- Page 1 Quick Start Guide ProMA Series Version: 1.1 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
-
Page 2: Product Overview
1 Product Overview ProMA-QR Microphone Camera 2" Display Screen Card Reading Area Doorbell Button Flash QR Code Scanner 90° Reset Speaker 12V-OUT Power Out Power In WD1-OUT Wiegand Out WD0-OUT 485B RS485 Lock COM1 485A IWD1 Wiegand In Auxiliary Input AUX1 IWD0 Sensor... -
Page 3: Installation Environment
ProMA ProMA-RF Microphone Microphone Camera Camera 2" Display Screen 2" Display Screen Card Reading Area Card Reading Area Doorbell Button Doorbell Button Flash Flash Fingerprint Sensor 2 Installation Environment Please refer to the following recommendations for installation. AVOID DIRECT INSTALL INDOORS AVOID INSTALLATION AVOID USE OF ANY SUNLIGHT... -
Page 4: Device Installation
3 Device Installation ProMA series installation are the same, the following is an example of ProMA. ① Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. ② Fix the backplate on the wall using wall mounting screws. -
Page 5: Standalone Installation
4 Standalone Installation Smoke Alarm Detector Door Sensor Exit Button Reader Lock TCP/IP 5 Power Connection AC Adapter DC 12V, 3A Recommended power supply Rating of 12V and 3A To share the device’s power supply with other devices, use a power supply with higher current ratings. - Page 6 6 Lock Relay Connection The system supports both Normally Opened Lock and Normally Closed Lock. The NO Lock (normally opened when powered) is connected with ‘NO’ and ‘COM’ terminals, and the NC Lock (normally closed when powered) is connected with ‘NC’ and ‘COM’ terminals. The power can be shared with the lock or can be used separately for the lock, as shown in the example with NC Lock below: ...
-
Page 7: Wiegand Connection
8 Wiegand Connection Wiegand card reader connects to the top 4 pins of the wiegand terminal and the last two pins are used by the Access Controller, as shown in the following figure. It sends the credentials to the device via wiegand communication. +12V 12V-OUT WD1-OUT... -
Page 8: Ethernet Connection
10 Ethernet Connection Connect the device and computer software over an Ethernet cable. An example is shown below: ZKBio CVSecurity Default IP address : 192.168.1.201 IP address : 192.168.1.130 Subnet mask : 255.255.255.0 Subnet mask : 255.255.255.0 Note: In LAN, IP addresses of the server (PC) and the device must be in the same network segment when connecting to ZKBio CVSecurity software. - Page 9 Open a browser to enter the address to log in the WebServer, the address is the https:// Serial IP Address:1443, for example: https://192.168.1.201:1443. https：//192.168.1.201:1443/lo https：//192.168.1.201:1443 https：//192.168.1.201:1443 https：//192.168.1.201:1443 - Goolge - Search https：//192.168.1.201:1443/login.html - https：//192.168.1.201:1443/start.html https：//192.168.1.201:1443/login.html - https：//192.168.1.201:1443/login.html https：//192.168.1.201:1443/lo https：//192.168.1.201:1443/login.html User Name Password Login Enter the account ID and password, the default account ID is: admin, password: admin@123.
-
Page 10: User Registration
12 User Registration Clickon [All Users] on the WebServer to register a new user. Settings include entering user ID, name, password, card number, fingerprint, face, setting user role and access control role. Step 1 Step 2 Enter the User Info. Step 3 Enroll Fingerprint, Step 4... - Page 11 Connection to ZKBio CVSecurity Software Set the IP address and cloud service server address in the [Advanced Settings] option on the WebServer. Step 2 Enter the IP Info. Step 1 Step 3 Step 5 Enter the Server Info. Step 6 Step 4...
- Page 12 Click [Access] > [Access Device] > [Device] > [Search Device] to search the device on the software. When an appropriate server address and port is set on the device, the searched devices are displayed automatically. Step 1 Step 2 Step 3 Step 4 Step 5 For more details, please refer to the ZKBio CVSecurity V6600 User Manual.
- Page 13 Employee Login screen. Enter the Employee ID and Password (Default: 123456) to login. Tap [Mobile Credential] on the APP, and a QR code will appear, parallel the phone screen to the device QR code scanner. For details, please refer to ProMA Series User Manual. Note:...
- Page 14 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2022 ZKTECO CO., LTD. All Rights Reserved.
