Tv Matrix - Lexicon DC-1 - REV 1 Owner's Manual

DC-1 Digital Controller
The TV Matrix effect provides surround effects for television viewing of
monaural, stereo, and stereo synthesized programs.
Parameter
AUTO AZIMUTH
FRONT STEERING
REAR ROLLOFF
DOLBY B NR
RE-EQUALIZER
SIDE ASSIGN
SIDE LEVEL
SUB BASS BOOST
EFFECT LEVEL
CUSTOM
* Dependent on speaker configuration
AUTO AZIMUTH is short for auto azimuth error correction/automatic
input balance. Auto Azimuth should be set to ON for films, and OFF for
music. When ON, special patented algorithms continually monitor the
input signal and adjust both the relative level and time offset of the two
channels to keep the dialog properly centered and special effects properly
localized. This automatic feature is the reason the unit does not need an
input balance control for Dolby Surround decoding.
FRONT STEERING The essence of the TV MATRIX Effect is that dialog,
music, and surround effects are dynamically directed to the output chan-
nels, a process called steering. The FRONT STEERING control allows you
to adjust the amount of steering in the front channels. When this control is
set to FULL, the steering is identical to Dolby Pro Logic. At 1/2, steering is
reduced to accommodate the wide range of television programming. Select-
ing OFF will steer the center signal to both the left and right channels. This
parameter is automatically set to OFF for systems configured without a
center speaker.
REAR ROLLOFF sets the cutoff frequency of a low pass filter in the rear-
channel. Frequencies above this setting are attenuated. This control should
be set high enough to give presence and airiness to the rear sound without
placing distracting instrumental overtones or other sounds behind you. In
systems configured without rear speakers, the settings affect the side out-
puts.
DOLBY B NR is used in Pro Logic and THX effects for the surround channels
according to Dolby specifications. Because Dolby Surround encoded pro-
gram material is generally listened to with the unit set for Pro Logic or THX,
this parameter is normally off.
RE-EQUALIZER equalizes the left, center, and right channel outputs to
match the overall frequency balance of the original recording. Without this
re-equalization, many films and some television programs will sound too
bright.
Initial Value
ON
FULL 1/4, 1/2, Full, Off
20.0kHz 453Hz-20.0kHz
ON
OFF
SIDE Front/Side, Front/Rear*
+0dB
+3dB
+00dB
Range
ON/OFF
ON/OFF
ON/OFF
-5 to +5dB
-5 to +5dB
-30 to +05dB
DC-1Effects

TV Matrix

TV Matrix Parameters
