User Manual
after-sales@suptekmount.com
Warning
Please read the installation instruction carefully. We are not
responsible for any damage or injury caused by improper
assemble or use. Any question, please contact our customer
service.
Parts
SFM001
d-Crossbar (2)
Screw Package
A-Rubber feet (8)
E-Carpet nail (8)
I-Nut M6 (2)
a-Base (2)
b-Lower column (2)
e-Supporting bar (2)
B-Pad for plate (2)
F-M4x30 (2)
J1-Washer D4 (2)
J2-Spacer D8x11 (2)
c-Upper column (2)
C-M6x16 (2)
D-ST4.2x13
(8)
G-M6x25 (6)
H-M4x8 (2)
K-Wrench S4 (1)
Spacer D8x6 (2)
Advertisement
Related Manuals for Suptek SFM001
Summary of Contents for Suptek SFM001
- Page 1 Parts SFM001 User Manual after-sales@suptekmount.com c-Upper column (2) a-Base (2) b-Lower column (2) d-Crossbar (2) e-Supporting bar (2) Screw Package A-Rubber feet (8) B-Pad for plate (2) C-M6x16 (2) D-ST4.2x13 Warning E-Carpet nail (8) F-M4x30 (2) G-M6x25 (6) H-M4x8 (2) Please read the installation instruction carefully.
- Page 2 Step 1 Attach lower column to Step 2 Attach upper column Step 3 Cable management Step 4 Height adjustment the base wire for solid floor tighten two screws at front turn the stand take off two upside down pre-positioned screws for soft wall (carpet) （metal side against the glass）...
