  • Page 1 INSTRUCTION MANUAL EVMS EVMS 1 - 3 - 5 - 10 - 15 - 20 - 32 - 45 - 64 - 90...
  • Page 2 INSTRUCTION MANUAL REGARDING USE AND MAINTENANCE 2. MANUFACTURER IDENTIFICATION DATA MANUFACTURER DATA INDEX EBARA Pumps Europe S.p.A. page 2 Registered office: INTRODUCTION Via Campo Sportivo, 30 - 38023 Cles (TN), ITALIA page 2 MANUFACTURER IDENTIFICATION DATA Phone: 0463/660411 - Telefax: 0463/422782...
  • Page 3 5.2 STORAGE Do not touch the pump when the liquid handled is hot The purchaser shall check the goods for defects and quantities on delivery. Any water. Burns may result from high temperatures. damage discovered on delivery must be reported to the carrier/shipper and recorded on the delivery note.

  • Page 4: Pump Specifications

    THE MANUFACTURER RESERVES THE RIGHT TO AMEND TECHNICAL DATA FOR THE PURPOSE OF PRODUCT IMPROVEMENTS AND UPDATING. This list shows specification of Ebara motors. In case of using other motors, please see nameplate of motors and check the motor manufacturer’s specification. 8. PREPARING FOR USE 7.3 PUMP RATING PLATE...

  • Page 5: General Installation Precautions

    Move the electric pump temporarily and Evenly tighten the three set screws on the seal holder to the specified use a drill to make 4 holes (dia. 12 for EVMS 1, 3, 5, 10, 15, 20 pumps and dia. 14 torque.
  • Page 6 8.3 FLANGE LOADING AND TIGHTENING TORQUES Flange Strain X Strain Y Strain Z Model EVMS (L)(G) EVMS (L)(G) EVMS (L)(G) EVMS (L)(G) EVMS (L)(G) EVMS (L)(G) 2100 1850 1700 2100 1850 1700 EVMS 1050 1050 2500 2250 2050 2500 2250 2050 EVMS 1250...
  • Page 7 10.2 FILLING PUMP IN A FLOODED INSTALLATION WARNING! Motor-driven pumps not equipped with a plug must be a) Unscrew the hexagonal cap; powered by connecting them permanently to the electrical b) Open the suction gate valve until the water comes out; cabinet equipped with a switch, fuses and thermal cut-out c) Screw the cap back on until it is locked tight.

  • Page 8: Troubleshooting

    According to Article 9(1)(i) of the Waste Framework Directive 2008/98/EC and to the 1907/2006 REACH regulation, all EBARA products have been notified to the European Chemicals Agency System undersized Reviewing the system (ECHA).
  • Page 9 Incorrect motor rotation for pressure applications Reverse phases direction (only three-phase). Set maximum pressure at a Supply the pump with the voltage indicated Maximum pressure too high Incorrect supply voltage lower value on the ate Leaks from piping Check the joints Pressure too high Recheck the system 14.5 THE PUMP VIBRATES...
  • Page 10 15. SUPPLIED TECHNICAL DOCUMENTATION 60 Hz Pmax 15.1 STANDARD VOLTAGES SHOWN ON THE PLATE WITH THEIR EVMS1 EVMS3 EVMS5 EVMS10 EVMS15 RESPECTIVE TOLERANCES 2 ÷ 18 2 ÷ 15 2 ÷ 12 1 ÷ 10 1 ÷ 7 Frequency Phase [kW] UN [V] ±...
  • Page 11 FIG.2 Model EVMS1 EVMS3 EVMS5 EVMS10 EVMS15 EVMS20 EVMS32 EVMS45 EVMS64 EVMS90 15.6 WARNINGS FOR CORRECT OPERATION OF EVMS MOTOR-DRIVEN Insufficient immersion PUMPS (FIG. 1 - FIG. 2) Negative slope, air pockets created Tight bend, pressure loss Pipe diameter < pump port diameter, pressure loss FIG.1 libretto_EBARA_313_nuovo.indd 7 6-02-2009 9:30:36...
  • Page 12 EN: EC DECLARATION OF CONFORMITY (TRANSLATION FROM THE ORIGINAL) We, EBARA PUMPS EUROPE S.p.A., with head office in Via Campo Sportivo, 30 38023 Cles (TN) – ITALY , hereby declare under our own responsibility that our products pump conform to the provisions of the following European directives: Machinery Directive 2006/42/EC ; Low Voltage Directive 2014/35/EU;...
  • Page 13 DA: CE-OVERENSSTEMMELSESERKLÆRING (ORIGINAL) Vi, EBARA PUMPS EUROPE S.p.A med hjemsted i Via Campo Sportivo, 30 38023 Cles (TN) ITALY , erklærer under eget ansvar, at vores produkter stemmer overens med reglerne i følgende europæiske direktiver: Maskindirektivet 2006/42/EF; Lavspændingsdirektivet 2014/35/EF; Direktivet om elektromagnetisk kompatibilitet 2014/30/EF;...
  • Page 14 GR: ΔΗΛΩΣΗ ΣΥΜΜΟΡΦΩΣΗΣ CE (ΠΡΩΤΌΤΥΠΟ) Εμείς, η EBARA PUMPS EUROPE S.p.A με έδρα επί της Via Campo Sportivo, 30 38023 Cles (TN) ITALY , δηλώνουμε υπεύθυνα ότι τα προϊόντα μας είναι σύμφωνα με τις προδιαγραφές των ακόλουθων Ευρωπαϊκών οδηγιών: Οδηγία Μηχανών 2006/42/ΕΚ, Οδηγία Χαμηλής Τάσης 2014/35/ΕΚ, Οδηγία...
  • Page 15 RO: DECLARAȚIE CE DE CONFORMITATE (ORIGINALUL) Noi, EBARA PUMPS EUROPE S.p.A., cu sediul în Via Campo Sportivo, 30 38023 Cles (TN) ITALY , declarăm pe răspunderea noastră că produsele noastre sunt în conformitate cu dispozițiile următoarelor Directive europene: Directiva Mașini 2006/42/CE ; Directiva Joasă Tensiune 2014/35/CE;...
  • Page 16 LV: EK ATBILSTĪBAS DEKLARĀCIJA (ORIĢINĀLĀ) Mēs, EBARA PUMPS EUROPE S.p.A, juridiskā adrese: Via Campo Sportivo, 30 38023 Cles (TN) ITĀLIJA, uz savu atbildību paziņo- jam, ka mūsu izstrādājumi atbilst šo Eiropas direktīvu noteikumiem: Mašīnu direktīva 2006/42/ES; Zemsprieguma direktīva 2014/35/ ES; Elektromagnētiskās saderības direktīva 2014/30/ES;...
  • Page 17 SI: CE OZNAKA SKLADNOSTI (IZVIRNIK) Mi, podjetje EBARA PUMPS EUROPE S.p.a, s sedežem na naslovu Via Campo Sportivo 30, 38023 Cles (TN), ITALIJA, na našo lastno odgovornost izjavljamo, da so naši izdelki, na katere se navezuje ta izjava, skladni s sledečimi evropskimi direktivami: Direktiva o strojih 2006/42/ES; Direktiva o nizki napetosti 2014/35/EU;...
  • Page 18 Remove motor shaft key. - A - Fit the half key into the motor EVMS 1 - 3 - 5 - 10 - 15 - 20 shaft. Note: Ensure the half key does not protrude. M6=10 Nm  M8=20 Nm ...
  • Page 19 - A - EVMS 1 - 3 - 5 - 10 - 15 - 20  3 Nm...
  • Page 20 - A - EVMS 32 - 45 - 64 - 90 without ball bearing 360° M8=20 Nm M12=40 Nm M16=70 Nm ≥ 5.5 kW ≤ 4.0 kW M6=10 Nm M8=25 Nm M10=50 Nm...
  • Page 21 - A - EVMS 32 - 45 - 64 - 90 without ball bearing 5 Nm 2 min ...
  • Page 22 - A - EVMS 32 - 45 - 64 - 90 with ball bearing M8=20 Nm M12=40 Nm M16=70 Nm 2 min ...
  • Page 23 - B - EN: Single phase EN: Single phase with motor protector Monofase con moto prote ‫ﺛﻼﺛﻲااﻟ ﻣ ر ر ا ا ﺣلل‬ ‫أأﺣ ﺎ د د ييااﻟ ﻣ ررﺣﻠﺔ‬ ‫رركك‬ ‫أأﺣﺎ ددييااﻟ ﻣ ررﺣﻠﺔ ﺑﺣﺎﻣﻲ ﻟﻠﻣﺣ‬ Monofase con moto protettore Trifase EN: Threee phase ‫أأﺣ...
  • Page 24 - C - EN: chap. 10.1 EN: chap. 10.2...
  • Page 25 - D - EN: chap. 11.2    10 Nm 7 Nm...
  • Page 26 - E - EVMS 1 - 3 - 5 - 10 - 15 - 20 ≤ 4 kW M6=10 Nm  3 Nm  ...
  • Page 27 - E - EVMS 1 - 3 - 5 - 10 - 15 - 20 ≥ 5.5 kW M8=18 Nm M10=50 Nm  3 Nm  ...
  • Page 28 - E - EVMS 32 - 45 - 64 - 90 ≤ 4 kW without bearing 5 Nm  360°  2 min M8=20 Nm M12=40 Nm M16=70 Nm    M6=10 Nm M6=15 Nm  5 Nm  ...
  • Page 29 - E - EVMS 32 - 45 - 64 - 90 ≥ 5.5 kW without bearing 2 min 360° M8=25 Nm M8=25 Nm M10=50 Nm M10=50 Nm 5 Nm 10 Nm 5 Nm 5 Nm...
  • Page 30 - E - EVMS 32 - 45 - 64 - 90 ≥ 37 kW with bearing 5 Nm 10 Nm 2 min 25 Nm 25 Nm 360° 60 Nm 50 Nm 5 Nm 5 Nm...
  • Page 31 - F - EVMS1-20 EVMS XXXX EVMS32-90 EVMS XXXX Series name Code for model series Flow rate [m³/h] Number of impellers Code for pump version Code for pipe connection Frequency [Hz] Pole Code for shaft seal materials Code for rubber parts Motor in kW Phase motor Dash...
