Customization; Locking Settings; Assign Custom Name - Lexicon DC-1 - REV 1 Owner's Manual

DC-1 Digital Controller
After you have calibrated and customized the DC-1, there are two addi-
tional steps recommended to safeguard the settings. First, document your
adjustments. Second, consider locking the settings so that they cannot be
inadvertently changed. The last item in the Setup menu allows you to lock
the DC-1 settings, as well as to change the name displayed during power up.
Locking the settings allows full operation of the unit but prohibits the ability
to change effect parameters or setup values. Specifically, with the settings
locked, the unit will allow any Parameter or Setup menu to be displayed, but
attempting to select any item for adjustment will display the message:
SETTINGS ARE LOCKED.
In order to prevent accidental changes, select the SETTINGS parameter and
use MENU to select LOCKED. A higher level of security can be achieved
by simultaneously pressing the ACCY and DONE keys on the remote while
setting LOCKED to ON. To release lock, select SETTINGS and hold down
ACCY and DONE. MENU
UNLOCKED.
When the DC-1 is first turned on, it displays a copyright notice with the
current software version. You can choose to have it display CUSTOMIZED
FOR DEMONSTRATION with the word DEMONSTRATION scrolled in
from right to left.
The word DEMONSTRATION can be replaced by a custom name of as
many as 20 characters. To assign a new name, use MENU
highlight CUSTOM NAME. Press SELECT and press MENU
function ON, then press DONE.
You will return to the Lock Settings menu with ASSIGN CUSTOM NAME
highlighted. Pressing SELECT will display the current name with a cursor
indicating which character position can be modified. Use MENU
to select a new character. Use SELECT to move the cursor to a new position.
Press DONE to save the new name.
and will once again select LOCKED or
Installation and

Customization

Locking Settings

Assign Custom Name

and to
to turn this
and
Calibration
29
