Suptek ML5074 Installation Manual

INSTALLATION MANUAL
WARNING!
Severe personal injury and property damage can result from improper
installation or assembly. Read the following warning carefully before
beginning.
●If you do not understand the instructions or have any concerns or
questions, please contact a qualified local installer.
●Do not install or assemble if the product or hardware is damaged or
missing. If you require replacement parts, please contact your local
distributor for assistance.
●This product fits most 32"-75" LCD/plasma screen; load capacity up
to 165 lbs/75kg; lower shelf max load: 10 lbs/4.5kg.
●Do not use this product for anything other than the original purpose.
●This product contains moving parts, please use with caution.
32"-75"
（ 75KG ）
Step 1
Base installation
1.1
Insert four square tubes
into the base as shown
1.3
ML5074
MAX 600x400
165lbs
VESA Pattern
I
1.2
Tighten screw I with wrench J
Parts
Plastic fixing
cover X2
Base x1
Plate for fixing
column x1
Screw package (for TV installation)
M5x20 (x4)
(G1)
Screw package (for upper shelf installation)
A:M5x10
(X4)
Screw package (for floor stand)
φ
F:M8x60 G:
(X6)
Screw package (for lower shelf)
M:M5 Cap nut (X4)
Step 2
2.1
J
2.3
Long square Short square
tube x2 tube x2
Lower Shelf x1 Hook x2
Upper shelf x1
M6x20 (x4) M8x20 (x4) D8 Higher
(H1) spacer (x4)
( G2)
(H2)
D: φ 8x φ 16x1.5 Washer
B:M5 Nut C:M8x20
(X4)
(X4)
φ
8x 16x1.5 H:M8 Nut I:M8x12 J:S6 allen key
Washer (X4) (X8)
(X10)
Installation of base and column and the adjustment of height
2.2
Tighten screw F with wrench J as shown.
2.4
Column x1 Panel x1
Connecting plate
for upper shelf x1
Holder for Castor x4
lower shelf x2
D5 Washer(x4) D6 Washer(x4)
(F) (O)
E:M8 Nut
(X4)
(X4)
K:bubble level & wrench(X1)
(X1)
2.5
