- Page 1 Quick Start Guide ProMA Series Version: 2.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
-
Page 2: Product Overview
1 Product Overview ProMA-QR ProMA Microphone Microphone Camera & Palm Camera & Palm 2" Display Screen 2" Display Screen Card Reading Area Card Reading Area Doorbell Button Doorbell Button Flash Flash QR Code Scanner Fingerprint Sensor ProMA-RF Microphone Camera & Palm 2"... -
Page 3: Installation Environment
Terminal Block 2 Terminal Block BELL+ BELL- BUT1 SEN1 AUX1 COM1 IWD0 IWD01 485A 485B WD0-OUT WD1-OUT PGND 12V-OUT 12VIN 3 Installation Environment Please refer to the following recommendations for installation. AVOID DIRECT INSTALL INDOORS AVOID INSTALLATION AVOID USE OF ANY SUNLIGHT ONLY NEAR... -
Page 4: Device Installation
4 Device Installation ProMA series installation are the same, the following is an example of ProMA. ① Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. ② Fix the backplate on the wall using wall mounting screws. -
Page 5: Standalone Installation
5 Standalone Installation Smoke Alarm Detector Door Sensor Exit Button Reader Lock TCP/IP 6 Power Connection Recommended power supply Rating of 12V and 3A To share the device’s power supply with other devices, use a power supply with higher current ratings. -
Page 6: Lock Relay Connection
7 Door Sensor, Exit Button, Alarm and Auxiliary Connection BELL+ BELL- Alarm Power ExitButton BUT1 SEN1 AUX1 Alarm Door COM1 Sensor Detector Smoke Detector Power 8 Lock Relay Connection The system supports both Normally Opened Lock and Normally Closed Lock. The NO Lock (normally opened when powered) is connected with ‘NO’... -
Page 7: Wiegand Connection
9 Wiegand Connection Wiegand card reader connects to the top 4 pins of the wiegand terminal and the last two pins are used by the Access Controller, as shown in the following figure. It sends the credentials to the device via wiegand communication. QR600 IWD0 IWD1... -
Page 8: Ethernet Connection
11 Ethernet Connection Connect the device and computer software over an Ethernet cable. An example is shown below: ZKBio CVSecurity Default IP address : 192.168.1.201 IP address : 192.168.1.130 Subnet mask : 255.255.255.0 Subnet mask : 255.255.255.0 Note: In LAN, IP addresses of the server (PC) and the device must be in the same network segment when connecting to ZKBio CVSecurity software. - Page 9 Open a browser to enter the address to log in the WebServer, the address is the https:// Serial IP Address:1443, for example: https://192.168.1.201:1443. https：//192.168.1.201:1443/lo https：//192.168.1.201:1443 https：//192.168.1.201:1443 https：//192.168.1.201:1443 - Goolge - Search https：//192.168.1.201:1443/login.html - https：//192.168.1.201:1443/start.html https：//192.168.1.201:1443/login.html - https：//192.168.1.201:1443/login.html https：//192.168.1.201:1443/lo https：//192.168.1.201:1443/login.html User Name Password Login Enter the account ID and password, the default account ID is: admin, password: admin@123.
- Page 10 Forgot Password 13 Forgot Password Method 1 (When there is a super admin): If you forgot the password of WebServer, the registered super admin can reset it for you. Click the icon on the login interface. Login On the pop-up page, enter the relevant information of the super admin user as prompted. After a successful reset, enter the default account and password (account: admin, password: admin@123) on the login interface to log in.
- Page 11 Method 2 (When there is no super admin): If the network of the device is normal and ZKBio CVSecurity has been connected, you can reset the password by sending the super admin account and password from the server. Click [Personnel] > [Person] > [New] on the ZKBio CVSecurity. After registering the information of the super admin, click Save and New.
-
Page 12: User Registration
14 User Registration Click on [All Users] on the WebServer to register a new user. Settings include entering user ID, name, password, card number, face, palm, fingerprint, setting user role and access control role. Step 2 Enter the User Info. Step 1 Step 3 Enroll Face, Palm... - Page 13 Connection to ZKBio CVSecurity Software Set the IP address and cloud service server address in the [Advanced Settings] option on the WebServer. Step 2 Enter the IP Info. Step 1 Step 3 Step 5 Enter the Server Info. Step 6 Step 4...
- Page 14 Click [Access] > [Access Device] > [Device] > [Search Device] to search the device on the software. When an appropriate server address and port is set on the device, the searched devices are displayed automatically. Step 1 Step 2 Step 3 Step 4 Step 5 For more details, please refer to the ZKBio CVSecurity V6600 User Manual.
-
Page 15: System Settings
16 System Settings Note: Device type to set the device as an access control terminal or attendance terminal. After changing the device type, the device will delete all the data and restart, and some functions will be adjusted accordingly. Step 2 Step 1 Step 3 17 Card Management... - Page 16 Employee Login screen. Enter the Employee ID and Password (Default: 123456) to login. Tap [Mobile Credential] on the APP, and a QR code will appear, parallel the phone screen to the device QR code scanner. For details, please refer to ProMA Series User Manual. Note:...
- Page 17 When the device-side video intercom parameters are set correctly, the device automatically pushes the device list on the left, as shown in following figure. WebServer VideoIntercom ZKBio Talk Server Address: 192.168.163.199 Server Port: 25550 For details, please refer to ProMA Series User Manual.
- Page 18 ZSmart Download and install the ZSmart APP on the phone. Use the ZSmart to scan the QR code in the [Video Intercom] on the WebServer. WebServer ZSmart VideoIntercom TUYA...
-
Page 19: Sip Settings
20 SIP Settings This function needs to be used with the indoor station Vpad A2. Local Area Network Use Set the IP address on the indoor station. Network Accounts 1. Connection Mode Static IP 192.168.163.199 Network 2. IP Address 255.255.255.0 Security 3. - Page 20 Note: In LAN, the IP addresses of the indoor station and the ProMA must be in the same network segment. SIP Server On WebServer, enable SIP Server, and enter the server parameters for the indoor station Vpad A2. WebServer SIP Settings SIP Server Server Address: 20.205.119.174...
-
Page 21: Onvif Settings
21 Onvif Settings This function needs to be used with the network video recorder (NVR). After network video recorder (NVR) is configured with ZKBio CVSecurity, set ProMA to the same network segment as the NVR. In the device list, click [Search] [Start Search] on the >... - Page 22 Step 6 Step 7 Step 8 Step 9 Step 10...
- Page 23 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2022 ZKTECO CO., LTD. All Rights Reserved.
