SUMAKE
Specification:
Free Speed
Pad Size
Orbit Dia.
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
Air Angle Sander
W/ 1" Hook Pad
ST-AS11N1H
10,000 r/min
1" (25 mm)
2.5mm
2.3 CFM (66 L/min)
4-5/7" (120 mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
1.1 lbs (0.48 kg)
Noise and Vibration:
Vibration
EN ISO 28927-3
Sound Pressure Level
No load: 83 dB(A)
Load:
1.3 m/s²
Sound power level
No load: 94 dB(A)
Uncertainty
²
K= 1.5 m/s
Noise
Remark
EN ISO 15744
Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
hearing!
K= 3dB
ST-AS11N1H-S-1901A-D5F
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sumake ST-AS11N1H
Summary of Contents for Sumake ST-AS11N1H
- Page 1 Air Hose (I.D.) 3/8” (10 mm) risk of impaired Air Pressure 90 psi (6.3 bar) Uncertainty Uncertainty hearing! ² K= 1.5 m/s K= 3dB Net Weight 1.1 lbs (0.48 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-AS11N1H-S-1901A-D5F...
-
Page 2: Ec Declaration Of Conformity
DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： AIR ANGLE SANDER W/ 1" HOOK PAD Model/ Serial No.： ST-AS11N1H to which this declaration applies, complies with these normative documents: ... - Page 3 To operate this tool, just push the lever To operate this tool, just push the lever Sumake is a manufacturer and exporter of air Sumake is a manufacturer and exporter of air Sumake is a manufacturer and exporter of air compressor and the tool.
-
Page 4: Parts List
ST-AS11N1H, ST-AS11NQH, ST-AS11N2H AIR ANGLE SANDER W/ 1"(1-1/4")(2") HOOK PAD PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty AS11N1H-01 1" Pad AS11N3H-21 O-Ring (ID6.07x1.78) AS11NQH-01 1-1/4" Pad AS11N3H-22 Parallel Pin (Φ4x23.8) AS11N2H-01 2" Pad AS11N3H-23 Retaining Ring AS11N1H-03... - Page 5 SANDER Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 13. Always use dust extraction or suppression systems which are suitable for the material being processed. Safety precautions for repetitive motions hazards 1. When using a sander to perform work-related activities, the operator can experience discomfort in the hands, arms, shoulders, neck or other parts of the body.
-
Page 8: Specific Safety Instructions
Specific safety instructions Warnings shall be given about any specific or unusual hazards associated with the use of the sander. Such warnings shall indicate the nature of the hazard, the risk of injury and the avoidance action to be taken. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet.
