SUMAKE
Central Vacuum Random Orbital Sander
Specification:
Free Speed
Orbit Dia.
Sanding Pad
Air Consumption
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
W/6"-53 Hole Hook Pad
ST-7139DC-653
11,000 r/min
5.0 mm
6" (150 mm)
15 cfm (430 l/min)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
1.8 lbs (0.8 kg)
Noise and Vibration:
Vibration
EN ISO 28927-3
Sound Pressure Level
Load:
0.8 m/s²
Sound power level
Uncertainty
K= 1.5 m/s
²
Noise
Remark
EN ISO 15744
Please always
load: 82 dB(A)
protector at
environment
load: 93 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
K= 3dB
ST-7139DC-653-S-1802A-STF
wear ear
hearing!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sumake ST-7139DC-653
Summary of Contents for Sumake ST-7139DC-653
- Page 1 3/8” (10 mm) dB(A) due to risk of impaired Air Pressure 90 psi (6.3 bar) Uncertainty Uncertainty hearing! K= 1.5 m/s ² K= 3dB Net Weight 1.8 lbs (0.8 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-7139DC-653-S-1802A-STF...
-
Page 2: Ec Declaration Of Conformity
DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： CENTRAL-VACUUM RANDOM ORBITAL SANDER W/6"-53 HOLE HOOK PAD Model/ Serial No.： ST-7139DC-653 to which this declaration applies, complies with these normative documents: ... - Page 3 Foreword air leaves the compressor. A portion of the 3. Operation, Adjusting And Replacing Ordering service Parts water content, however, is condensed in the Method For further operational and handling We are the a manufacturer and exporter of piping, and can enter the tool mechanism, information or for replacement of parts and On-off device air tools since established.
-
Page 4: Parts List
ST-7139DC-653 CENTRAL VACUUM RANDOM ORBITAL SANDER W/6"-53 HOLE HOOK PAD PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty 7139-01 Snap Ring 7139-24 Bushing 7139-02 O-Ring 7139-25 Pin (3x8) 7139-03 Valve Stem 7139-26 Front Plate 7139-04 O-Ring 7139-27 Bearing (6002ZZ) - Page 5 SANDER Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 13. Always use dust extraction or suppression systems which are suitable for the material being processed. Safety precautions for repetitive motions hazards 1. When using a sander to perform work-related activities, the operator can experience discomfort in the hands, arms, shoulders, neck or other parts of the body.
-
Page 8: Specific Safety Instructions
Specific safety instructions Warnings shall be given about any specific or unusual hazards associated with the use of the sander. Such warnings shall indicate the nature of the hazard, the risk of injury and the avoidance action to be taken. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet.
