Suptek ML6802 Instruction Manual

Step 3
Attach the VESA Plate to the Monitor
q
For Monitor with Flat Back
For Monitor with Curved or
Step 4
Install the monitor to the pole
Insert the monitor into the head
Secure and lock the panel with nut(h)
attachment of the rotating arm
Step 5 Make the Necessary Adjustments
s or g
r
o
Adjust and tighten the bolt with the
supplied Allen Key（O）to fix the tilt angle
Recessed Back
Step 6 Manage the Wires and Store the Allen Keys on Wire Clip
h
By adjusting the tightness of the
screws, the height of the monitor
can be adjusted.
n1
The wire is held in place with a cable clip (n1)
Thank you for choosing our products!
o
UNPACKING INSTRUCTIONS
Carefully open the carton, remove contents and lay out on cardboard or other protective
surface to avoid damage.
Check package contents against the Supplied Parts List in the next page to assure that
all components wete received undamaged. Do not use damaged or defective parts.
Carefully read all instructions before attempting installation.
IMPORTANT SAFETY INFORMATION
Install and operate this device with care. Please read this instruction before installation,
and carefully follow all instructions contained herein. Use proper safety equipment during
installation.
Please call a qualified installation contractor for help if you
directions or have any doubts about the safety of the installation.
Do not use this product for any purpose or in any configuration not explicitly specified in
this instruction. We hereby disclaims any and all liability for injury or damage arising from
incorrect assembly, incorrect mounting, or incorrect use of this product.
ML6802
INSTALLATION MANUAL
