Please read the installation instruction carefully. We are not
responsible for any damage or injury caused by improper
assemble or use. Any question, please contact our customer
service.
https://z.wiki
SDM001T
User Manual
after-sales@suptekmount.com
Warning
Parts
A-Supporting pole(2)
B-Base(2)
Screw package
E-S3/S5(1)
D-M5*18(6)
H-M8 small washer(2)
I-Pad(8)
C-Tray(2)
F-Large washer(2)
G-M8*25(2)
Advertisement
Related Manuals for Suptek SDM001T
Summary of Contents for Suptek SDM001T
- Page 1 SDM001T Parts User Manual after-sales@suptekmount.com A-Supporting pole(2) B-Base(2) C-Tray(2) Screw package Warning E-S3/S5(1) D-M5*18(6) F-Large washer(2) G-M8*25(2) Please read the installation instruction carefully. We are not responsible for any damage or injury caused by improper H-M8 small washer(2) I-Pad(8) assemble or use. Any question, please contact our customer service.
- Page 2 Step 1: Connect base and Step 2: Connect tray to the pole Step 3: Height adjustable supporting pole knob Loosen the knob, adjust supporting pole to the proper height,insert the pin and tighten the knob. Step 4: Angle adjustment of tray Step 5: Complete 360°...
