SUMAKE
Specification:
Free Speed
Sanding Pad
Spindle Thread
Motor
Overall Length
Air Consumption
Air Inlet
Hose Size (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
7" Air Angle Disc Sander
ST-AS7017P
6,000 r/min
7"
ST-AS7017P3: M14*2.0
ST-AS7017P6: 5/8"-11UNC
1 HP
10-5/8" (270mm)
6 CFM (171 L/min)
1/4" (6.35mm)
3/8" (10mm)
90 psi (6.3 bar)
3.31 lbs (1.5 kg)
Noise and Vibration:
Vibration
EN ISO 28927-3
Sound Pressure Level
No load: 88 dB(A)
No Load:
1.2 m/s²
Sound power level
No load: 99 dB(A)
Uncertainty
K= 1.5 m/s
²
Noise
Remark
EN ISO 15744
Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
hearing!
K= 3dB
ST-AS7017P-S-2408A-GTF
Advertisement
Table of Contents
Related Manuals for Sumake ST-AS7017P
Summary of Contents for Sumake ST-AS7017P
- Page 1 Hose Size (I.D.) 3/8” (10mm) risk of impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! K= 1.5 m/s K= 3dB ² Net Weight 3.31 lbs (1.5 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-AS7017P-S-2408A-GTF...
-
Page 2: Ec Declaration Of Conformity
DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： 7" AIR ANGLE DISC SANDER Model/ Serial No.： ST-AS7017P3, ST-AS7017P6 to which this declaration applies, complies with these normative documents: ... - Page 3 Foreword This tool stops rotation within few sec, after part number, name and quantity. Sumake is a manufacturer and exporter of air releasing the lever. For the sake of safety, put it tools since established. We have devote all our...
-
Page 4: Parts List
ST-AS7017P 7" AIR ANGLE DISC SANDER PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty AS7017P-01 Wave Spring AS7017P-29B Air Inlet (NPT18) AS7017P-02 Adapter AS7017P-30 Felt AS7017P-03 Bearing (6200) AS7017P-31 Angle Housing AS7017P-04 Spanner (Chuck) 14mm AS7017P-32 Coupling Insert... - Page 5 SANDER Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 13. Always use dust extraction or suppression systems which are suitable for the material being processed. Safety precautions for repetitive motions hazards 1. When using a sander to perform work-related activities, the operator can experience discomfort in the hands, arms, shoulders, neck or other parts of the body.
-
Page 8: Specific Safety Instructions
Specific safety instructions Warnings shall be given about any specific or unusual hazards associated with the use of the sander. Such warnings shall indicate the nature of the hazard, the risk of injury and the avoidance action to be taken. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet.
