SUMAKE
Specification:
Free Speed
Pad
Spindle Thread
Motor
Overall Length
Air Consumption
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
Industrial 3" Air Angle Sander
W/ Roloc Pad
ST-AS55N3R
18,000 r/min
3" (75mm)
1/4"-20
0.7HP
7-2/7" (185mm)
13 CFM (368 L/min)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
1.8 lbs (0.84 kg)
PNEUMATIC TOOLS
Noise and Vibration:
Vibration
EN ISO 28927-3
Load:
<2.5 m/s²
Uncertainty
K= 1.5 m/s
Noise
EN ISO 15744
Sound Pressure Level
No load: 83 dB(A)
Sound power level
No load: 94 dB(A)
Uncertainty
²
K= 3dB
ST-AS55N3R-S-2203A-CFF
Remark
Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
hearing!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sumake ST-AS55N3R
Summary of Contents for Sumake ST-AS55N3R
- Page 1 3/8” (10 mm) Air Hose (I.D.) risk of impaired Uncertainty Uncertainty hearing! Air Pressure 90 psi (6.3 bar) ² K= 1.5 m/s K= 3dB Net Weight 1.8 lbs (0.84 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-AS55N3R-S-2203A-CFF...
- Page 2 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： INDUSTRIAL 3" AIR ANGLE SANDER W/ ROLOC PAD Model/ Serial No.： ST-AS55N3R to which this declaration applies, complies with these normative documents: ...
- Page 3 Foreword This tool stops rotation within few sec, after Sumake is a manufacturer and exporter of air releasing the lever. For the sake of safety, put it tools since established. We have devote all our Coupler...
- Page 4 ST-AS55N3R INDUSTRIAL 3" AIR ANGLE SANDER W/ ROLOC PAD PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty AS55N3R-01 Housing AS55N3R-19 Ring AS55N3R-01A Insert AS55N3R-20 Spacer AS55N3R-02 Seal AS55N3R-21 O-Ring AS55N3R-03 Regulator AS55N3R-22 Lock Nut AS55N3R-04 O-Ring AS55N3R-23 Motor Housing...
- Page 5 SANDER Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 13. Always use dust extraction or suppression systems which are suitable for the material being processed. Safety precautions for repetitive motions hazards 1. When using a sander to perform work-related activities, the operator can experience discomfort in the hands, arms, shoulders, neck or other parts of the body.
- Page 8 Specific safety instructions Warnings shall be given about any specific or unusual hazards associated with the use of the sander. Such warnings shall indicate the nature of the hazard, the risk of injury and the avoidance action to be taken. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet.
