SUMAKE
Mini Air Random Orbital Angle Sander
Specification:
Free Speed
Pad Size
Motor
Spindle Thread
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
W/2" Hook Pad
ST-AS30N2H-3
18,000 r/min
2" (50 mm)
0.3HP
5/16"-24UNF
10 CFM (283 L/min)
5-3/7" (138 mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
1.12 lbs (0.51 kg)
Noise and Vibration:
Vibration
EN ISO 28927-3
Sound Pressure Level
Load:
2.5 m/s²
Uncertainty
K= 1.5 m/s
²
Noise
EN ISO 15744
Please always
No load: 81.5 dB(A)
Sound power level
No load: 92.5 dB(A)
noise level > 80
risk of impaired
Uncertainty
K= 3dB
ST-AS30N2H-3-S-2004B-JUF
Remark
wear ear
protector at
environment
dB(A) due to
hearing!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sumake ST-AS30N2H-3
Summary of Contents for Sumake ST-AS30N2H-3
- Page 1 3/8” (10 mm) Air Hose (I.D.) risk of impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! K= 1.5 m/s ² K= 3dB Net Weight 1.12 lbs (0.51 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-AS30N2H-3-S-2004B-JUF...
-
Page 2: Ec Declaration Of Conformity
DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： MINI AIR RANDOM ORBITAL ANGLE SANDER, W/2" HOOK PAD Model/ Serial No.： ST-AS30N2H-3 to which this declaration applies, complies with these normative documents: ... - Page 3 So, install an air filter and on oiler between the part number, name and quantity. To operate this tool, just push the lever Sumake is a manufacturer and exporter of air compressor and the tool. Use a 3 HP or larger toward the tool itself. The tool continuously Warning tools since established.
-
Page 4: Parts List
ST-AS30N2H-3 MINI AIR RANDOM ORBITAL ANGLE SANDER W/2" HOOK PAD PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty J2-080108001 Air Strainer J2-078124601 Driving Gear Spindle J2-001124603 Housing J2-035124601 Lock Nut J2-032101601 Anvil Collar J2-073112501 Angle Housing J2-010101601 Pin Valve Rod... - Page 5 SANDER Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 13. Always use dust extraction or suppression systems which are suitable for the material being processed. Safety precautions for repetitive motions hazards 1. When using a sander to perform work-related activities, the operator can experience discomfort in the hands, arms, shoulders, neck or other parts of the body.
-
Page 8: Specific Safety Instructions
Specific safety instructions Warnings shall be given about any specific or unusual hazards associated with the use of the sander. Such warnings shall indicate the nature of the hazard, the risk of injury and the avoidance action to be taken. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet.
