SUMAKE
Specification:
Free Speed
Sanding Pad
Spindle Thread
Motor
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
7" Industrial Angle Sander
W/O Lever Lock
ST-GD507L3-PL
8,500 r/min
7" (180mm)
M14x2.0
2.3HP
19 CFM (540 L/min)
11-1/2" (291 mm)
3/8" (10 mm)
1/2" (13 mm)
90 psi (6.3 bar)
3.5 lbs (1.6 kg)
Noise and Vibration:
Vibration
EN ISO 28927-3
Sound Pressure Level
Load:
3.3 m/s²
Sound power level
Uncertainty
²
K= 1.5 m/s
Noise
Remark
EN ISO 15744
Please always
load: 78 dB(A)
wear ear
protector at
environment
load: 89 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
hearing!
K= 3dB
ST-GD507L3-PL-S-1911C-KHF
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sumake ST-GD507L3-PL
Summary of Contents for Sumake ST-GD507L3-PL
- Page 1 Air Hose (I.D.) 1/2” (13 mm) risk of impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! ² K= 1.5 m/s K= 3dB Net Weight 3.5 lbs (1.6 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-GD507L3-PL-S-1911C-KHF...
- Page 2 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment：7" INDUSTRIAL ANGLE SANDER W/O LEVER LOCK Model/ Serial No.： ST-GD507L3-PL to which this declaration applies, complies with these normative documents: ...
- Page 3 Use a 3 HP or larger compressor and the tool. Use a 3 HP or larger “hold-to-run” type. You can alsoadjusting the “hold-to-run” type. You can alsoadjusting the * In ordering parts and components give each * In ordering parts and components, give each ST-GD507L3-PL-I-1908A-KH...
- Page 4 ST-GD507L3-PL 7" INDUSTRIAL ANGLE SANDER W/O LEVER LOCK PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty GD505L-02 O-Ring GD505L-30 Bolt Holder GD505L-03B Exhaust Deflector GD505L-31 Trigger GD505L-04 Spring GD505L-32 Screw GD505L-05 Bushing GD505L-33 O-Ring GD505L-06 Washer GD505L-34 Pin Valve Rod...
- Page 5 SANDER Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 13. Always use dust extraction or suppression systems which are suitable for the material being processed. Safety precautions for repetitive motions hazards 1. When using a sander to perform work-related activities, the operator can experience discomfort in the hands, arms, shoulders, neck or other parts of the body.
- Page 8 Specific safety instructions Warnings shall be given about any specific or unusual hazards associated with the use of the sander. Such warnings shall indicate the nature of the hazard, the risk of injury and the avoidance action to be taken. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet.
