of port 6: TP-LINK# show port isolation 6...
-
Page 81: Chapter 13 Mstp Commands
Chapter 13 MSTP Commands MSTP (Multiple Spanning Tree Protocol), compatible with both STP and RSTP and subject to IEEE 802.1s, can disbranch a ring network. STP is to block redundant links and backup links as well as optimize paths. spanning-tree global Description The spanning-tree global command is used to configure STP globally. -
Page 82: Spanning-Tree Common-Config
4096, Hello Time as 4 seconds, Max Age as 10 seconds, Forward Delay as 10 seconds, TxHold Count as 8pps and Max Hops as 15 hops: TP-LINK(config)# spanning-tree global status enable mode mstp cist 4096 htime 4 mage 10 delay 10 hcount 8 mhop 15... -
Page 83: Spanning-Tree Region
Enable the STP function of port 1, and configure the Port Priority as 64, ExtPath Cost as 100, IntPath Cost as 100, and then enable Edge Port: TP-LINK(config)# interface ethernet 1 TP-LINK(config-if)# spanning-tree common-config status enable pri 64 expath 100 inpath 100 edge enable spanning-tree region Description The spanning-tree region command is used to configure the region of MSTP. -
Page 84: Spanning-Tree Msti
Command Mode Global Configuration Mode Example Configure the region name of MSTP as r1, and the revision level as 100: TP-LINK(config)# spanning-tree region r1 100 spanning-tree msti Description The spanning-tree msti command is used to configure MSTP Instance. To return to the default configuration of the corresponding Instance, please use no spanning-tree msti command. -
Page 85: Spanning-Tree Msti
Example Enable Instance 1, add VLAN 2, 3, 4, 5, 8 for it, and configure MSTI Priority as 4096: TP-LINK(config)# spanning-tree msti 1 status enable pri 4096 mapped 2-5,8 spanning-tree msti Description The spanning-tree msti command is used to configure MSTP Instance Port. To return to the default configuration of the corresponding Instance Port, please use no spanning-tree msti command. -
Page 86: Spanning-Tree Tc-Defend
Command Mode Global Configuration Mode Example Configure TC Threshold as 30 packets, and TC Protect Cycle as 10 seconds: TP-LINK(config)# spanning-tree tc-defend threshold 30 period 10 spanning-tree security Description The spanning-tree security command is used to configure MSTP Port Protect. -
Page 87: Spanning-Tree Mcheck
Example Enable Loop Protect, Root Protect, TC Protect, BPDU Protect, and BPDU Filter for port 2: TP-LINK(config)# interface ethernet 2 TP-LINK(config-if)# spanning-tree security loop enable root enable TC enable defend enable hold enable spanning-tree mcheck Description The spanning-tree mcheck command is used to enable MCheck. -
Page 88: Show Spanning-Tree Global-Info
Command Mode Any Configuration Mode Example Display the current status of Spanning Tree: TP-LINK# show spanning-tree global-info show spanning-tree global-config Description The show spanning-tree global-config command is used to display the global configuration of Spanning Tree. Syntax... -
Page 89: Show Spanning-Tree Region
Command Mode Any Configuration Mode Example Display the configuration of port 5: TP-LINK(config)# show spanning-tree port-config 5 show spanning-tree region Description The show spanning-tree region command is used to display the Region configuration of MSTP. -
Page 90: Show Spanning-Tree Msti Port
Command Mode Any Configuration Mode Example Display the configuration of port 5 in Instance 1: TP-LINK(config)# show spanning-tree msti port 1 5 show spanning-tree security tc-defend Description The show spanning-tree security tc-defend command is used to display TC Threshold and TC Protect Cycle of Spanning Tree. -
Page 91: Show Spanning-Tree Security Port-Defend
—— The port selected to display the configuration. By default, the Port Protect configuration of all ports is displayed. Command Mode Any Configuration Mode Example Display the Port Protect configuration of port 2: TP-LINK(config)# show spanning-tree security port-defend 2... -
Page 92: Chapter 14 Igmp Commands
Command Mode Global Configuration Mode Example Enable IGMP Snooping function, and specify the operation to process unknown multicast as discard: TP-LINK(config)# igmp-snooping global status enable unknown-packet discard igmp-snooping config Description The igmp-snooping config command is used to configure IGMP Snooping and Fast Leave function for port. -
Page 93: Igmp-Snooping Vlan-Config-Add
Interface Configuration Mode（interface ethernet / interface range ethernet） Example Enable IGMP Snooping and Fast Leave function for port 5: TP-LINK(config)# interface ethernet 5 TP-LINK(config-if)# igmp-snooping config status enable fast-leave enable igmp-snooping vlan-config-add Description The igmp-snooping vlan-config-add command is used to configure IGMP Snooping parameters for individual VLANs. -
Page 94: Igmp-Snooping Vlan-Config
Enable IGMP Snooping for VLAN 1, and configure Router Port Time as 200 seconds, Member Port Time as 100 seconds, Leave time as 10 seconds and Static Router Port as port 1: TP-LINK(config)# igmp-snooping vlan-config-add 1 rtime 200 mtime 100 ltime 10 rport 1 igmp-snooping vlan-config... -
Page 95: Igmp-Snooping Multi-Vlan-Config
Example Modify Router Port Time as 300 seconds, Member Port Time as 200 seconds, and Leave time as 15 seconds for VLAN 1: TP-LINK(config)# igmp-snooping vlan-config 1 rtime 300 mtime 200 ltime 15 igmp-snooping multi-vlan-config Description The igmp-snooping multi-vlan-config command is used to create Multicast VLAN. -
Page 96: Igmp-Snooping Static-Entry-Add
Example Enable Multicast VLAN, and configure Router Port Time as 300 seconds, Member Port Time as 200 seconds, and Leave time as 15 seconds for VLAN 2: TP-LINK(config)# igmp-snooping multi-vlan-config enable 2 rtime 300 mtime 200 ltime 15 igmp-snooping static-entry-add... -
Page 97: Igmp-Snooping Filter-Add
Example Add static multicast IP address 225.0.0.1, which correspond to VLAN 2, and configure the forward port as port 1: TP-LINK(config)# igmp-snooping static-entry-add 225.0.0.1 2 1 igmp-snooping filter-add Description The igmp-snooping filter-add command is used to configure the multicast IP-range desired to filter. To delete the corresponding IP-range, please use no igmp-snooping filter-add command. -
Page 98: Igmp-Snooping Filter
Command Mode Global Configuration Mode Example Modify the multicast IP-range whose ID is 20 as 225.0.0.10~225.0.0.12: TP-LINK(config)# igmp-snooping filter-config 20 225.0.0.10 225.0.0.12 igmp-snooping filter Description The igmp-snooping filter command is used to configure Port Filter. To return to the default configuration, please use no igmp-snooping filter command. When... -
Page 99: Show Igmp-Snooping Global-Config
IP-range 2, 3, 4, and specify the maximum number of multicast groups for port 5 to join in as 128: TP-LINK(config)# interface ethernet 5 TP-LINK(config-if)# igmp-snooping filter status enable mode accept addr-id 2-4 maxgroup 128 show igmp-snooping global-config Description The show igmp-snooping global-config command is used to display the global configuration of IGMP. -
Page 100: Show Igmp-Snooping Vlan-Config
Command Mode Any Configuration Mode Example Display the IGMP configuration of port 2: TP-LINK> show igmp-snooping port-config 2 show igmp-snooping vlan-config Description The show igmp-snooping vlan-config command is used to display the VLAN configuration of IGMP. Syntax show igmp-snooping vlan-config... -
Page 101: Show Igmp-Snooping Multi-Ip-List
Syntax show igmp-snooping multi-ip-list Command Mode Any Configuration Mode Example Display the Multicast IP table: TP-LINK> show igmp-snooping multi-ip-list show igmp-snooping filter-ip-addr Description The show igmp-snooping filter-ip-addr command is used to display the Multicast Filter IP-Range table. Syntax show igmp-snooping filter-ip-addr... -
Page 102: Show Igmp-Snooping Packet-Stat
By default, the configuration of all ports is displayed. Command Mode Any Configuration Mode Example Display the Multicast Filter configuration of port 5: TP-LINK> show igmp-snooping port-filter 5 show igmp-snooping packet-stat Description The show igmp-snooping packet-stat command is used to display the Packet Statistics information of all ports. -
Page 103: Chapter 15 Snmp Commands
64 hexadecimal characters, which must be even number meanwhile. Command Mode Global Configuration Mode Example Enable the SNMP function, and specify the Local Engine ID as 1234567890, the Remote Engine ID as 123456abcdef: TP-LINK(config)# snmp global status enable engine-id 1234567890 remote-id 123456abcdef... -
Page 104: Snmp View-Add
Example Add a View named view1, configuring the OID as 1.3.6.1.6.3.20, and this OID can be managed by the SNMP management station: TP-LINK(config)# snmp view-add view1 1.3.6.1.6.3.20 include snmp group-add Description The snmp group-add command is used to manage and configure the SNMP group. -
Page 105: Command Mode
privacy mode guarantee the high security for the communication between the management station and the managed device. Syntax snmp group-add {name} [smode { v1 | v2c | v3 }] [slev { noAuthNoPriv | authNoPriv | authPriv }] [ro ro-view] [wo wo-view] [inform inform-view] no snmp group-add {name} {smode { v1 | v2c | v3 }} {slev { noAuthNoPriv | authNoPriv | authPriv }} Parameter... -
Page 106: Snmp User-Add
TP-LINK(config)# snmp group-add group1 smode v2c ro view1 wo view1 inform view2 snmp user-add Description The snmp user-add command is used to add User. To delete the corresponding User, please use no snmp user-add command. The User in a SNMP Group can manage the switch via the management station software. The User and its Group have the same security level and access right. -
Page 107: Snmp Community-Add
MD5, the Authentication Password as 11111, the Privacy Mode as DES, and the Privacy Password as 22222: TP-LINK(config)# snmp user-add admin local group2 smode v3 slev authPriv cmode MD5 cpwd 11111 emode DES epwd 22222 snmp community-add Description The snmp community-add command is used to add Community. -
Page 108: Snmp Notify-Add
Example Add Community community1, and the community has read-write management right to View view1: TP-LINK(config)# snmp community-add community1 read-write view1 snmp notify-add Description The snmp notify-add command is used to add Notification. To delete the corresponding Notification, please use no snmp notify-add command. With the... -
Page 109: Snmp-Rmon History Sample-Cfg
Security Model of the management station as v2c, the type of the notifications as inform, the maximum time for the switch to wait as 1000 seconds, and the resending time as 100: TP-LINK(config)# snmp notify-add 192.168.0.1 162 admin smode v2c type inform resend 100 timeout 1000 snmp-rmon history sample-cfg... -
Page 110: Snmp-Rmon History Owner
Example Configure the sample port as 1, and the sample interval as 100 seconds for the entries 1-3: TP-LINK(config)# snmp-rmon history sample-cfg 1-3 1 100 snmp-rmon history owner Description The snmp-rmon history owner command is used to configure the owner of the history sample entry. -
Page 111: Snmp-Rmon Event User
—— The name of the User to which the event belongs, ranging from 1 to 16 characters. By default, it is public. Command Mode Global Configuration Mode Example Configure the user name of entry 1 as user1: TP-LINK(config)# snmp-rmon event user 1 user1 snmp-rmon event description Description... -
Page 112: Snmp-Rmon Event Type
Command Mode Global Configuration Mode Example Configure the description of entry 1 as description1: TP-LINK(config)# snmp-rmon event description 1 description1 snmp-rmon event type Description The snmp-rmon event type command is used to configure the type of SNMP-RMON Event. To return to the default configuration, please use no snmp-rmon event type command. -
Page 113: Snmp-Rmon Event Owner
Example Configure the event type of entries 1,2,3,4 and 8 as log: TP-LINK(config)# snmp-rmon event type 1-4,8 log snmp-rmon event owner Description The snmp-rmon event owner command is used to configure the owner of SNMP-RMON Event. To return to the default configuration, please use no snmp-rmon event owner command. -
Page 114: Snmp-Rmon Alarm Config
Command Mode Global Configuration Mode Example Enable the SNMP-RMON Event entries 1,2,3,4 and 8: TP-LINK(config)# snmp-rmon event enable 1-4,8 snmp-rmon alarm config Description The snmp-rmon alarm config command is used to configure SNMP-RMON Alarm Management. To return to the default configuration, please use no snmp-rmon alarm config command. -
Page 115: Snmp-Rmon Alarm Owner
Global Configuration Mode Example Configure the alarm interval time of the entries 1,2,3 and 6 as 1000 seconds: TP-LINK(config)# snmp-rmon alarm config 1-3,6 interval 1000 snmp-rmon alarm owner Description The snmp-rmon alarm owner command is used to configure the owner of the Alarm Management entry. -
Page 116: Snmp-Rmon Alarm Enable
Command Mode Global Configuration Mode Example Configure the owner of entry 1 as owner1: TP-LINK(config)# snmp-rmon alarm owner 1 owner1 snmp-rmon alarm enable Description The snmp-rmon alarm enable command is used to enable SNMP-RMON Alarm Management entry. To disable the corresponding entry, please use no snmp-rmon alarm enable command. -
Page 117: Show Snmp View
Example Display SNMP configuration globally: TP-LINK> show snmp global-config show snmp view Description The show snmp view command is used to display the View table. Syntax show snmp view Command Mode Any Configuration Mode Example Display the View table: TP-LINK> show snmp view... -
Page 118: Show Snmp Community
Command Mode Any Configuration Mode Example Display the User table: TP-LINK> show snmp user show snmp community Description The show snmp community command is used to display the Community table. Syntax show snmp community Command Mode Any Configuration Mode Example Display the Community table: TP-LINK>... -
Page 119: Show Snmp-Rmon Event
Command Mode Any Configuration Mode Example Display the Event configuration of entry 2: TP-LINK> show snmp-rmon event 2 show snmp-rmon alarm Description The show snmp-rmon alarm command is used to display the configuration of... - Page 120 1 to 12. You can only select one entry for each command. By default, the configuration of all entries is displayed. Command Mode Any Configuration Mode Example Display the configuration of all Alarm Management entries: TP-LINK> show snmp-rmon alarm...
Need help?
Do you have a question about the TL-SG2216 and is the answer not in the manual?
Questions and answers
