Sumake ST-P7740-5 Original Instructions Manual

Air angle sander/polisher with 5" hook pad w/o wool wheel
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

SUMAKE
With 5" Hook Pad (W/O Wool Wheel)
Specification:
Free Speed
Sanding Pad
Spinlde
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
Air Angle Sander/Polisher
ST-P7740-5
1,800 r/min
5" (125 mm)
5/16"x24
10 CFM (283 L/min)
8-1/3" (211 mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
2.9 lbs (1.32 kg)
Noise and Vibration:
Vibration
EN ISO 28927-3
Sound Pressure Level
No Load:
0.6 m/s²
Sound power level
Uncertainty
²
K= 1.5 m/s
Noise
EN ISO 15744
Please always
load: 79.9 dB(A)
protector at
environment
load: 90.9 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
K= 3dB
ST-P7740-5-S-2502E-STF
Remark
wear ear
hearing!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST-P7740-5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sumake ST-P7740-5

Summary of Contents for Sumake ST-P7740-5

  • Page 1 3/8” (10 mm) Air Hose (I.D.) risk of impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! ² K= 1.5 m/s K= 3dB Net Weight 2.9 lbs (1.32 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-P7740-5-S-2502E-STF...

  • Page 2: Ec Declaration Of Conformity

    DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： AIR ANGLE SANDER/POLISHER WITH 5" HOOK PAD (W/O WOOL WHEEL) Model/ Serial No.： ST-P7740-5 to which this declaration applies, complies with these normative documents: ...
  • Page 3 compressor for each sander. running speed by raising or lowering the lever. * In ordering parts and components, give each Foreword This tool stops rotation within few sec, after part number, name and quantity. We are a manufacturer and exporter of air tools releasing the lever.

  • Page 4: Parts List

    ST-P7740-3, ST-P7740-5 AIR ANGLE SANDER/POLISHER WITH 3"(5") HOOK PAD (W/O WOOL WHEEL) PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty P7740-01A Air Regulator Set P7740-30A Idler Gear Plate P7740-07A Valve Stem Set P7740-31 Washer P7740-09A Air Inlet (PT19)
  • Page 5 SANDER Original instructions SUMAKE Industrial Co. Ltd.
  • Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
  • Page 7 13. Always use dust extraction or suppression systems which are suitable for the material being processed. Safety precautions for repetitive motions hazards 1. When using a sander to perform work-related activities, the operator can experience discomfort in the hands, arms, shoulders, neck or other parts of the body.

  • Page 8: Specific Safety Instructions

    Specific safety instructions Warnings shall be given about any specific or unusual hazards associated with the use of the sander. Such warnings shall indicate the nature of the hazard, the risk of injury and the avoidance action to be taken. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet.
