Ultimaker S6 Installation And User Manual

Ultimaker S6 Installation And User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation
and
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ultimaker S6

Summary of Contents for Ultimaker S6

  • Page 1 Installation user manual...

  • Page 2: Intended Use

    Original instructions Disclaimer This manual sets out the instructions on how to install and operate the UltiMaker S6. Please read and understand the contents of this installation and user manual carefully. Failure to read the manual may lead to personal injury, inferior print results, or damage to the UltiMaker printer or its accessories.

  • Page 3: Table Of Contents

    5.4 Build plate maintenance 1.5 Regulatory information 5.5 Print core maintenance 2. Introduction 6. Troubleshooting 2.1 Product explanation 6.1 UltiMaker support 2.2 Main components 6.2 Error messages 2.3 Specifications 6.3 General recommendations 2.4 Software and accounts 6.4 Print core troubleshooting 6.5 Print quality issues...

  • Page 4: Safety And Compliance

    1. Safety and compliance Read the important notices in this chapter to ensure the safety of the UltiMaker S6 and its operators. Additionally, this chapter contains compliance and regulatory information. 1.1 Safety messages This document contains tips and notes: Tip: Additional information that is helpful to do a task or learn more.

  • Page 5: General Safety Notices

    • Do not change or adjust any parts of the product unless the change or adjustment is authorized by UltiMaker. • Do not store items inside UltiMaker products, except compatible material spools in the Material Station.

  • Page 6: Mechanical Safety

    Glass plate safety The UltiMaker S6 is available in two variants: with a flexible build plate and with a glass build plate. The notes below apply to the glass plate.

  • Page 7: Magnetic Field

    Please check the safety data sheet of each specific material for information. UltiMaker cannot be held responsible for any adverse effects from the use and/or performance of third-party materials.
  • Page 8 Indoor and outdoor use* 1.656 μA/m at 10 meters * Note: The UltiMaker S6 is not intended for outdoor use. FCC Supplier’s Declaration of Conformity This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 9 This product has RF Device modular certification This product has in-country homologation for the following countries: certification for the following countries: • Japan • Israel • • Korea • Qatar • Mexico • Taiwan • Saudi Arabia • Korea UltiMaker S6 Installation and user manual...

  • Page 10: Introduction

    S6 offers versatile capabilities for complex applications. The UltiMaker S6 is the latest addition to the UltiMaker S series. It builds on the S5’s great legacy, maintaining its core versatility and modular design, but includes powerful innovations like the UltiMaker Cheetah for up to 4x speed, substantially better bed leveling for reliable first layers, and dual drive gripper feeders.

  • Page 11: Main Components

    2.2 Main components 13 14 Glass plate variant Flexplate variant UltiMaker S6 1. Bowden tubes 6. Glass build plate 10. Feeder 2 14. NFC port 2. Print head cable 7. Flexible build plate 11. Spool holder with 15. Ethernet port 3.

  • Page 12: Specifications

    Feeder type Dual gripper feeder with tension adjustment, release functionality, and filament feed-rate control Motion planner UltiMaker Cheetah, the world’s first and only jerk limited 3D printer motion planner, with third order continuous, smooth motion, and corner blending algorithm Filament diameter 2.85 mm...

  • Page 13: Software And Accounts

    Or switch to the Custom mode which gives over 400 settings for granular control. The UltiMaker S6 is compatible with UltiMaker Cura version 5.10.1 (and later). For the best printing results, always use the latest version of UltiMaker Cura. Download UltiMaker Cura for free from ultimaker.com/cura.

  • Page 14: Set Up For First Use

    The UltiMaker S6 must be positioned out of direct sunlight during operation. • Ensure there is sufficient space around the printer for airflow and material handling: UltiMaker S6: If using the spool holder, allow at least 20 cm (8 in) of space behind the printer. • •...

  • Page 15: Included Components

    6. Place the printer on the floor, or onto a flat, level, and stable surface (see section 3.1). For the Pro Bundle: You can install the S6 directly on the Material Station (see section 3.4), or temporarily place it on a desk first to remove the other packaging materials.

  • Page 16: Installation

    1. Insert the spool holder into the back panel and push until it snaps into place. 2. Secure the cable behind the clips in the UltiMaker S6 back panel. 3. Connect the spool holder cable to the NFC socket in the back panel.

  • Page 17: Glass Build Plate

    7. Connect the cable to the 8. Use the cable clips to secure UMB OUT port at the the Air Manager cable to the back of the printer*. spool holder cable*. UltiMaker S6 Installation and user manual...

  • Page 18: Power Cable

    2. Plug the other end of the cable into a wall outlet. If the UltiMaker S6 is installed with a Material Station, connect the power cable to the Material Station instead. A mains socket with a protective earth/ground terminal must be used.

  • Page 19: Welcome Setup

    3.5 Welcome setup Turn on the printer using the power switch at the back. When you power on the UltiMaker S6 for the first time, a welcome setup will appear on the display. This guided setup walks you through essential configuration steps to ensure the printer is ready for its first print.

  • Page 20: Operation

    All UltiMaker materials have been extensively tested and have optimized profiles in UltiMaker Cura to ensure the best print results. Therefore, it is advised to use one of the default profiles in UltiMaker Cura for the highest reliability. Using UltiMaker materials will also allow you to benefit from the NFC detection system. UltiMaker spools will be automatically recognized by the material bays.

  • Page 21: Print Cores

    Material Station. 4.3 Print cores The UltiMaker S6 uses two print cores in the print head, which can easily be changed. There are different types of print cores. See which types are supported on the UltiMaker S6 in the overview below:...

  • Page 22: Preparing A Print

    After installing the software, complete the first-run experience. If you sign in to your UltiMaker Account, you can add any printers already connected to your Digital Factory workspace. If your UltiMaker S6 is not connected yet, set it up via the Digital Factory option on the printer, or add the printer manually from the list of non-networked printers.

  • Page 23: Printing Process

    Pre-print When a print job is selected, either remotely or via USB, the UltiMaker S6 will automatically prepare for printing. This can take several minutes and includes the following processes: Configuration check. The printer will check if the printer has the right configuration for the selected print •...

  • Page 24: Remove The Print

    4.6 Remove the print Once your 3D print is finished, it must be removed from the build plate. The UltiMaker S6 is available in two variants, with different build plate options. See the instructions for your build plate type below.

  • Page 25: Remove Support Material

    PVA support structures can be removed easily by dissolving the PVA in water and leave no trace afterward. Dissolving PVA can take up to several hours. Tip: Experience quicker and easier post-processing when using PVA support material with the UltiMaker PVA Removal Station. The PVA Removal Station removes PVA up to 4x faster compared to motionless water.

  • Page 26: Change Configuration

    4.8 Change configuration The UltiMaker S6 is compatible with several print core types and a wide variety of materials. Changing the configuration to print different applications is quick and simple, and no tools are necessary. Select the Change option in the Configuration menu and the printer will guide you through the steps.
  • Page 27 Note: If the current print core and material configuration is not allowed (e.g. print core AA+ with PVA material), the printer will prompt you to also change the material. This only applies if the UltiMaker S6 is used without a Material Station.
  • Page 28 Tip: You can pre-load any material, even if no compatible print core is currently installed in the print head. You can change the print core type later. The printer will show a configuration change prompt when a print job is started. UltiMaker S6 Installation and user manual...

  • Page 29: Calibrations

    A correct XY calibration will ensure that the two colors or materials align well. The print cores that are supplied with the UltiMaker S6 are already calibrated. For any new combination of print cores, an XY offset calibration must be performed.

  • Page 30: Build Plate Leveling

    If not, select No to perform the calibration again. Build plate leveling UltiMaker S series printers feature a large build surface, making precise leveling essential for high-quality prints. To ensure consistent nozzle-to-build-plate distance across the entire surface, the UltiMaker S6 automatically performs an active leveling procedure at the start of each print.
  • Page 31 With the manual leveling process, you can adjust the tilt and the height of the build plate. The printer will guide you through the steps. Note: Manual leveling is only available on the UltiMaker S6 with a glass build plate. The flexplate variant does not require manual build plate calibration, as the build plate is fixed in place.

  • Page 32: Maintenance

    Note: Do not power off the printer during the firmware installation. Update using a USB stick If the UltiMaker S6 is not connected to a network, you can update to the latest firmware via USB. The firmware files are found on the UltiMaker website: 1.

  • Page 33: Preventive Maintenance Schedule

    The Air Manager filter should be replaced after 1500 hours. Directly place the used filter in a (resealable) bag and close it. Tip: For detailed instructions on how to perform each maintenance action, visit support.ultimaker.com or go to UltiMaker Digital Factory. UltiMaker S6 Installation and user manual...

  • Page 34: Build Plate Maintenance

    5. Reinstall the glass build plate. Slide the glass plate into the clamps at the back, while keeping the glass flat. Close the clamps at the front to secure the glass build plate. Note: Leaving the build plate clamps open may damage your printer when the build plate is raised. UltiMaker S6 Installation and user manual...

  • Page 35: Print Core Maintenance

    You will need UltiMaker cleaning filament, pliers, and wire cutters. In the Options menu, navigate to Maintenance → Print head → Print core cleaning to get started. Follow the instructions on the display.

  • Page 36: Troubleshooting

    6.2 Error messages When the UltiMaker S6 detects that something is wrong, or when it reads values outside of the allowed range, an error will occur. The display will give a short description of the detected issue along with its unique error code.

  • Page 37: Print Core Troubleshooting

    S6 for specific applications: BB for support materials and DD for Ultrafuse® Support Layer material. Note: Although the regular AA and CC cores can be used on the UltiMaker S6, there are no profiles to support this configuration in UltiMaker Cura.

  • Page 38: Print Quality Issues

    Check if the rubber anti-slip feet are installed (if the printer is used without a Material Station). Do not place the UltiMaker S6 in direct sunlight as this may cause sagging in overhangs and other quality issues.

  • Page 39: Limited Warranty

    UltiMaker or its authorized reseller will assess warranty claims to determine their validity. If the claim is justified, UltiMaker or the reseller shall rectify the defects by repairing or replacing the non-conforming or damaged part(s) of the Product in a commercially reasonable time.

  • Page 40: Exclusions

    INCIDENTAL, COLLATERAL, EXEMPLARY, PUNITIVE, SPECIAL, OR CONSEQUENTIAL DAMAGES, INCLUDING LOSS OF USE OR LOSS OF PROFITS, EVEN IF ULTIMAKER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH CLAIMS OR DAMAGES. ULTIMAKER’S LIABILITY IS LIMITED TO THE PURCHASE VALUE OF THE PRODUCT.

  • Page 41: Contact And Links

    Contact and links Do you have a question about the UltiMaker S6 or compatible products? Find a list of links below with more information or submit a support case. Support support.ultimaker.com Visit our knowledgebase for information about all UltiMaker products.
