- Page 1 Quick Start Guide ProFace X (DS) Version: 1.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
- Page 2 1Overview Near-infrared Flash Microphone Camera 8-inch Touchscreen Under-screen Card Reading Area Tamper Switch Speaker Reset Button +12V Power RS232 RXD1 Power Auxiliary TXD1 interface input 485B RS485 485A Sensor Exit button Wiegand Lock INWD1 Wiegand INWD0 Alarm Networkinterface Note: Not all products have the function with , the real product shall prevail.
-
Page 3: Installation Environment
2 Installation Environment Please refer to the following recommendations for installation. 10ft KEEP DISTANCE AVOID GLASS AVOID DIRECT KEEP EFFECTIVE REFRACTION SUNLIGHT DISTANCE AND EXPOSURE 0.3-2.5m 3 Device Installation Install on the wall ①Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. ②Fix the backplate on the wall using wall mounting screws. - Page 4 3 Device Installation Install on the barrier gate Please thread the wire through the bracket before installation. ①Drill a hole on the barrier gate, insert the bracket into the hole and fix it with a nut. ②Adjust the angle of the device. ①...
-
Page 5: Standalone Installation
4 Standalone Installation Smoke Alarm Detector Door Sensor Exit Button Reader Lock TCP/IP 5 Door Sensor, Exit Button & Alarm Connection Detector Power SmokeDetector Door Sensor ExitButton Alarm Alarm Power... -
Page 6: Lock Relay Connection
6 Lock Relay Connection The system supports Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally unlocked when power-on) is connected with 'NO' and 'COM' terminals, and the NC LOCK (normally locked when power-on) is connected with 'NC' and 'COM' terminals. Take NC Lock as an example below: 1)Device not sharing power with the lock 2)Device sharing power with the lock... - Page 7 8 Barrier Connection RXD1 TXD1 485B 485A Barrier gate 9 RS485 Connection +12V RXD1 TXD1 485- 485B 485+ 485A 485 reader Note: 485A and 485B can be connected to the Barrier gate or the 485 Reader, separately, but cannot be connected to the gate and reader at the same time.
-
Page 8: Power Connection
10 Power Connection 12V3ADC Recommended power supply: 12V - 3A To share the power with other devices, use a power supply with higher current ratings. 11 Ethernet Connection Connect the device and computer software over an Ethernet cable. An example is shown below: ZKBioSecurity Default IP address : 192.168.1.201... -
Page 9: User Registration
12 UserRegistration When there is no super administrator set in the device, click on to enter the menu. After setting the super administrator, the system will request for the administrator’s verification before entering the menu. For the security purpose, it is recommended to register a super administrator at the first time you use the device. - Page 10 Method2: Register on ZKBioSecurity software Please set the IP address and cloud service server address in the Comm. Menu option on the device. Click [Access] > [Access Device] > [Device] > [Search Device] to search the device on the software. When an appropriate server address and port is set on the device, the searched devices are displayed automatically.
- Page 11 Method 3: Register on the phone Click [Personnel] > [Parameters], input ‘’http://Server address: Port’’ in the QR Code UGL bar. The software will automatically generate a QR code. Scan the QR code or login onto ‘’http://Server address: Port/app/v1/adreg’’ by the mobile phone to register users. Personnel Registration Personnel Registration Personnel ID Setting...
-
Page 12: Access Control Settings
13 Access Control Settings Clickon > [Access Control]to enter the access control management interface and set relevant parameters of access control. Main Menu Access Control Options Access Control Gate Control Mode Access Control Options User Mgt. System Door Lock Delay (s) User Role COMM. - Page 13 15 Detection Management Clickon > [Detection Management]to enter the setting interface. You can enable mask detection function, and enable the Deny Access Without Mask and the Trigger External Alarm, the device will send an alarm prompt when the user doesn’t wear a mask, meanwhile the user will be forbidden to access, as shown in the following figure.
- Page 14 16 Multi-face Identifying Settings Clickon > [System]> [Face] > [Face Identifying Settings] > [Identifying Mode] > [Multi-face Identifying] to enter the setting interface. When the Multi-face Identifying is enabled, the device can perform facial recognition of multiple people at once. For more details, please refer to the User Manual. Main Menu System Face...
- Page 15 17 Video Door Phone Connection Visitors click the on the main interface of the device to call and the phone will ring. The user can select accept or decline the call. After the user accepting, it will enter the video door phone interface. On the device, click on >...
- Page 16 18 QR Code as the Mobile Credential 1. In [System] > [Basic Management] > [Parameters] of ZKBioSecurity software, set Enable QR Code to “Yes”, and select the QR code status according to the actual situation. On the server, choose [System] > [Authority Management] > [Client Register] to add a registered App client.
- Page 17 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright@2022 ZKTECO CO., LTD. All Rights Reserved.
