Summary of Contents for ThermoFisher Scientific Thermo Scientific TSG Series
- Page 1 Laboratory & Pharmacy Refrigerators TSG Series Installation and Operation 333924H01 • Revision B • 06/06/2024...
- Page 2 IMPORTANT Read this instruction manual. Failure to follow the instructions in this manual can result in damage to the unit, injury to operating personnel, and poor equipment performance. CAUTION All internal adjustments and maintenance must be performed by qualified service personnel. Material in this manual is for informational purposes only.
-
Page 3: Table Of Contents
Contents Model................1 Safety Precautions............2 Unpacking..............4 Packing List ..............4 General Recommendations ........5 Temperature Monitoring ......... 5 Door Management ..........5 Intended Use............5 Initial Loading............6 Operating Standards ..........7 Unit Specifications ..........7 Installation..............9 Location .............. - Page 4 Startup ................ 15 Initial Startup ............15 Additional Sample Prep Refrigerator Startup ..15 Product Loading and Unloading Guidelines ... 16 Operation ..............17 Control Panel ............17 Standard Display............. 19 Navigation ............... 19 Screens ..............21 Programming Mode ..........22 Temperature Settings ..........
- Page 5 Troubleshooting............30 End of Life Care ............32 Warranty ..............33 Regulatory Compliance ..........34 Product Safety ............34 Hydrocarbon Refrigerant Service Notes ....34 Electromagnetic Compatibility ........ 34 Canadian ISED IC Notice ........34 Korean KC Registration .......... 35 Energy Efficiency.............
-
Page 6: Model
Model The table below show the units covered in this operation and installation manual by model number. Table 1. Applicable Models Unit Model (*) Thermo Scientific - TSG1205G* A/D/V Thermo Scientific - TSG1205S* A/D/V Thermo Scientific - TSG1205P* A/D/V Thermo Scientific - TSG2305G* A/D/V Thermo Scientific - TSG2305S* A/D/V... -
Page 7: Safety Precautions
Safety Precautions In this manual, the following symbols and conventions are Below are important safety precautions that apply to this used: product. This symbol when used alone indicates important CAUTION: Use this product only in the way operating instructions which reduce the risk of described in the product literature and in this injury or poor performance of the unit. - Page 8 Below are additional safety precautions that apply to sample prep refrigerator models: WARNING: Risk of Fire. Equipment should only be powered using the internal outlet. In case a refrigeration leak occurs, a built in safety circuit will remove power to the outlet in the unit. This safety circuit has no control over equipment powered via battery or an external power supply (i.e.
-
Page 9: Unpacking
Unpacking At the time of delivery, make sure to inspect the unit packaging for damage before signing for the shipment. If packaging damage is present, request immediate product inspection and file a claim with the carrier. Note: Packaging damage does not denote that unit damage exists. -
Page 10: General Recommendations
General Recommendations Intended Use This section includes some general recommendations for your unit. The 5 °C refrigerators described in this manual are high Temperature Monitoring performance units for professional use. These products are intended for use as cold storage of temperature sensitive materials such as media, reagents, and clinical* and laboratory products. -
Page 11: Initial Loading
Initial Loading Allow the unit to operate at the desired temperature for a minimum of 12 hours before loading. Load the unit one shelf at a time, starting from bottom to top shelf. After loading each shelf, allow the unit to recover to the desired setpoint before loading the next shelf. -
Page 12: Operating Standards
Operating Standards The units described in this manual are classified for use as stationary equipment in a Pollution Degree 2 and Over voltage Category II environment. These units are designed to operate under the following environmental conditions: • Indoor use •... - Page 13 Other specifications are listed in the table below. Table 2. Unit Specifications Glass Solid Power Door Door Exterior Rated Rated Frequency Model Module Unit Unit Dimensions Voltage Current / Phase Plug Weight Weight (D x W x H) † † Kg (lbs) Kg (lbs) 115 V...
-
Page 14: Installation
Installation The use of this bracket does not prevent the tipping of the WARNING: Risk of Shock. Do not exceed the refrigerator when not properly installed. electrical rating printed on the data plate located on the upper left side of the unit. CAUTION: Do not move the unit using the drain pan on the back. -
Page 15: Label Description
1. Locating the Bracket Label Description a. Determine where you want the centerline of the refrigerator to be. Back of Unit b. Place the included template on the floor lined up with 1/2" Bolt Location the centerline of the refrigerator and keep Detailed View 6 - 12"... -
Page 16: Convenience Outlet (Sample Prep Refrigerators)
Table 4. Power Cord Specification Flammable materials should not be stored in the refrigerator. Power Cord Safety Circuit Lights Model Specifications 3-G 12 AWG, NEMA The safety circuit has two LEDs: 5-15P, 15 A/125 V • RED (on the top) - When the red LED is ON, it indicates 3-G 14 AWG, NEMA that the safety circuit has disconnected AC power to the 6-15P, 15 A/250 V... -
Page 17: Shelves
you have a Pharmacy model, do not position shelving where it will disrupt the thermal bottle and probe assembly. Figure 4. Shelf Support Hanger Baskets Pharmacy models ship with baskets installed. 12 cubic foot Pharmacy models ship with 5 baskets, 23 and 30 cubic foot Pharmacy models ship with 6 baskets, and 50 cubic foot Pharmacy models ship with 12 baskets. -
Page 18: Door Operation
Sliding Doors 4. Install shelves onto clips with the product retention bar facing upwards. Be careful not to dislodge clips during shelf installation. The doors on the 45 cu.ft. models are self-closing sliding 5. Before loading the shelf, ensure that the shelf is resting glass doors. -
Page 19: Remote Alarm (Optional)
Remote Alarm (Optional) To install the remote alarm, make the following connections: 1. Connect the COMMON terminal on the cabinet switch to the COMMON wire on the alarm. All units have factory-installed local alarm contacts that can be used for remote alarm systems. See Alarm Relay column 2. -
Page 20: Startup
Startup Initial Startup Additional Sample Prep Refrigerator Startup To start up the refrigerator, complete the following steps: 1. If you have a Pharmacy model, verify that the sensor 1. Connect the AC power cord to the Convenience Outlet probe(s) have been installed in the bottle(s). Power connector. -
Page 21: Product Loading And Unloading Guidelines
Product Loading and Unloading Guidelines When loading your laboratory refrigerator, ensure to observe the following guidelines: • Distribute the load as evenly as possible. Temperature uniformity depends on air circulation, which could be impeded if the internal storage components are overfilled, particularly at the top of the cabinet. -
Page 22: Operation
Operation Control Panel Figure 6. Control Panel Display Buttons Icons Laboratory & Pharmacy Refrigerators Operation |... - Page 23 Table 6. Keypad Icon/ Description Flashing button Minimum temperature Direct access to minimum recorded temperature Reset minimum and Reset minimum and maximum recorded temperatures maximum temperature (requires confirmation) Maximum temperature Direct access to maximum recorded temperature Setpoint/Up arrow Increase value Scroll menu Pressed briefly: •...
-
Page 24: Standard Display
Standard Display Icon Action in Direct Access Mode At start-up, the user terminal briefly shows the firmware Lights version and then the standard display. The standard display depends on the setting of parameter: • All models (except Pharmacy models) will display the Navigation temperature as recorded by the control probe. - Page 25 4. Press PRG to enter programming mode; the UP and 10. Press DOWN to move to the next category and follow DOWN buttons will flash and the first category of steps 6 to 9 to set the other parameters; parameters dir (=direct functions) will be displayed; 11.
-
Page 26: Screens
Screens The possible states of the terminal are shown in the table below. Table 8. Screens Icon Status Description The display shows the main value, Standard alternating with any alarms and signals The terminal shows any Display active active loads, loads the keypad is locked... -
Page 27: Programming Mode
Programming Mode In direct access mode, pressing PRG enters programming mode, where the unit’s main operating parameters can be set. Notice: In the default settings the user password is set to 0 and is not required when entering programming mode; if the password has been set to a value other than 0, this needs to be entered to access the Direct Access Mode and Programming Mode. -
Page 28: Controller On/Off
Table 11. Programming Parameters Par. Menu Desc. Def. Temperature control setpoint °C/°F Unit of measure: 0 = °C; 1 = °F Enable buzzer: 0 = disabled; 1 = enabled -100 / ∆ High temperature alarm threshold 537/ 999 °C/ °F -148 -100 / ∆... -
Page 29: Calibration (Parameters / Cc To / Cr)
Calibration (Parameters the battery and performs a test every 24 hours to verify correct operation. The test can also be run manually by / cc to / cr) pressing a button or via the direct function. Activation of the backup battery can be disabled when the unit is in storage using the boF parameter turned ON within the direct functions. -
Page 30: Alarms And Signals
Alarms and Signals five alarms, in a FIFO list (the 6th alarm overwrites the 1st alarm, and so on). The error log can be accessed from the user terminal. Example Signals Display after HI error. Signals are messages shown on the display to notify the user of the control procedures in progress (e.g. -
Page 31: Alarm Table
Alarm Table Table 14. Alarm Table Display Delay Icon Alarm Effects on Description Buzzer Reset code code (default) display relay control Battery faulty or not Automatic connected See “Battery Blackout in progress Automatic status” Battery test in Automatic progress Configuration write Automatic error See “Door... - Page 32 Table 14. Alarm Table (Continued) Display Delay Icon Alarm Effects on Description Buzzer Reset code code (default) display relay control Configuration not Manual completed correctly Maintenance Manual request Low and High Temperature Alarms LO and HI Table 15. Low and High Temperature Alarm User Par.
-
Page 33: Maintenance
Maintenance Cleaning the Condenser WARNING: Risk of Shock. Disconnect equipment from main power before attempting any maintenance to equipment or its controls unless stated otherwise. CAUTION: Condensers should be cleaned at least every six months; more often if the laboratory area is dusty. In heavy traffic areas, Cleaning the Cabinet condensers load with dirt more quickly. -
Page 34: Gasket Maintenance
Gasket Maintenance Use of other cleaners may contain chemicals that will trip the safety circuit. If this occurs, continue to clean the refrigerator and leave the doors open for approximately 5 minutes to Periodically check the gaskets around the door for punctures allow any vapors to exit the refrigerator. -
Page 35: Troubleshooting
Troubleshooting WARNING: Troubleshooting procedures involve working with high voltages which can cause injury or death. Troubleshooting should only be performed by Factory Authorized Service Personnel. This section is a guide for troubleshooting equipment problems. Component parts must be replaced only with similar components. - Page 36 Table 16. Troubleshooting Procedure (Continued) Problem Cause Solution Door is open Make sure the door is completely closed. Door seal check Check the door seal. Warm product recently loaded in Allow ample time to recover from loading warm unit product. Check for proper voltage to the unit.
-
Page 37: End Of Life Care
End of Life Care Some considerations and suggestions are listed below for proper disposal of this product. While addressing these actions for safe recycling and disposal, please follow all guidelines, Safety Data Sheets (SDS), or regulations applicable to your country and region. •... -
Page 38: Warranty
Warranty International Warranty • 48 Months Parts and Labor, 5 years for compressor parts During the first forty eight (48) months from shipment, Thermo Fisher Scientific Inc, through its authorized Dealer or service organizations, will at its option and expense repair or replace any part found to be non-conforming in material or workmanship. Thermo Fisher Scientific Inc reserves the right to use replacement parts, which are used or reconditioned. -
Page 39: Regulatory Compliance
Regulatory Compliance Product Safety Product Testing This product family has been tested to applicable product safety standards by a Nationally Recognized Test Laboratory (NRTL) and may bear the NRTL’s mark of safety compliance to those applicable standards. Hydrocarbon Refrigerant Service Notes This refrigerator employs natural hydrocarbon refrigerants. -
Page 40: Korean Kc Registration
Korean KC Registration 사용자 안내문 이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서 가정용 환경에서 사용 하는 경우 전파간섭의 우려가 있습니다. WARNING: EMC Registration is done on this equipment for business use only. It may cause interference when the product would be used in home. -
Page 41: Weee Compliance
WEEE Compliance Great Britain WEEE Compliance. This product is required to comply with the European Union’s Waste Electrical & Electronic Equipment (WEEE) Directive 2012/19/EU. It is marked with the following symbol. Thermo Fisher Scientific has contracted with one or more recycling/disposal companies in each EU Member State, and this product should be disposed of or recycled through them. - Page 42 This page is intentionally left blank.
- Page 43 This page is intentionally left blank.
-
Page 44: If You Need Assistance
IF YOU NEED ASSISTANCE: Thermo Fisher Scientific products are backed by a global technical support team ready to support your applications. We offer cold storage accessories, including remote alarms, temperature recorders, and validation services. Visit www.thermofisher.com/cold or call: Countries Sales North America +1 866 984 3766 India toll free...
