Technical Data

8 Technical Data
Marking
Europe (ATEX)
Gas explosion
protection
Dust explosion
protection
IECEx
Gas explosion
protection
Dust explosion
protection
Certificates
Europe (ATEX)
IECEx
Electrical data
Rated operational voltage
Rated operational current
Rated cross section
Ambient conditions
Ambient temperature
Mechanical data
Degree of protection
Material
Enclosure
Sealing gasket
Mounting plate
Wall thickness
Enclosure cover
Mounting plate
Flanges
Standard
Option
Cover fixing
Standard
Option
Cover screws tightening
torque
Earth connection
Powder coated enclosures must not be used in areas where intense electrostatic 
charging may occur.
4
Control and Distribution Box
8150/5
E II 2 G Ex db eb ia/ib [ia/ib] ma mb qb IIA, IIB, IIC T6, T5, T4
E II 2 D Ex tb IIIC IP66 T130°C, T95°C, T80°C
Ex db eb ia/ib [ia/ib] ma mb qb IIA, IIB, IIC T6, T5, T4
Ex tb IIIC IP66 T130°C, T95°C, T80°C
PTB 09 ATEX 1109
IECEx PTB 09.0049
max. 1100 V AC / DC
depending on explosion protected components used
max. 630 A
depending on explosion protected components used
2
300 mm
depending on explosion protected components used
- 60 ... + 85 °C
depending on explosion protected components used
IP66 acc. to IEC/EN 60529 (depending on the built-in components used)
8150/5-....-....-...-2...: stainless steel 1.4301 (AISI 304), brush finished
8150/5-....-....-...-3...: stainless steel 1.4404 (AISI 316L), brush finished
Silicone, foamed
sheet steel, galvanized
min. 2 mm
3 mm
In the standard version, the enclosures are supplied without flanges.
Depending on order requirements the enclosures can be installed on one or more sides with
flanges; flange material: sheet steel, zinc-galvanised or stainless steel
with captive M6 stainless steel combo head screws
with cover hinges
4.5 Nm
M8 blind rivet nut (1x): at the outside of the enclosure
M8 rivet nut (1x): on mounting plate
M6 bolt (1x): additionally on enclosures with cover hinges
WARNING
