SUMAKE
Specification:
Free Speed
Sanding Pad
Motor
Spindle Thread
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
Air Angle Polisher
(Low Profile) W/3" Hook Pad
ST-AP1063H
4,500 r/min
3"
0.35HP
1/4"-20
13CFM (370 L/min)
10-2/7" (261mm)
1/4" (6.35mm)
3/8" (10mm)
90psi (6.3bar)
1.72lbs (0.78kg)
PNEUMATIC TOOLS
Noise and Vibration:
Vibration
EN ISO 28927-3
No Load:
< 2.5 m/s²
Uncertainty
K= 1.5 m/s
Noise
EN ISO 15744
Sound Pressure Level
No load: 80 dB(A)
Sound power level
No load: 91 dB(A)
Uncertainty
K= 3dB
²
ST-AP1063H-S-2207A-STF
Remark
Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
hearing!
Advertisement
Table of Contents
Related Manuals for Sumake ST-AP1063H
Summary of Contents for Sumake ST-AP1063H
- Page 1 Air Inlet (PT) dB(A) due to 3/8” (10mm) Air Hose (I.D.) risk of impaired Uncertainty Uncertainty Air Pressure 90psi (6.3bar) hearing! K= 1.5 m/s K= 3dB ² Net Weight 1.72lbs (0.78kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-AP1063H-S-2207A-STF...
-
Page 2: Ec Declaration Of Conformity
DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： AIR ANGLE POLISHER (LOW PROFILE) W/3" HOOK PAD Model/ Serial No.： ST-AP1063H to which this declaration applies, complies with these normative documents: ... - Page 3 Foreword This tool stops rotation within few sec, after Sumake is a manufacturer and exporter of air releasing the lever. For the sake of safety, put it tools since established. We have devote all our Recoil...
-
Page 4: Parts List
AP1063H-33 Spindle Lock Set AP1063H-14 Rotor Blade AP1063H-34 Shaft Set AP1063H-15 Rotor AP1063H-35 Face Plate AP1063H-16 Cylinder Set AP1063H-36 Screw (M4x10) AP1063H-17 Front Plate AP1062H-37 2" Hook Pad [ST-AP1062H] AP1063H-18 Bearing (609ZZ) AP1063H-37 3" Hook Pad [ST-AP1063H] AP1063H-19 Washer ST-AP1062(3)H-P-2306B-ST... - Page 5 SANDER Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 13. Always use dust extraction or suppression systems which are suitable for the material being processed. Safety precautions for repetitive motions hazards 1. When using a sander to perform work-related activities, the operator can experience discomfort in the hands, arms, shoulders, neck or other parts of the body.
-
Page 8: Specific Safety Instructions
Specific safety instructions Warnings shall be given about any specific or unusual hazards associated with the use of the sander. Such warnings shall indicate the nature of the hazard, the risk of injury and the avoidance action to be taken. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet.
