SUMAKE
Central Vacuum Gear-Driven Sander
Specification:
Free Speed
Orbit Diameter
Sanding Pad
Air Consumption
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
W/5" Velcro (Stick) Pad
ST-7110DC(S)-5
900 r/min
5 mm
5" (127 mm)
15 CFM (430 L/min)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
3.1 lbs (1.4 kg)
Noise and Vibration:
Vibration
EN ISO 28927-3
Sound Pressure Level
No Load:
2.6 m/s²
Uncertainty
²
K= 1.5 m/s
Noise
EN ISO 15744
No load: 88 dB(A)
Please always
Sound power level
No load: 99 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
K= 3dB
ST-7110NC(S)-5-S-1410H-STF
Remark
wear ear
protector at
environment
hearing!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sumake ST-7110DC(S)-5
Summary of Contents for Sumake ST-7110DC(S)-5
- Page 1 Air Hose (I.D.) dB(A) due to risk of impaired Air Pressure 90 psi (6.3 bar) Uncertainty Uncertainty hearing! ² K= 1.5 m/s K= 3dB Net Weight 3.1 lbs (1.4 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-7110NC(S)-5-S-1410H-STF...
-
Page 2: Ec Declaration Of Conformity
DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： CENTRAL VACUUM GEAR-DRIVEN SANDER W/5" VELCRO (STICK) PAD Model/ Serial No.： ST-7110DC(S)-5 to which this declaration applies, complies with these normative documents: ... - Page 3 Application: It is useful for various sanding work, to smooth wood and automotive or wood finishes by abrasion with sandpaper. (Sander) Pad mounting dangers: Correct sanding pad mounting is necessary to prevent injury from loosen wheels. Do not use chipped or cracked sanding pad. Use only wheels fitting the machine easily.
-
Page 4: Parts List
ST-7110NC(S)-5 NON-VACUUM GEAR-DRIVEN SANDER W/5" VELCRO (STICK) PAD ST-7110DC(S)-5 CENTRAL VACUUM GEAR-DRIVEN SANDER W/5" VELCRO (STICK) PAD ST-7110VC(S)-5 SELF-GENERATED VACUUM GEAR-DRIVEN SANDER W/5" VELCRO (STICK) PAD PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty 7110-01 Housing 7110-33 Faceplate... - Page 5 SANDER Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 13. Always use dust extraction or suppression systems which are suitable for the material being processed. Safety precautions for repetitive motions hazards 1. When using a sander to perform work-related activities, the operator can experience discomfort in the hands, arms, shoulders, neck or other parts of the body.
-
Page 8: Specific Safety Instructions
Specific safety instructions Warnings shall be given about any specific or unusual hazards associated with the use of the sander. Such warnings shall indicate the nature of the hazard, the risk of injury and the avoidance action to be taken. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet.
