Ultimaker S5 Material Station
Repair manual: Prefeeder
Required
Tools
• ESD prevention supplies
• Torque screwdriver (adjustable)
• 0.3 Nm
• 2.0 mm hex bit
• 2.0 mm hex screwdriver
Parts
• 1x 213625 - Prefeeder assembly
Time
• 25 minutes
Notes
Caution:
Make sure the Ultimaker S5 Material Station is
turned off and the power cable is disconnected before you
start the replacement.
Safety note:
The Material Station has a built-in power supply.
Disconnect the power cable before starting this repair. Never
connect the power cable when the bottom cover is removed.
Caution:
This repair involves working with or exposing
sensitive electronic components. Take ESD precautions before
starting this procedure.
Tip:
All orientations are as seen from the front in the upright
orientation, unless specified otherwise.

Advertisement

loading
Need help?

Need help?

Do you have a question about the S5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ultimaker S5

Summary of Contents for Ultimaker S5

  • Page 1 Ultimaker S5 Material Station Repair manual: Prefeeder Required Notes Tools Caution: Make sure the Ultimaker S5 Material Station is • ESD prevention supplies turned off and the power cable is disconnected before you • Torque screwdriver (adjustable) start the replacement. • 0.3 Nm •...
  • Page 2 5. Pull the pin out of the right side panel 6. Pull the tabs out of the back panel Rep eat steps 4. and 5. for the left panel Place the bottom cover aside Ultimaker S5 Material Station Repair manual: Prefeeder...
  • Page 3 Caution: Handle the NFC antennas carefully; they are fragile Tip: Start on the right side and loosen the clips one by one. Gently pull the main PCB upwards above each prefeeder Ultimaker S5 Material Station Repair manual: Prefeeder...
  • Page 4 18. Lift the prefeeder out of the Material sliding it across the bottom plate Station and place it aside Tip: For prefeeders 1 and 5, ensure to keep all wires out of the way when sliding the prefeeder backwards Ultimaker S5 Material Station Repair manual: Prefeeder...
  • Page 5 6. Push the black slider down to secure the connector in the middle interface panel cable Tip: Push the cable over the black slider, into the white connector Tip: Gently pull the cable to check if it is properly secured Ultimaker S5 Material Station Repair manual: Prefeeder...
  • Page 6 The Bowden tubes closest to the bottom panel go Tip: The ‘left’ is as seen from the front, in upright position. It is the into the left merger side without the door damper Tools: 2.0 mm hex screwdriver Ultimaker S5 Material Station Repair manual: Prefeeder...

  • Page 7: Hardware Checks

    16. Insert an M3x35 bolt through the middle of the mergers to secure them to the merger mount Note: The bolt goes through the hole at the front (prefeeder side) Tools: 2.0 mm hex screwdriver Ultimaker S5 Material Station Repair manual: Prefeeder...
  • Page 8 19. Push the front of the cover so the three 20. Secure the bottom cover with two tabs snap into place M3x16 flat head bolts Tools: Torque screwdriver with hex 2.0 mm bit, 0.3 Nm Finished! Place the Material Station upright again Ultimaker S5 Material Station Repair manual: Prefeeder...
