Table C-2.
EIO Graphical Control Panel Menu (3 of 5)
Menu Item
Options
MANUAL
SETTINGS
DEFAULT IP
DNS SERVER
IPX/SPX
ENABLE
ENWW
Description of settings
(Available only if CONFIG METHOD is set
to MANUAL) Configure parameters
directly from the printer control panel:
IP ADDRESS n.n.n.n: The unique IP
address of the printer, where n is a
value from 0 to 255.
SUBNET MASK m.m.m.m: The
subnet mask for the printer, where m
is a value from 0 to 255.
SYSLOG SERVER n.n.n.n: The IP
address of the syslog server used to
receive and log syslog messages.
DEFAULT GATEWAY n.n.n.n: The
IP address of the gateway or router
used for communications with other
networks.
IDLE TIMEOUT: The time period, in
seconds, after which an idle TCP print
data connection is closed (default is
270 seconds, 0 disables the timeout).
Specify the IP address to default to when
the print server is unable to obtain an IP
address from the network during a forced
TCP/IP reconfiguration (for example,
when manually configured to use BOOTP
or DHCP).
AUTO IP: A link-local IP address
169.254.x.x will be set.
LEGACY: The address 192.0.0.192
will be set consistent with older
Jetdirect products.
(620n only) Specify the IP address
(n.n.n.n) of the DNS Server.
ON: Enable the IPX/SPX protocol.
OFF: Disable the IPX/SPX protocol.
HP Jetdirect EIO Control Panel Menus 42
