ThermoFisher Scientific Thermo Scientific MicroClick Instruction Manual

30 x 2 rotor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Thermo Scientific
MicroClick 30 x 2
Rotor
For Thermo Scientific General Purpose
Centrifuges
Instruction Manual
50142071-b • 09 / 2020
Visit us online to register your warranty:
thermofisher.com/labwarranty

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Thermo Scientific MicroClick and is the answer not in the manual?

Questions and answers

Related Manuals for ThermoFisher Scientific Thermo Scientific MicroClick

Summary of Contents for ThermoFisher Scientific Thermo Scientific MicroClick

  • Page 1 Thermo Scientific MicroClick 30 x 2 Rotor For Thermo Scientific General Purpose Centrifuges Instruction Manual 50142071-b • 09 / 2020 Visit us online to register your warranty: thermofisher.com/labwarranty...
  • Page 2 WEEE Compliance This product is required to comply with the European Union’s Waste Electrical & Electronic Equipment (WEEE) Directive 2012/19/EU. It is marked with the following symbol:...

  • Page 5: Table Of Contents

    Contents Preface ............. . 7 Items Supplied .

  • Page 7: Preface

    Preface Before starting to use the rotor, read through this instruction manual carefully and follow the instructions. Failure to follow the instructions and safety information in this instruction manual will result in the expiration of the seller’s warranty. Items Supplied Quantity Check Item...

  • Page 8: Precautions

    • Never overload the rotor. • Use only accessories which have been approved by Thermo Fisher Scientific. Exceptions to this rule are commercially available glass or plastic centrifuge tubes, provided they have been approved for the speed or the RCF value of the rotor. •...

  • Page 9: Rotor Specifications

    Rotor Specifications Rotor Specifications Contents • “General Purpose Centrifuges” page 10 Thermo Scientific MicroClick 30 x 2 Rotor...

  • Page 10: General Purpose Centrifuges

    Rotor Specifications General Purpose Centrifuges 230 V, 50 / 60 Hz, Ventilated Centrifuge Multifuge X3 Multifuge X3F Multifuge X1 Megafuge 40 Megafuge 16 Weight of Empty Rotor [kg] Max. Cycle Number 50000 50000 50000 50000 50000 Maximum Permissible Load [g] 30 x 4 30 x 4 30 x 4...
  • Page 11 Rotor Specifications 120 V, 60 Hz, Ventilated Centrifuge Multifuge X3 Multifuge X3F Multifuge X1 Megafuge 40 Megafuge 16 Weight of Empty Rotor [kg] Max. Cycle Number 50000 50000 50000 50000 50000 Maximum Permissible Load [g] 30 x 4 30 x 4 30 x 4 30 x 4 30 x 4...
  • Page 12 Rotor Specifications 230 V, 50 / 60 Hz, Ventilated Centrifuge Legend XT Legend XF Legend X1 ST 40 ST 16 Weight of Empty Rotor [kg] Max. Cycle Number 50000 50000 50000 50000 50000 Maximum Permissible Load [g] 30 x 4 30 x 4 30 x 4 30 x 4...
  • Page 13 Rotor Specifications 120 V, 60 Hz, Ventilated Centrifuge Legend XT Legend XF Legend X1 ST 40 ST 16 Weight of Empty Rotor [kg] Max. Cycle Number 50000 50000 50000 50000 50000 Maximum Permissible Load [g] 30 x 4 30 x 4 30 x 4 30 x 4 30 x 4...
  • Page 14 Rotor Specifications 100 V, 50 / 60 Hz, Ventilated Centrifuge Legend XT Legend XF Legend X1 ST 40 ST 16 Weight of Empty Rotor [kg] Max. Cycle Number 50000 50000 50000 50000 50000 Maximum Permissible Load [g] 30 x 4 30 x 4 30 x 4 30 x 4...
  • Page 15 Rotor Specifications General Purpose Centrifuges 230 V, 50 / 60 Hz, Ventilated Centrifuge SL 40 SL 40 F SL 16 Weight of Empty Rotor [kg] Max. Cycle Number 50000 50000 50000 Maximum Permissible Load [g] 30 x 4 30 x 4 30 x 4 Maximum Speed n [rpm]...
  • Page 16 Rotor Specifications 120 V, 60 Hz, Ventilated Centrifuge SL 40 SL 40 F SL 16 Weight of Empty Rotor [kg] Max. Cycle Number 50 000 50000 50000 Maximum Permissible Load [g] 30 x 4 30 x 4 30 x 4 Maximum Speed n [rpm] 14000...

  • Page 17: Chapter 2 Thermo Scientific Auto-Lock Rotor Exchange

    Thermo Scientific Auto-Lock Rotor Exchange Thermo Scientific Auto-Lock Rotor Exchange Contents • “Rotor Installation” page 18 • “Removing the Rotor” page 19 Thermo Scientific MicroClick 30 x 2 Rotor...

  • Page 18: Rotor Installation

    Thermo Scientific Auto-Lock Rotor Exchange Rotor Installation Rotor Installation CAUTION Unapproved or incorrectly combined accessories can cause serious damage to the centrifuge. This rotor is equipped with a Thermo Scientific™ Auto-Lock™-system. This system is used to automatically lock the rotor to the centrifuge spindle. The rotor does not have to be bolted onto the centrifuge spindle.

  • Page 19: Removing The Rotor

    Thermo Scientific Auto-Lock Rotor Exchange Removing the Rotor WARNING Be sure to check all seals before starting any aerosol-tight applications. 4. Close the centrifuge door. Removing the Rotor To remove the rotor, proceed as follows: 1. Open the centrifuge door. 2.

  • Page 21: Rotor Loading

    Rotor Loading Rotor Loading Contents • “Before a Run” page 22 • “Proper Loading” page 22 • “Improper Loading” page 23 • “Maximum Loading” page 23 • “Cycle Counter” page 24 Thermo Scientific MicroClick 30 x 2 Rotor...

  • Page 22: Before A Run

    Rotor Loading Before a Run Before a Run 1. Please read and observe the safety instructions contained in the operating instructions and in the instructions for use. 2. Check the rotor and all accessory parts for damages such as cracks, scratches or traces of corrosion. 3.

  • Page 23: Improper Loading

    Rotor Loading Improper Loading Improper Loading Maximum Loading The rotor can run at high speeds. The rotor design has sufficient reserve stability even when spinning at top speed. The safety system of the centrifuge requires that you do not overload the rotor. There are two options available for centrifuging samples whose weight, including adapter, exceeds the maximum permissible load: •...

  • Page 24: Cycle Counter

    Rotor Loading Cycle Counter Actual Load (g/cavity) 14000 16663 13348 13055 12780 12522 12279 12049 11832 11626 11431 Cycle Counter The lifetime of rotors and buckets is dependent on the amount of mechanical load. Do not exceed the number of cycles recommended for rotors and buckets. The maximum number of cycles is given in the rotor table in the rotor specification section.

  • Page 25: Chapter 4 Aerosol-Tight Applications

    Aerosol-Tight Applications Aerosol-Tight Applications Contents • “Basic Principles” page 26 • “Fill Level” page 26 • “Checking the aerosol Tightness” page 26 Thermo Scientific MicroClick 30 x 2 Rotor...

  • Page 26: Basic Principles

    Aerosol-Tight Applications Basic Principles Basic Principles CAUTION Biological seals are part of bio-containment systems as specified in international and national bio-safety guidelines, and cannot relied on as the only means of safeguarding workers and the environment when handling pathogenic micro-organisms. Mind the “Laboratory Biosafety Manual”...
  • Page 27 Aerosol-Tight Applications Checking the aerosol Tightness 3. Close the bucket or the rotor as explained in the handling instructions. 4. Shake the bucket or the rotor vigorously using your hands. This releases the carbonic acid gas which is bound in the water, resulting in excess pressure. Do not apply pressure to the lid when doing so! Leaks can be detected by escaping water or the sound of escaping gas.

  • Page 29: Maintenance And Care

    Maintenance and Care Maintenance and Care Contents • “Cleaning Intervals” page 30 • “Cleaning” page 30 • “Disinfection” page 32 • “Decontamination” page 33 • “Autoclaving” page 34 • “Thermo Fisher Scientific Service” page 34 Thermo Scientific MicroClick 30 x 2 Rotor...

  • Page 30: Cleaning Intervals

    Maintenance and Care Cleaning Intervals Cleaning Intervals For the sake of personal, environmental and material protection, you have to clean and if necessary, disinfect the centrifuge on a regular basis. Maintenance Recommended Interval Clean rotor chamber Daily or when polluted Clean rotor Daily or when polluted Accessories...
  • Page 31 Maintenance and Care Cleaning 1. Open the centrifuge. 2. Turn off the centrifuge. 3. Pull out the power supply plug. 4. Grasp the rotor with both hands and lift it vertically off the centrifuge spindle. 5. Remove the centrifuge tubes and adapters. 6.

  • Page 32: Disinfection

    Maintenance and Care Disinfection Disinfection Disinfect the centrifuge immediately whenever infectious material has spilled during centrifugation. WARNING Infectious material can get into the centrifuge when a tube breaks or as a result of spills. Keep in mind the risk of infection when touching the rotor and take all necessary precautions.

  • Page 33: Decontamination

    Maintenance and Care Decontamination Decontamination Decontaminate the centrifuge immediately whenever radioactive material has spilled during centrifugation. WARNING Radioactive material can get into the centrifuge when a tube breaks or as a result of spills. Keep in mind the risk of infection when touching the rotor and take all necessary precautions.

  • Page 34: Autoclaving

    Maintenance and Care Autoclaving Autoclaving 1. Before autoclaving clean rotor and accessories. 2. Place the rotor on a flat surface. • Rotors and adapter can be autoclaved at 121 °C. • The maximum permissible autoclave cycle is 20 minutes at 121 °C. Clean the rotor before autoclaving and rinse it with distilled water.

  • Page 35: Rcf-Values

    RCF-Values RCF-Values Speed (rpm) RCF R RCF R 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300 2400 2500 2600 2700 2800 2900 3000 3100 1064 3200 1133 3300 1205 3400 1279 Thermo Scientific MicroClick 30 x 2 Rotor...
  • Page 36 RCF-Values Speed (rpm) RCF R RCF R 3500 1356 3600 1434 3700 1515 3800 1033 1598 3900 1088 1683 4000 1145 1771 4100 1203 1861 4200 1262 1952 4300 1323 2047 4400 1385 2143 4500 1449 2241 4600 1514 2342 4700 1581 2445...
  • Page 37 RCF-Values Speed (rpm) RCF R RCF R 7200 3709 5738 7300 3813 5898 7400 3918 6061 7500 4025 6226 7600 4133 6393 7700 4242 6562 7800 4353 6734 7900 4466 6908 8000 4579 7084 8100 4695 7262 8200 4811 7442 8300 4929 7625...
  • Page 38 RCF-Values Speed (rpm) RCF R RCF R 10900 8501 13150 11000 8658 13393 11100 8816 13637 11200 8975 13884 11300 9136 14133 11400 9299 14384 11500 9463 14638 11600 9628 14893 11700 9795 15151 11800 9963 15411 11900 10132 15674 12000 10303 15938...

  • Page 39: Chemical Compatibility Chart

    Chemical Compatibility Chart Chemical Compatibility Chart CHEMICAL 2-mercaptoethanol S S U - S M S - S U S S U S S - S S S S U S S S S S S Acetaldehyde U U - M U U U M M - M S U - Acetone M S U U S U M S S U U S U S U U U S S U U S M M S U U...
  • Page 40 Chemical Compatibility Chart CHEMICAL Barium Salts M U S - S S S S S S S S S S S M - S S S S S S M S S S Benzene S S U U S U M U S U U S U U U M U M U U U S U U S U S Benzyl Alcohol U U - M M -...
  • Page 41 Chemical Compatibility Chart CHEMICAL (5 %) Acetic Acid S S M S S S M S S S S S M S S S S S S S M S S M S S M (60 %) Acetic Acid S S U U S S U - S M S U U M U S M S M S M S M U S M U Ethyl Acetate M M U U S S M M S S U S U M U U -...
  • Page 42 Chemical Compatibility Chart CHEMICAL Potassium Hydroxide U U S S S S M - S S S S - S U S S S S S S S M U M S U (5 %) Potassium Hydroxide U U M U - M S S - U M U U U S M - M U -...
  • Page 43 Chemical Compatibility Chart CHEMICAL Sodium Borate M S S S S S S S S S S U S S S S - S S S S S S M S S S Sodium Bromide U S S - S S S - S S S S S S S S - S S S S S S M S S S Sodium Carbonate...
  • Page 44 Chemical Compatibility Chart CHEMICAL Rubidium Bromide M S S - S S S - S S S S S S S - S S S S S S M S S S Rubidium Chloride M S S - S S S - S S S S S S S - S S S S S S M S S S Sucrose...
  • Page 45 CHEMICAL Hydrogen Peroxide (3 %) S M S S S - S S S S S S S S M S S S S S S S S S S Xylene S S U S S S M U S U U U U U U M U M U U U S U M S U S Zinc Chloride U U S S S S U S S S S S S S S S S S S S S S S U S S S Zinc Sulfate...
  • Page 47 Index Aerosol-Tight Applications ..... 25 RCF-Values ....... . .35 Autoclaving .
  • Page 49 Thermo Electron LED GmbH Zweigniederlassung Osterode Am Kalkberg, 37520 Osterode am Harz Germany thermofisher.com/rotors © 2013-2020 Thermo Fisher Scientific Inc. All rights reserved. All trademarks are the property of Thermo Fisher Scientific Inc. and its subsidiaries unless otherwise indicated. Delrin, TEFLON, and Viton are registered trademarks of DuPont. Noryl is a registered trademark of SABIC. POLYCLEAR is a registered trademark of Hongye CO., Ltd.
