Specifications - Lexicon DC-1 - REV 1 Owner's Manual

DC-1 Digital Controller
Inputs:
Outputs:
Conversion:
Frequency Response:
THD+Noise:
Dynamic Range:
Signal to Noise Ratio:
Power Requirements:
Dimensions:
Weight:
Environment:
Remote Controls:
Audio: 8 stereo (RCA) pairs
Minimum Input Level: 500 mVrms for maximum output
Input Impedance:
Video: 5 composite (RCA), 3 S-video, NTSC, PAL, SECAM compatible
Input Level and Impedance: 1Vpp, 75
Digital: 4: 2 coaxial (RCA), 2 optical (TOSLINK™),
conforms to S/PDIF standard
Audio: 8 outputs:Left, Center,Right, L&R Sides, L&R Rears, Subwoofer (RCA)
Maximum Output Level: minimum 6 Vrms (System Volume=+12dB)
Output Impedance:
Video: 2 composite (RCA), 2 S-video, NTSC, PAL, SECAM compatible
Output Level and Impedance: 1V p-p, 75
A/D Conversion: 16-bit Delta-Sigma
D/A Conversion: 20-bit Delta-Sigma
10 Hz-20 kHz, +0.5dB, Ref. 1kHz
Less than 0.01% @1kHz, maximum output level
90dB minimum, 22kHz bandwidth,
Ref. 1kHz@ -60dB below maximum output level
90dB minimum, 22kHz bandwidth, Ref. 1kHz at maximum output level
100-240 VAC, 50-60Hz 35Watts (universal input)
IEC detachable power cord provided per country of destination
17.3"W x 11.5"D x 3.6"H (440 x 292 x 92mm)
19.0"W x 11.5"D x 3.5"H (483 x 292 x 89mm) with rack mounting brackets
10.5 lbs. (4.8kg)
Operating Temperature: 32° to 95°F (0° to 35°C)
Storage Temperature: -22° to 167°F (-30° to 75°C)
Relative Humidity: 95% maximum without condensation
1 hand-held, battery-powered remote control unit uses 2 AAA batteries
Specifications subject to change without notice.
200 mVrms for Dolby level (Input Gain=0dB)
100 k in parallel with 150pF
100 in parallel with 150pF
